FOXBORO FCP280 RH924YA High Performance Field Control Processor

Description

FOXBORO FCP280 RH924YA is a high-performance field control processor

FOXBORO FCP280 RH924YA

It serves as the central nervous system of the control system, receiving information from numerous sensors and field devices, processing this data, and then sending instructions to actuators and other control components. It is an important component of the Foxboro I/A series distributed control system (DCS), which is widely used in the field of industrial automation. In the control system architecture, it occupies a core position and can achieve seamless communication between on-site devices and higher-level monitoring and control stations. For engineers and system integrators, its value lies in the ability to handle complex control tasks, support a wide range of fieldbus modules, and be easy to program to meet the specific requirements of different industrial applications.

FOXBORO FCP280 RH924YA

Main features and advantages:
In terms of functional performance, it is equipped with a high-speed processor. With its advanced processing capabilities, it can execute a large number of control blocks per second, ensuring that real-time control applications can respond quickly. It can manage a large number of control blocks and implement extensive and complex control logic.

The hardware design of FCP280 RH924YA is sturdy and durable, specifically designed to withstand harsh industrial environments. It adopts a sturdy casing and can operate in harsh environments of G3 class. Its operating temperature range is 0 to+60 ° C, capable of withstanding non condensing humidity of 5% to 95%, and can maintain reliable operation even under the most challenging conditions. Its modular configuration is easy to expand and customize, and can support multiple fieldbus modules.

In terms of compatibility, it has excellent connectivity options. It supports different series of fieldbus modules (FBMS) and can connect a large number of these modules. It communicates with the Foxboro Evo control network through standard fiber optic or 100 Mbps Ethernet copper cable, ensuring high-speed and reliable data transmission. This enables seamless integration with other components in industrial control settings.

In terms of long-term reliability, it has sufficient memory and has error correction code (ECC) functionality. This ensures data integrity during operation. This module also has fault-tolerant operation function, which ensures continuous operation in case of hardware failure and minimizes downtime to the greatest extent possible.

FOXBORO FCP280 RH924YA

Technical specifications:
Model FCP280 RH924YA
Brand FOXBORO
Type: On site Control Processor
Power supply 24 VDC
Working temperature: 0 ° C to+60 ° C
Installation method: Rack installation (compatible with standard industrial racks)
Dimensions (length x width x height) 147 mm x 51.5 mm x 116 mm
Weight 0.8 kg
Ethernet interface (100 Mbps fiber or copper cable) RS – 232/485
CE certification, in compliance with relevant industrial standards
Natural convection for heat dissipation (specifically designed for efficient heat dissipation in industrial environments)
Environmental grade G3 (suitable for harsh environments)

Contact Us
Phone:+86 16626708626
WhatsApp/WeChat:+86 16626708626
Email: 3772179818@qq.com

Application areas:
Stable and efficient electricity production is crucial in power plants, whether they are coal-fired, gas-fired, or nuclear power plants. FCP280 RH924YA plays a crucial role here. It continuously monitors key parameters such as temperature, pressure, and flow rate in the steam and coolant systems. By precisely controlling steam turbines, boilers, and other important equipment, it ensures efficient power production while reducing the risk of power outages caused by equipment failures.

Petrochemical plants handle hazardous substances and complex chemical reactions. Here, FCP280 RH924YA is indispensable. It precisely manages the opening and closing of valves, adjusts the speed of pumps, and controls the temperature of reactors. This not only improves production efficiency, but also reduces the risk of accidents and environmental pollution. Manufacturing factories, especially those with large-scale production lines, rely on FCP280 RH924YA to maintain smooth production. It coordinates the operation of the conveyor belt, controls the speed of the machine, and monitors product quality in real time. If any deviation is detected, it can quickly adjust the production process to maintain product quality and production speed.

Related products:
FOXBORO FBM200- This fieldbus module can be directly connected to FCP280 RH924YA, providing additional input and output channels for connecting various sensors and actuators on site, thereby expanding the system’s data acquisition and control capabilities.
FOXBORO FEM100- Fieldbus Expansion Module 100, when used in conjunction with FCP280 RH924YA, can connect more fieldbus modules, significantly enhancing the system’s ability to handle field devices and expanding control range.
FOXBORO P0971GN – A power unit that can be used to ensure stable and reliable power supply for FCP280 RH924YA, enhancing its overall performance and reliability in industrial operations, and preventing power related issues.
FOXBORO I/A series operator interface station – This interface station can be integrated with FCP280 RH924YA, providing an easy-to-use interface for operators to monitor and control industrial processes managed by FCP280, improving operational efficiency.
FOXBORO Network Management Interface – Connected to FCP280 RH924YA, used to manage and optimize communication networks within industrial control systems, ensuring smooth data transmission between different components and efficient system operation.

Installation and maintenance:
Before installing FCP280 RH924YA, it is necessary to carefully plan the rack layout. Ensure there is sufficient space around the module for proper ventilation as it operates within a specific temperature range. The rack should be properly grounded to protect the module from surge damage. When connecting fieldbus modules and other devices, carefully check the wiring diagram to ensure correct connections and complete signals. During installation, handle the module carefully to avoid electrostatic discharge, as it may damage its sensitive components.

For maintenance work, establish a regular visual inspection plan. Inspect the casing for any signs of physical damage, such as cracks or dents, and check for loose connections. Regularly conduct diagnostic tests to verify the communication capability and data processing accuracy of the module. Maintain firmware updates for FCP280 RH924YA, as new versions of firmware typically include bug fixes, performance improvements, and enhanced compatibility with other system components.
