EMERSON MVME61006E-0163 Embedded computing module

Description

Emerson MVME61006E-0163 is an advanced embedded computing module. It is part of Emerson’s comprehensive industrial grade product portfolio, designed to meet the strict requirements of industrial and high-tech applications.

MVME61006E-0163

As the central processing unit in larger systems, it can interface with various input/output devices, storage media, and communication networks. For engineers and system integrators, its value lies in providing a stable and high-performance computing platform that can be customized according to specific application requirements. Whether building a new industrial control system from scratch or upgrading an existing system, MVME61006E-0163 can provide the required flexibility and processing power.

MVME61006E-0163

Main features and advantages:
It uses the MPC7457 PowerPC processor and runs at a frequency of up to 1.267 GHz. This high-speed processing core enables it to easily handle complex computing tasks. Whether conducting real-time data analysis, running complex control algorithms, or multitasking between different software applications, MPC7457 ensures smooth and efficient system operation. In terms of memory, it is equipped with Double Data Rate (DDR) Random Access Memory (RAM) with Error Correction Code (ECC) function. The starting capacity is 512MB and can be expanded up to 2GB. The error correction code function provides additional reliability assurance for applications where data integrity is crucial by detecting and correcting single bit errors in memory. Combined with 128MB of flash memory, it provides non-volatile storage for the operating system, firmware, and necessary configuration data of the system.

In terms of connectivity, this module is fully functional. It has dual Gigabit Ethernet interfaces and supports speeds of 10/100/1000 Mbps. This high-speed network connection can achieve fast data transmission and is very suitable for applications that require real-time data exchange, such as control systems based on industrial Ethernet or data collection settings for network connections. In addition, it also provides multiple input and output interfaces. Serial ports can be used to connect old devices or sensors that use serial communication protocols. The Universal Serial Bus (USB) port provides a convenient way to connect external devices such as storage drives, keyboards, or other peripherals. The VME (Versa Module Europa) bus interface is a key feature that enables seamless integration with other VME compatible modules in modular industrial control systems. The diversity of input and output interfaces enablesMVME61006E-0163 to highly adapt to different system architectures.

The module was designed with durability in mind. Its dimensions are 8.25 inches x 9.5 inches x 4.5 inches, with a weight of approximately 0.36 kilograms. Its compact appearance makes it easy to install in various industrial chassis. Its IP65 protection rating means it can effectively prevent dust and water spray. This makes it suitable for deployment in harsh industrial environments, such as dusty factories or outdoor installation scenarios that may be exposed to water spray. It can operate within a wide temperature range of -40 ° C to+85 ° C, further demonstrating its adaptability under extreme environmental conditions.

MVME61006E-0163

Technical specifications:
Model MVME61006E-0163
Brand Emerson
Type Embedded Computing Module
Processor MPC7457 PowerPC, 1.267 GHz
Double data rate random access memory with error correction code function (512MB -2GB), 128MB flash memory
Ethernet interface dual gigabit (10/100/1000 Mbps)
Input/output interface serial, universal serial bus, VME bus
Working temperature -40 ° C to+85 ° C
Installation method designed for industrial grade chassis installation
Dimensions 8.25 inches x 9.5 inches x 4.5 inches
Weight 0.36 kilograms
Protection level IP65

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

MVME61006E-0163

Installation and maintenance:
Before installing Emerson MVME61006E-0163, integrators need to consider several factors. Firstly, they must ensure that the physical space inside the industrial chassis is sufficient to accommodate the size of the module. Adequate ventilation should be provided for heat dissipation, especially considering its operation over a wide temperature range. Proper grounding is crucial for preventing electrical interference and ensuring the safety of modules and the entire system in terms of electrical connections. The power supply should be carefully selected to meet the requirements of the module and must comply with any specifications related to the power supply, such as voltage and current ratings.

In terms of maintenance, it is recommended to conduct regular visual inspections. Check for any signs of physical damage, such as cracked casing or loose connections. It may be necessary to regularly update the firmware of the module. Emerson typically releases firmware updates to improve performance, fix vulnerabilities, and enhance compatibility with other components. Monitoring the temperature of the module during operation can also help identify any potential overheating issues. In addition, running diagnostic tests can ensure that various components of the module, such as processors, memory, and input/output interfaces, are functioning properly.

MVME61006E-0163
