Emerson CON021 Eddy Current Signal Converter

Description

Emerson CON021 is an eddy current signal converter.

CON021

It is a key part of Emerson’s comprehensive industrial monitoring and control product line. It is designed specifically for use with various eddy current sensors such as PR 6422, PR 6423, PR 6424, PR 6425, PR 6426, and PR 6453, serving as a bridge between sensors and data acquisition and analysis systems. In the architecture of industrial monitoring systems, CON021 receives analog signals from eddy current sensors. Then, these signals are converted into a format that other components in the system can easily process and understand. For engineers and integrators, its value lies in the ability to improve the accuracy and reliability of mechanical monitoring. By providing precise signal conversion, it enables more informed decisions in equipment maintenance and operation.

CON021

Main features and advantages:
It has a frequency range of 0 to 20000 Hz (-3 dB) and can accurately capture and process a wide range of signals related to mechanical operation. A rise time of less than 15 µ s ensures that it can quickly respond to changes in sensor input, providing real-time data for critical applications. In terms of hardware design, it has a compact and sturdy structure. The shell is made of LMG SI 0.5 F22 material, which can withstand harsh industrial environments. The self-locking Lemo plug sensor and screw terminal type for power/output (capable of handling wires up to 1.5mm ²) not only make the connection easy and safe, but also help improve its durability. Compatibility is a significant advantage. As mentioned earlier, it is designed to work seamlessly with various eddy current sensors. Although its IP20 protection level is not completely waterproof, it can prevent solid objects from entering and limit dust from entering, making it suitable for many industrial environments. In terms of long-term reliability, it can operate within a wide temperature range of -30 ° C to 100 ° C (-22 ° F to 212 ° F), reducing the risk of performance degradation due to temperature fluctuations.

CON021

Technical specifications:
Model CON021
Brand Emerson
Type Eddy Current Signal Converter
Power supply -23 V to -32 V (output range -4 V to -20 V); -21 V to -32 V (output range -2 V to -18 V)
Working temperature -30 ° C to 100 ° C (-22 ° F to 212 ° F)
Weight 120 g

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

CON021

Application areas:
In power plants, CON021 is crucial for monitoring the status of steam turbines, gas turbines, and generators. By accurately measuring key parameters related to these machines, it helps prevent catastrophic failures that could lead to widespread power outages.
In the oil and gas industry, it is used for compressors and pumps to ensure their stable operation and minimize the risk of leaks or malfunctions that may cause serious environmental and economic consequences. This makes the Emerson CON021 an indispensable component in industrial automation and mechanical protection settings.

Related products:
PR6422 eddy current sensor – used in conjunction with CON021 to provide raw eddy current signals that are subsequently converted into useful data for analysis.
PR6423 eddy current sensor – another sensor highly compatible with CON021, capable of accurately monitoring mechanical parameters such as shaft displacement and eccentricity.
PR6424 Eddy Current Sensor – Similar to the aforementioned sensors, it is paired with CON021 to provide precise measurements in industrial applications, particularly in turbomachinery.
PR6425 eddy current sensor – used in conjunction with CON021 to improve the reliability of mechanical health monitoring systems and ensure early detection of potential issues.
PR6426 eddy current sensor – CON021 processes signals from this sensor, which are crucial for maintaining optimal performance of rotating equipment in various industrial environments.
PR6453 eddy current sensor – seamlessly integrated with CON021, helps improve the overall accuracy and effectiveness of mechanical monitoring solutions.
Data acquisition systems – These systems rely on signals converted by CON021 to store and analyze data related to mechanical operation, enabling trend analysis and predictive maintenance.

CON021

Installation and maintenance:
Before installing Emerson CON021, integrators should carefully consider the installation location. Make sure to place it in a well ventilated area to prevent overheating, especially considering that it will operate within a specific temperature range. Although it has an IP20 protection level, it should be installed in a location relatively free of excessive dust and large solid particles to maintain its performance over the long term. Please strictly follow the wiring diagram provided by Emerson when making connections. The self-locking Lemo plug and screw terminal connection are designed for safe connection, but wiring errors may result in signal errors or even damage to the module.
In terms of maintenance, it is recommended to conduct regular visual inspections. Check for any signs of physical damage, loose connections, or abnormal discoloration on the casing (which may indicate overheating). Regular calibration of CON021 may be necessary in conjunction with relevant eddy current sensors to ensure accurate signal conversion. Calibration should be carried out according to Emerson’s recommended procedures.
