Emerson 5X00846G01 dedicated module

Description

Emerson 5X00846G01 is a dedicated module in the Emerson Ovation Distributed Control System (DCS). However, its functionality is not limited to Ovation system, making it a universal choice for various industrial control settings. This module operates at 24 VDC voltage, providing stable power for its operation. The module has 8 analog output channels, each of which can output high-resolution analog signals. Its resolution is 16 bits, which can accurately represent a wide range of numerical values, ensuring precise control of connected devices.

5X00846G01

This module supports the HART (addressable remote sensor highway) protocol and can communicate digitally with intelligent field devices. This not only achieves more precise control, but also provides additional diagnostic information, improving the overall reliability of the system. The analog output range is -10 V to+10 V, suitable for various application scenarios. The output accuracy is within ± 0.1% of the full range, ensuring high precision of the control signal. The fast response time is less than 250 microseconds, which enables real-time control and is crucial for applications that require quick adjustments.

5X00846G01

Main features and advantages:
The Emerson 5X00846G01 module is designed to withstand harsh industrial environments. Its working temperature range is -40 ° C to 85 ° C, and it can operate reliably in extreme cold or hot conditions. This module can also withstand environments with relative humidity ranging from 5% to 95% (non condensing), making it suitable for humid industrial environments. In terms of mechanical robustness, it can withstand vibrations of up to 5 g (10 Hz to 500 Hz) and impacts of 10 g for 20 milliseconds, ensuring stable operation even in environments with significant mechanical stress.

Its high-resolution output function enables precise control of actuators such as valves and motors, thereby improving process efficiency and product quality. The support for the HART protocol enables seamless integration with intelligent field devices, providing valuable diagnostic data and improving system reliability. Fast response time ensures that control actions can be executed in a timely manner, minimizing process delays and optimizing overall system performance.

The module’s wide operating temperature range and high tolerance to humidity and mechanical stress make it suitable for various industrial environments, from refineries to food processing plants. Its compact design and modular structure simplify installation and maintenance work, reducing downtime and related costs. The Emerson 5X00846G01 module also provides flexibility in system configuration, making it easy to expand and adapt to constantly changing industrial needs.

5X00846G01

Technical specifications:
Model: 5X00846G01
Brand Emerson
Type 8-channel fast HART analog output module
Input voltage 24 VDC
Number of output channels 8
Output range -10 V to+10 V
Resolution 16 bits
Accuracy within ± 0.1% of full range
Response time<250 microseconds
Working temperature range -40 ° C to 85 ° C
Storage temperature range -40 ° C to+85 ° C
Humidity tolerance range 5% -95% (non condensing)
Anti vibration ability 5 g, 10 Hz to 500 Hz
Impact resistance of 10 g, 20 milliseconds
Dimensions (width x height x depth) 125mm x 75mm x 25mm
Weight 510 grams
Power consumption<5 W
Communication protocol HART

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

5X00846G01

Application areas:
In the power generation industry, it is used to control the output of power plants by adjusting turbine speed and generator voltage.
In the water treatment industry, it can be used to control the dosage of chemical agents and the operation of pumps, ensuring efficient water treatment.
In the manufacturing industry, this module can be used to control the operation of production lines, such as adjusting the speed of conveyor belts or controlling the position of robotic arms.
It is also applied in the chemical, pharmaceutical, and oil and gas industries, where precise process control is crucial.

5X00846G01

Related products:
Emerson 5X00847G02- Upgraded version, with more output channels and enhanced processing capabilities, suitable for more complex industrial applications that require controlling more equipment.
Emerson 5X00845G01- An affordable alternative product with basic analog output capabilities, suitable for industrial settings with limited budgets and low performance requirements.
Emerson 5X00846G01- HAZ – intrinsically safe variant, designed for use in hazardous environments such as areas with explosive gases or flammable substances, ensuring safe operation in high-risk environments.
Emerson 5X00846G01- EXT – With an extended temperature range and enhanced environmental tolerance, it is suitable for outdoor applications or environments with extreme cold or hot conditions.
Emerson 5X00846G01- PRO – Provides advanced features such as advanced diagnostic capabilities, faster response times, and higher precision to meet industry demands for high precision.
Emerson 5X00846G01- RF – integrates wireless communication capabilities, suitable for applications where wired connections are impractical, such as large industrial plants with complex layouts or mobile industrial equipment.

5X00846G01

Installation and maintenance:
Before installing the Emerson 5X00846G01 module, it is essential to verify its compatibility with the existing control system. Check the voltage requirements, communication settings, and the type of equipment planned to be connected. Ensure that there is sufficient space inside the industrial cabinet to accommodate the module. At the same time, check if the firmware version is Emerson’s latest version to obtain the most stable features and safety enhancements, which can further optimize the performance of the module.

For daily maintenance, the status of modules should be regularly monitored through diagnostic tools in the control system. Check for signs of abnormal output signals, communication errors, or component degradation. Check for signs of wear or corrosion at the connection, as these can affect the accuracy of the analog signal. Regularly calibrating analog outputs (such as once a year) helps maintain module accuracy and ensure reliable operation of industrial automation systems.
