The Emerson 5X00453G01 is a precision analog input/output module that can be seamlessly integrated into the Emerson Ovation distributed control system (DCS) and is also compatible with other related control platforms.
5X00453G01
This module operates at 24V DC voltage, providing stable power supply for its operation. The module has 8 analog input channels and 4 analog output channels, equipped with high-resolution analog-to-digital converters (ADCs) and digital to analog converters (DACs), which can achieve precise signal conversion. Analog input supports multiple input types, including voltage (± 10V), current (4-20mA), and resistance (0-1000 Ω), enabling it to connect various sensors. Analog output can drive loads up to 500 Ω and control various actuators.
5X00453G01
Main features and advantages:
The sampling rate of Emerson 5X00453G01 is as high as 100 samples per second per channel, which can quickly capture and process data, ensuring real-time monitoring and control. It also supports built-in diagnostic functions, sustainable monitoring modules, and the health status of connected devices. If any malfunction or abnormal situation occurs, the module will issue an alarm so that operators can take corrective measures in a timely manner. This module is designed to withstand harsh industrial environments, with a working temperature range of -40 ° C to+70 ° C and a storage temperature range of -40 ° C to+85 ° C. It can also withstand up to 5g (10Hz to 500Hz) of vibration and 10g of continuous impact for 20 milliseconds, ensuring reliable operation in harsh industrial environments.
The high-resolution signal conversion capability ensures accurate measurement of process variables, thereby improving product quality and reducing waste. The wide range of input types and high-capacity output loads provide flexibility for system design, making it easy to integrate different sensors and actuators. A fast sampling rate enables real-time monitoring and control, enabling the system to quickly respond to process changes and improve overall operational efficiency.
The built-in diagnostic function simplifies maintenance work, and operators can easily identify and troubleshoot faults without the need for extensive manual testing. This module is sturdy and durable, with a wide operating temperature range, suitable for various industrial environments from extreme cold to high temperature, and will not affect performance. Its compatibility with multiple control platforms also reduces the complexity of system integration, saving time and resources during installation and debugging processes.
5X00453G01
Technical specifications:
Model 5X00453G01
Brand Emerson
Type Analog Input/Output Module
Input voltage 24V DC
8 analog inputs
4 analog outputs
Input type voltage (± 10V), current (4-20mA), resistance (0-1000 Ω)
Output load capacity up to 500 Ω
Sampling rate up to 100 samples per second per channel
Resolution (ADC/DAC) High Resolution
Working temperature range -40 ° C to+70 ° C
Storage temperature range -40 ° C to+85 ° C
Anti vibration ability 5g, 10Hz to 500Hz
Impact resistance 10g, 20ms
Dimensions (width x height x depth) 120mm x 80mm x 40mm
Weight 0.4kg
Power consumption<3W
contact us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
5X00453G01
Application areas:
In the field of energy, it is used to monitor and control parameters such as voltage, current, and power in power generation and distribution systems, ensuring grid stability and efficient energy management.
In the pharmaceutical industry, it can precisely control the temperature, pressure, and flow rate during the manufacturing process, ensuring product quality and meeting strict regulatory requirements.
In the food and beverage industry, this module is used to control the filling and packaging process, maintain product consistency, and reduce production losses.
5X00453G01
Related products:
Emerson 5X00454G02- With more input/output channels and enhanced processing capabilities, it is suitable for more complex industrial applications that require monitoring and controlling more variables.
Emerson 5X00452G01- equipped with basic analog input/output functions, suitable for industrial settings with limited budgets and low requirements.
Emerson 5X00453G01- HAZ – Designed for use in hazardous environments with explosive gases or flammable materials, ensuring safe operation in high-risk industrial environments.
Emerson 5X00453G01- EXT – with an extended temperature range and enhanced environmental tolerance, suitable for outdoor applications or extreme cold or hot environments.
Emerson 5X00453G01- PRO – Provides advanced features such as advanced diagnostic capabilities, faster data transfer rates, and higher accuracy to meet industry demands for high precision.
Emerson 5X00453G01- RF – Integrated wireless communication function, suitable for applications where wired connections are impractical, such as large industrial factories with complex layouts or mobile industrial equipment.
5X00453G01
Installation and maintenance:
Before installing Emerson 5X00453G01, it is essential to verify its compatibility with your existing control system. Check the voltage requirements, communication protocol, and the type of sensors and actuators you plan to connect. Ensure that there is sufficient space in the industrial cabinet to install the module. In addition, checking the firmware version with Emerson’s latest version to obtain the most stable features and safety enhancements can further optimize the performance of the module.
For daily maintenance, the diagnostic status of the module should be regularly monitored through the interface of the control system. Check for signs of abnormal signal readings, communication errors, or component degradation. Check for signs of wear or corrosion at the connection, as these can affect the accuracy of the analog signal. Regularly calibrating analog inputs and outputs, perhaps once a year, can help maintain module accuracy over time and ensure reliable operation of industrial automation systems.
