Emerson 5X00419G02 is an advanced Ethernet link controller module that occupies a core position in Emerson Ovation distributed control system (DCS). However, its versatility goes far beyond that, and it also demonstrates excellent compatibility with numerous other industrial control platforms. This module is designed to operate at 24 VDC voltage, providing a stable and reliable power supply for its operation. It is equipped with a high-speed Ethernet interface, which not only simplifies the connection process, but also achieves fast data transmission of 10/100 Mbps. This high-speed connection is crucial for applications that require real-time data exchange, such as high-speed production lines or complex process control systems.
5X00419G02
This module supports multiple network protocols, including TCP/IP, Modbus TCP, UDP, and ICMP. This extensive protocol support enables effective communication with various other devices in industrial networks, from sensors and actuators to other control modules and upper computers. It also has timestamp function with an accuracy of ± 100 microseconds, which is very valuable for applications that require precise time synchronization of multiple components in the control system. The Emerson 5X00419G02 is designed to withstand harsh industrial environments, with a working temperature range of -40 ° C to+70 ° C and a storage temperature range of -40 ° C to+85 ° C. It can also withstand humidity ranges of 5% to 95% (non condensing), as well as vibrations up to 5 g (10 Hz to 500 Hz) and impacts of 10 g for 20 milliseconds. This sturdy structure ensures that the module can operate reliably even under the most challenging industrial conditions.
5X00419G02
Technical specifications:
Model 5X00419G02
Brand Emerson
Type Ethernet Link Controller Module
Input voltage 24 VDC
Communication interface Ethernet
Network protocols TCP/IP, Modbus TCP, UDP, ICMP
Transmission rate 10/100 Mbps
Timestamp accuracy ± 100 microseconds
Working temperature range: 40 ° C to+70 ° C
Storage temperature range: 40 ° C to+85 ° C
Humidity tolerance range 5% to 95% (non condensing)
Anti vibration ability 5 g, 10 Hz to 500 Hz
Impact resistance of 10 g, 20 milliseconds
Dimensions (width x height x depth) 125 mm x 105 mm x 35 mm
Weight 0.5 kg
Power consumption<2 W
contact us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
5X00419G02
Main features and advantages:
Its advanced processing capability benefits from an enhanced architecture that enables the implementation of complex control algorithms, thereby achieving real-time process management. This means that industrial processes can be optimized in real-time, thereby increasing productivity, reducing waste, and improving product quality. The high compatibility of this module ensures seamless integration with existing Ovation system components and software, as well as other industrial control systems. This not only simplifies the installation process, but also reduces the need for complex and expensive system modifications.
Built in enhanced security features, including multi-layer security protocols, can protect modules from network threats. In the era where industrial network security is crucial, this feature provides peace of mind, ensuring that industrial control systems are protected from unauthorized access and malicious attacks. This module supports timestamps to achieve precise system time synchronization, which is crucial for applications that require multiple components to coordinate operations. This ensures that all devices in the control system can operate synchronously, minimizing errors and improving overall system performance.
5X00419G02
Application areas:
In the power generation industry, it plays a key role in connecting various control devices and sensors in power plants, achieving real-time monitoring and control of the power generation process, helping to ensure stable power supply and grid stability.
In the chemical industry, it is used to establish reliable communication between process control systems and on-site equipment, thereby achieving precise control of chemical reactions and processes.
In the water treatment industry, this module is used to manage the operation of pumps, valves, and other equipment to ensure effective water treatment and distribution.
It has also been applied in the manufacturing industry and can be used to control the operation of production lines, robots, and other automation equipment.
5X00419G02
Related products:
Emerson 5X00420G03- With enhanced processing capabilities, additional communication interfaces, and advanced safety features, it is suitable for more complex and demanding industrial applications.
Emerson 5X00418G01- equipped with basic Ethernet link control functions, suitable for industrial environments with budget constraints and low complexity requirements.
Emerson 5X00419G02- HAZ – Designed for use in hazardous environments such as areas with explosive gases or flammable materials, ensuring safe operation in high-risk environments.
Emerson 5X00419G02- EXT – With an extended temperature range and enhanced environmental tolerance, it is suitable for outdoor applications or extreme conditions where standard modules may not function properly.
Emerson 5X00419G02- PRO – Provides advanced features such as advanced diagnostic capabilities, faster data transfer rates, and enhanced integration with cloud systems to meet industry demands for high performance and connectivity.
Emerson 5X00419G02- RF – integrates wireless communication capabilities, suitable for applications where wired connections are impractical, such as large industrial factories with complex layouts or mobile devices in industrial environments.
5X00419G02
Installation and maintenance:
Before installing Emerson 5X00419G02, a thorough compatibility check must be conducted on the existing control system. Verify voltage requirements, communication settings, and the type of device you intend to connect to ensure seamless integration. Ensure that there is sufficient space in the industrial cabinet to accommodate the module. At the same time, verify the firmware version with Emerson’s latest version to obtain the most stable features and safety enhancements, in order to further optimize the performance of the module.
For continuous maintenance, the status of the module should be monitored regularly through the diagnostic tools of the control system. Check for signs of abnormal communication signals, network errors, or component degradation. Check for signs of wear or corrosion on the connections, as these can affect the performance of the module. Regular functional testing (such as quarterly or annual) helps maintain optimal module performance and detect potential issues early, ensuring the long-term reliability of industrial automation systems.
