Emerson 5X00226G02 rack mounted I/O interface module

Description

Emerson 5X00226G02 is a rack mounted I/O interface module that plays a central role in the automation ecosystem. It is designed for seamless integration with Emerson Ovation Distributed Control System (DCS) and is also compatible with other related control platforms. This module provides impressive 32 digital inputs and 32 digital outputs, providing ample capacity for connecting multiple field devices. It supports multiple I/O types, including analog, digital, and discrete types, suitable for various applications.

5X00226G02

This module is equipped with built-in connectors, which not only simplifies the installation process but also eliminates the need for complex power and communication wiring. This reduces the risk of wiring errors and accelerates deployment time. It also supports industry standard communication protocols such as Modbus and HART, enabling efficient data transmission and remote device management. The design incorporates redundant functions to ensure that the system can continue to operate uninterrupted in the event of component failure. This significantly improves the overall reliability of industrial automation settings.

5X00226G02

Technical specifications:
Model 5X00226G02
Brand Emerson
Type I/O interface module
Input voltage 24 VDC
Working temperature range: 40 ° C to 70 ° C
Installation method: Rack installation
Size 12.7 cm x 6.2 cm x 16.2 cm
Weight 280 grams
The interface/bus supports Modbus and HART communication protocols
Compliance with relevant industrial standards
Supports protocols Modbus and HART

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

5X00226G02

Main features and advantages:
Its modular and plug and play design aims to achieve long-term process reliability. By using a single point DIN rail fixing system, modules can be quickly and easily installed and configured, reducing installation time and lowering engineering costs. The built-in electronic identification function can automatically identify module types, groups, serial numbers, and versions, simplifying maintenance and inventory management.

Due to the limited number of module styles that need to be managed, the inventory cost of spare parts has significantly decreased. Redundant power supplies ensure system reliability and can operate normally even in the event of power fluctuations. The ‘hot plug’ function allows for system maintenance without shutting down the entire system, further reducing downtime. Standardized status indicator lights provide color coded diagnostic information, allowing operators to easily and quickly identify and resolve any issues.

5X00226G02

Application areas:
In the power generation industry, it is used to interface with sensors and actuators in power plants, monitor and control parameters such as voltage, current, and temperature, which helps ensure stable power generation and grid stability.
In the chemical industry, it achieves precise control of chemical processes by connecting control systems with various process sensors and valves.
In the field of water treatment, this module is used to manage the operation of pumps, valves, and other equipment to ensure efficient water treatment.

5X00226G02

Related products:
Emerson 5X00227G03- With increased I/O capacity and enhanced processing capabilities, it is suitable for more complex industrial applications.
Emerson 5X00225G01- with basic I/O functionality, suitable for low demand automation settings.
Emerson 5X00226G02- HAZ – Designed for use in hazardous environments, such as areas with explosive gases or flammable substances.
Emerson 5X00226G02- EXT – with an extended temperature range, suitable for outdoor applications or extreme cold conditions.
Emerson 5X00226G02- PRO – Provides advanced features such as advanced diagnostic capabilities and faster data transfer rates.
Emerson 5X00226G02- RF – Integrated wireless communication function, suitable for applications where wired connections are impractical.

Installation and maintenance:
Before installing Emerson 5X00226G02, it is essential to verify its compatibility with the existing control system. Check communication settings, voltage requirements, and I/O type compatibility with the on-site devices you plan to connect to. Ensure that the rack installation space is available and properly prepared. In addition, check if the firmware version is consistent with Emerson’s latest version to access the most stable features and security enhancements.

For continuous maintenance, the status of the module should be monitored regularly through color coded indicator lights. Check for signs of abnormal signal readings or communication errors. Check for signs of wear or corrosion on the connector, as these can affect signal quality. Regular (e.g. once a year) functional testing helps maintain optimal performance of the module and detect potential issues early.
