Emerson 5X00106G02 is a high-performance analog input module that plays a critical role in the automation stack. It can smoothly interface with Emerson Ovation control system and other compatible control platforms. This module has 16 analog input channels compatible with HART and can communicate bidirectionally with intelligent field devices. Its wide input range, from -40 mA to+40 mA, makes it suitable for a variety of applications. Its high accuracy, within ± 0.1% of full scale, ensures the high precision of the processed data.
EMERSON 5X00106G02
This module is designed for rack installation, simplifying the installation process inside industrial cabinets. The module supports the HART (High Availability Real Time) communication protocol, which enables efficient data transmission and remote device management. This not only enhances the overall functionality of the module, but also improves the integration process with existing industrial networks.
EMERSON 5X00106G02
Technical specifications:
Model 5X00106G02
Brand Emerson
Type: High performance analog input module
Input voltage 24 VDC
Working temperature range: 40 ° C to+70 ° C
Installation method: Rack installation
Size 12.1cm x 5.1cm x 15.2cm
Weight 0.3 kilograms
Interface/bus compatible with HART for communication
Compliance with relevant industrial standards
Support protocol HART
Typical power consumption of 20 W
Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
EMERSON 5X00106G02
Main features and advantages:
It adopts high-quality components and strict manufacturing process design to ensure high reliability, ensuring stable operation even in harsh industrial environments such as extreme temperature, high humidity, or electromagnetic interference. This reduces component failures and related downtime, resulting in significant cost savings over time.
The user-friendly integration function of this module reduces engineering costs. Due to seamless compatibility with Emerson Ovation systems and other compatible platforms, installation and configuration are simple and straightforward, allowing your team to quickly deploy modules and focus on optimizing operations. The built-in HART communication function supports remote device management, making maintenance more efficient. In many cases, operators can access diagnostic information and make configuration changes without on-site visits.
EMERSON 5X00106G02
Application areas:
In the power generation industry, it is used to monitor and control various parameters in power plants, such as voltage, current, and temperature, to ensure grid stability and efficient power generation.
In the water and wastewater treatment industry, this module accurately measures variables such as flow rate, chemical concentration, and pH value, achieving precise control over the treatment process.
In the oil and gas industry, it plays a critical role in monitoring pipeline pressure, flow rate, and fluid composition, helping to operate safely and efficiently.
EMERSON 5X00106G02
Related products:
Emerson 5X00107G03- With more input channels and enhanced processing capabilities, it is suitable for more complex applications.
Emerson 5X00105G01- with basic analog input functionality, suitable for applications with low requirements.
Emerson 5X00106G02- HAZ – Designed for use in hazardous environments, such as areas with explosive gases or flammable substances.
Emerson 5X00106G02- EXT – with an extended temperature range, suitable for outdoor applications or extreme cold conditions.
Emerson 5X00106G02- PRO – Provides advanced features such as advanced diagnostic capabilities and faster data transfer rates.
Emerson 5X00106G02- RF – Integrated wireless communication function, suitable for applications where wired connections are impractical.
EMERSON 5X00106G02
Installation and maintenance:
Before installing Emerson 5X00106G02, it is essential to verify its compatibility with the existing control system. Check the HART communication settings and ensure that the voltage level and input range are compatible with the field device you intend to connect to. Ensure that the rack installation space is available and configured correctly. In addition, check if the firmware version is consistent with Emerson’s latest version to access the most stable features and security enhancements.
For continuous maintenance, the performance of the module should be monitored regularly through HART enabled diagnostic tools. Check for signs of abnormal signal readings or communication errors. Check for signs of wear or corrosion on the physical connections, as these can affect signal quality. Regular (e.g. once a year) calibration checks can help maintain high precision of the module in the long term.
EMERSON 5X00106G02
