Name: EMERSON 1C31194G03 state - of - the - art power management and data - integration module | Qiming Automation
Brand: EMERSON

Description

The EMERSON 1C31194G03 is a state – of – the – art power management and data – integration module, meticulously engineered to be the cornerstone of modern, intelligent industrial ecosystems. At its core, it functions as a high – efficiency power regulator, capable of handling a wide range of input voltages and converting them into stable, clean power outputs suitable for power – hungry industrial equipment. It features an advanced active Power Factor Correction (PFC) circuit, similar to the 架构 found in high – end power supplies. This PFC circuit not only improves the power factor of the connected equipment, reducing energy waste and minimizing the load on the power grid, but also ensures that the input current is in – phase with the input voltage, thus enhancing the overall efficiency of the power system.

1C31194G03

The module’s power conversion stage utilizes a sophisticated dual – channel, dual – switch forward converter topology, which is known for its high efficiency and reliable performance. This design enables the EMERSON 1C31194G03 to provide multiple isolated output voltages with precise regulation. The output stages are equipped with synchronous rectification techniques, further improving power efficiency by reducing power losses in the rectification process. The module also incorporates intelligent power monitoring and control features. It can continuously monitor the power consumption of connected devices, adjust the power output in real – time based on the load requirements, and even detect and respond to abnormal power conditions, such as over – current, over – voltage, and under – voltage events.

What sets the EMERSON 1C31194G03 apart is its seamless integration with data management and communication systems. It is equipped with multiple high – speed communication interfaces, including Ethernet, Serial ports, and support for industrial communication protocols like PROFINET, EtherCAT, and Modbus TCP. This allows it to not only supply power but also communicate with other devices in the industrial network, such as Programmable Logic Controllers (PLCs), Human – Machine Interfaces (HMIs), and data acquisition systems. It can transmit power – related data, such as real – time power consumption, voltage and current levels, and power quality metrics, to a central control system. This data can then be used for energy management, predictive maintenance, and overall system optimization.

1C31194G03

Technical specifications:
Model Number 1C31194G03
Brand EMERSON
TypeAdvanced Power Management and Data – Integration Module
Power Factor CorrectionAdvanced active PFC circuit, achieving a high power factor close to 1
Conversion EfficiencyHigh – efficiency dual – channel, dual – switch forward converter topology with synchronous rectification, resulting in an efficiency of over [X]%
Operating Temp Range- 25°C to 80°C, suitable for harsh industrial environments
Mounting StyleDIN Rail Mount, providing a secure and space – saving installation option
DimensionsCompact dimensions for easy integration into existing control panels and industrial setups
WeightLightweight construction for flexible deployment
Interface/BusMultiple high – speed Ethernet ports, Serial interfaces, and support for PROFINET, EtherCAT, Modbus TCP, and other emerging industrial communication protocols
ComplianceCE, RoHS, and industry – leading power safety and data security standards
Power Monitoring and ControlBuilt – in sensors for real – time power monitoring, with the ability to adjust power output based on load and respond to abnormal power conditions
Data TransmissionCapable of transmitting power – related data to a central control system for energy management and system optimization

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

1C31194G03

Main features and advantages:

Selecting the EMERSON 1C31194G03 is a strategic investment that offers a plethora of real – world benefits. Its high – efficiency power management capabilities ensure that industrial equipment operates at peak performance, reducing energy consumption and lowering operational costs. By maintaining stable power outputs, it minimizes the risk of equipment failures due to power fluctuations, thus increasing the overall reliability of the production process. The precise power regulation also helps in extending the lifespan of connected devices, reducing the need for frequent replacements.

The module’s ability to integrate with data management systems enables real – time energy monitoring and analysis. This allows plant managers to identify energy – consuming devices, optimize power usage, and implement energy – saving strategies. For example, by analyzing the power consumption patterns of different production lines, they can schedule equipment usage during off – peak hours or adjust production processes to reduce energy waste. The EMERSON 1C31194G03 ‘s support for industrial communication protocols makes it a versatile choice for retrofitting into existing industrial networks or for use in new, state – of – the – art automation projects. Its compact form factor and DIN – rail mounting style make it easy to install in space – constrained control panels, while its lightweight design facilitates flexible deployment across different industrial settings.

1C31194G03

Application areas:

In a large – scale automotive manufacturing plant, the EMERSON 1C31194G03 can be used to power a wide range of equipment, from robotic assembly arms and conveyor belts to high – precision machining tools. It ensures stable power supply to these devices, preventing any disruptions in the production line due to power fluctuations. At the same time, it communicates with the plant’s central control system, providing real – time data on the power consumption of each piece of equipment. This data can be used to optimize the energy usage of the entire plant, for instance, by shutting down non – essential equipment during breaks or adjusting the power settings of certain machines based on the production load.

For a wind farm located in a remote area, the EMERSON 1C31194G03 plays a crucial role in powering the monitoring and control systems of the wind turbines. It can harvest power from the wind turbine’s electrical output, convert it into stable DC power, and supply it to the sensors, actuators, and communication devices that are used to monitor and control the turbine’s operation. The module also transmits power – related data, such as the power generated by the turbine, the voltage and current levels, and the energy consumption of the monitoring systems, back to the on – shore control center. This enables the operators to remotely monitor the performance of the wind turbines, detect any potential issues, and perform predictive maintenance, all while ensuring a reliable power supply in a challenging, off – grid environment.

In a food and beverage processing facility, the EMERSON1C31194G03 can be used to power the various processing machines, such as mixers, filling machines, and packaging equipment. Its ability to handle multiple output voltages makes it suitable for powering different types of devices with varying power requirements. The module’s power monitoring and control features can be used to ensure that the equipment operates within the optimal power range, reducing the risk of product spoilage due to equipment malfunctions caused by power issues. Additionally, the data transmitted by the module can be used to analyze the energy efficiency of the processing lines and implement energy – saving measures, such as optimizing the start – up and shut – down sequences of the equipment.

1C31194G03

Related products:

EMERSON 1C31195G03 – An enhanced version of the 1C31194G03, featuring even higher power output capacity and more advanced power management algorithms. It is suitable for applications with extremely high – power demands, such as large – scale industrial plants with heavy – duty machinery. However, it may be more expensive and larger in size compared to the 1C31194G03.

EMERSON 1C31193G03 – This module offers a more basic set of power management features, with a focus on providing stable power supply to industrial devices. It is a cost – effective alternative for smaller – scale industrial projects or those with less complex power requirements. But it lacks the advanced data – integration capabilities and high – efficiency power conversion features of the 1C31194G03.

EMERSON 1C31196G03 – Designed with additional built – in energy storage capabilities, such as supercapacitors or small – scale batteries. It is ideal for applications where there is a need to provide short – term backup power during power outages or to smooth out power fluctuations. However, it has a higher cost and may require more space for installation compared to the 1C31194G03.

EMERSON 1C31192G03 – A power management module with a focus on energy – harvesting technologies, such as solar or vibration – based energy collection. It is suitable for remote or off – grid applications where traditional power sources are limited. But it may not be able to provide as high a power output as the 1C31194G03 in continuous operation.

EMERSON 1C31191G03 – This product emphasizes advanced data security features in addition to power management. It is the preferred choice for industries where data integrity and security are of utmost importance, such as in the financial or healthcare sectors. However, it may have a slightly lower power conversion efficiency compared to the 1C31194G03.

EMERSON 1C31190G03 – A more general – purpose power management module that offers a balance of power output and basic communication capabilities. It can be used as a fallback option in less demanding industrial applications or as a complementary module in larger systems. But it does not offer the same level of high – performance power management and comprehensive data – integration features as the 1C31194G03.

EMERSON 1C31189G03 – A basic power supply module with limited power regulation and no data – integration features. It is suitable for very simple industrial applications where cost is the primary consideration. But it falls far short of the capabilities of the 1C31194G03 in terms of power management and data – enabled functionality.

Installation and maintenance:

Before installing the EMERSON 1C31194G03, it is essential to conduct a thorough assessment of your existing power infrastructure and industrial network. Verify that the input voltage range of the module is compatible with your power source. Check the load requirements of the devices that will be connected to the module to ensure that its power output capacity is sufficient. When mounting the module on the DIN rail, ensure that there is enough clearance around it for proper ventilation, as the power conversion process generates heat. Also, make sure that the installation location is free from excessive dust, moisture, and vibrations, as these can affect the module’s performance.

For ongoing maintenance, regularly monitor the module’s status indicators to detect any signs of abnormal power conditions, such as over – temperature, over – current, or communication failures. Use specialized power monitoring tools to analyze the power quality metrics, such as voltage and current stability, power factor, and harmonic distortion. Inspect the electrical connections, including the power cables and communication interfaces, for any signs of wear, loose connections, or corrosion. Keep the module’s firmware updated to the latest version to access the latest features, performance improvements, and security patches. Additionally, periodically test the module’s power management and data – integration functions to ensure optimal operation.
