EMERSON 1C31113G01 is an analog input module designed specifically for industrial automation systems, playing an important role in the data acquisition front-end of the entire automation architecture.
1C31113G01
It can efficiently connect various analog signal sources, such as temperature sensors, pressure sensors, flow sensors, etc., and accurately process the analog signals transmitted by these sensors. This module integrates advanced analog input circuits, high-performance analog-to-digital converters (ADCs), and fine filters internally to ensure that the input signal can remove noise interference to the greatest extent possible before being converted into a digital signal for use in the control system, ensuring the accuracy of the data. In terms of integration with the control system, EMERSON 1C31113G01 supports the RS-485 communication protocol, which enables it to seamlessly connect with various mainstream PLC and DCS control systems, smoothly transmit collected and processed data to the upper computer, and achieve precise control of the entire industrial process.
1C31113G01
Technical specifications:
Model Number 1C31113G01
Brand Emerson
Type Analog Input Module
Input Voltage 220 DC/AC
Operating Temp Range -5°C to +95°C
Communication Interface RS – 485
Input Range ±20mV
Resolution 13 – bit
Dimensions 4.8″ x 2.0″ x 5.5″
Compliance Not specified
Supported Protocols RS – 485
Typical Power Draw Not specified
contact us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
1C31113G01
Main features and advantages:
Its 13 bit resolution enables extremely high accuracy in the acquisition and conversion of weak analog signals, which is crucial for industrial processes that require precise measurement and control, such as dose control in pharmaceuticals and parameter adjustment in chemical reactions, ensuring the stability of the production process and consistency of product quality. The module design is sturdy and durable, and can adapt to harsh industrial environments such as high temperature, high humidity, and strong electromagnetic interference. It has overcurrent and overvoltage protection functions, greatly enhancing its reliability, reducing the occurrence rate of failures caused by environmental factors, and lowering maintenance costs and system downtime. Meanwhile, it is easy to integrate with existing automation systems, reducing the complexity and time cost of engineering implementation.
1C31113G01
Application areas:
In the field of energy management, especially in the power, oil, and natural gas industries, it is used to collect and monitor the operating parameters of various energy equipment, such as oil temperature monitoring of power transformers and pressure monitoring of oil pipelines, providing data support for efficient and stable energy supply.
In the environmental monitoring system, this module can connect various environmental sensors to collect environmental parameter data such as temperature, humidity, and air quality, assisting environmental protection departments or enterprises in real-time monitoring and analysis of environmental conditions.
In industrial automation production lines, it is indispensable for real-time collection of various analog signals during the production process, providing key data for optimizing the production process and fault diagnosis, improving production efficiency and product qualification rate.
1C31113G01
Related products:
EMERSON 1C31110G01- Digital input card, suitable for scenarios that require processing digital signal inputs.
EMERSON 1C31110G02- Differential SOE/Digital Input Module performs well in systems with high requirements for event sequence recording.
EMERSON 1C31110G03- Contact input module, which can be used to detect simple digital signal inputs such as device contact status.
EMERSON 1C31107G02- Digital input module, providing solutions for general digital signal acquisition needs.
EMERSON 5X00875G01- Process Control Module, focusing on overall control and management of industrial processes.
Installation and maintenance:
Before installing EMERSON 1C31113G01, it is necessary to first confirm whether the temperature of the installation environment is within the working temperature range of -5 ° C to+95 ° C, in order to avoid affecting module performance due to temperature discomfort. Check if the input voltage connected is 220 DC/AC to ensure voltage matching. At the same time, it is necessary to check the RS-485 communication line to ensure that the connection is correct and there are no short circuits, open circuits, or other issues, in order to ensure normal communication between the module and the control system.
In daily maintenance, the appearance of the module should be regularly inspected for any physical damage or signs of overheating. The data collected by the module can be regularly compared and verified through the control system software to confirm the accuracy of the data. Additionally, clean the RS-485 communication interface periodically to prevent dust and other impurities from affecting communication quality.
