The ECPE84-1B functions as a switched-mode power supply, converting incoming AC voltage into stable DC power tailored to the needs of industrial equipment. Its core design focuses on efficiency, minimizing energy loss as heat and reducing the load on facility cooling systems. What sets the ECPE84-1B apart is its ability to maintain output stability even when input voltage fluctuates—common in facilities with heavy machinery that causes electrical grid variations.
Model Number ECPE84-1B
Type Industrial Switched-Mode Power Supply
Input Voltage 100-240V AC (50/60Hz)
Output Voltage 24V DC
Output Current 10A
Operating Temp Range -25°C to 70°C (-13°F to 158°F)
Mounting Style DIN rail (35mm)
Dimensions 120mm x 60mm x 100mm (LxWxH)
Weight 450g
Efficiency Up to 92% at full load
Protection Features Overvoltage, overload, short-circuit, overtemperature
Compliance CE, UL 508, RoHS, IP20
Typical Power Loss <8W at full load
The ECPE84-1B functions as a switched-mode power supply, converting incoming AC voltage into stable DC power tailored to the needs of industrial equipment. Its core design focuses on efficiency, minimizing energy loss as heat and reducing the load on facility cooling systems. What sets the ECPE84-1B apart is its ability to maintain output stability even when input voltage fluctuates—common in facilities with heavy machinery that causes electrical grid variations.
ECPE84-1B
This power supply integrates seamlessly into automation architectures, with a compact form factor that fits easily into standard control cabinets alongside other components. It communicates with monitoring systems via a built-in diagnostic interface, providing real-time data on input voltage, output current, and internal temperature—allowing engineers to proactively address issues before they affect connected devices. The ECPE84-1B also includes a suite of protection mechanisms: overvoltage protection shields downstream equipment from voltage spikes, overload protection prevents damage during current surges, and short-circuit protection shuts down safely in the event of a wiring fault, with automatic recovery once the issue is resolved.
ECPE84-1B
Technical specifications:
Model Number ECPE84-1B
Type Industrial Switched-Mode Power Supply
Input Voltage 100-240V AC (50/60Hz)
Output Voltage 24V DC
Output Current 10A
Operating Temp Range -25°C to 70°C (-13°F to 158°F)
Mounting Style DIN rail (35mm)
Dimensions 120mm x 60mm x 100mm (LxWxH)
Weight 450g
Efficiency Up to 92% at full load
Protection Features Overvoltage, overload, short-circuit, overtemperature
Compliance CE, UL 508, RoHS, IP20
Typical Power Loss <8W at full load
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
ECPE84-1B
Main features and advantages:
The ECPE84-1B delivers tangible value through its ability to enhance system reliability while reducing operational costs. Its high efficiency translates to lower energy bills over the module’s lifespan, a significant advantage in facilities with dozens of power supplies running 24/7. For maintenance teams, the ECPE84-1B simplifies troubleshooting: its diagnostic interface provides clear alerts for issues like input voltage irregularities or overheating, eliminating the guesswork from power-related problems.
In terms of equipment protection, the ECPE84-1Bacts as a safeguard for expensive automation components. By regulating voltage and current precisely, it prevents damage from electrical anomalies that could fry PLC circuits or disable sensors—saving companies from costly replacements and unplanned downtime. Over time, this combination of efficiency, reliability, and protective features creates a more stable, cost-effective automation environment.
ECPE84-1B
Application areas:
The ECPE84-1Bexcels in applications where power consistency directly impacts productivity and safety. In automotive manufacturing, it supplies steady power to robotic control systems and vision sensors, ensuring that assembly processes aren’t disrupted by voltage dips that could cause robotic arms to misalign. Its rugged design withstands the mechanical vibration and electrical noise common on factory floors.
In water and wastewater treatment plants, theECPE84-1B powers SCADA system components and valve actuators, operating reliably in the humid, chemically exposed environments of treatment facilities. Its wide operating temperature range ensures performance in both unheated outdoor cabinets and temperature-fluctuating indoor enclosures.
In pharmaceutical production, the ECPE84-1B provides clean, stable power to precision dosing pumps and environmental monitoring sensors, where even minor power fluctuations could affect batch quality or regulatory compliance. Its low electromagnetic interference (EMI) ensures it doesn’t disrupt sensitive measurement equipment.
Related products:
ECPE84-2B – Higher output current (20A) for powering larger arrays of devices
ECPE84-1C – 12V DC output variant for systems requiring lower voltage power
ECPE84-1B-R – Redundant version with dual inputs for mission-critical applications
ECPE84-1B-EX – Explosion-proof model certified for hazardous areas (ATEX Zone 2)
ECPE84-1B-W – Weatherproof enclosure version for outdoor installations
ECPE-MON-001 – Power monitoring module that pairs with the ECPE84-1B for centralized oversight
ECPE-CAB-005 – Heavy-duty input/output cable set with strain relief for industrial environments
Installation and maintenance:
Before installing the ECPE84-1B, verify that the input voltage matches the facility’s supply (100-240V AC) and that the circuit is protected by an appropriate fuse or circuit breaker (16A recommended). Ensure the mounting location allows for adequate airflow—maintain at least 50mm of clearance above and below the module to prevent heat buildup, which can reduce efficiency over time. Check that the output wiring is sized correctly for the connected load (minimum 14AWG for 10A) to avoid voltage drop in longer cable runs.
For ongoing maintenance, the ECPE84-1B simplifies monitoring through its status LED: green indicates normal operation, red signals a fault (overload, short circuit, etc.), and amber warns of overtemperature. Monthly inspections should include checking input and output connections for tightness—vibration can loosen terminals, leading to increased resistance and heat. Every six months, clean dust from the module’s vents using compressed air, especially in dusty environments like cement plants or mining facilities. The ECPE84-1B’s self-protection features eliminate the need for frequent testing, but annual verification with a multimeter ensures output voltage remains within the 24V ±0.5V range.
