Name: Eaton XVS-440-10MPI-1-1AD 10-inch Secure Touchscreen HMI | Qiming Automation
Brand: EATON

Description

The Eaton XVS-440-10MPI-1-1AD functions as a central hub for communication between operators and industrial automation systems. It connects to programmable logic controllers (PLCs), sensors, actuators, and other devices through a variety of communication protocols, including Modbus, Ethernet/IP, and Profibus. Once connected, it collects real-time data from these sources, processes it, and presents it in an intuitive and visually appealing format on its 10-inch touchscreen display.

XVS-440-10MPI-1-1AD

This HMI integrates seamlessly into the automation stack, acting as a gateway between the field-level devices and higher-level control systems. It can display critical information such as equipment status, process variables, alarms, and trends, allowing operators to make informed decisions in real-time. For example, in a chemical plant, the Eaton XVS-440-10MPI-1-1AD can show the temperature, pressure, and flow rates of various chemical processes, and operators can use the touchscreen to adjust valves, start or stop pumps, and trigger safety procedures.

One of the key features of the Eaton XVS-440-10MPI-1-1AD is its advanced security capabilities. It supports user authentication and authorization, ensuring that only authorized personnel can access and control the system. It also incorporates encryption technologies to protect data transmission from interception and tampering. Additionally, its modular design allows for easy customization of screens, functions, and communication settings, making it adaptable to different industrial applications and requirements. Whether used in a new automation project or as an upgrade to an existing system, this HMI enhances the overall functionality, security, and efficiency of the industrial automation environment.

XVS-440-10MPI-1-1AD

Technical specifications:
Model NumberXVS-440-10MPI-1-1AD
Brand Eaton
Type10-inch Secure Touchscreen HMI
Display10.1-inch TFT LCD, 1024 x 600 resolution, LED backlight
Touch TechnologyProjected capacitive touch, multi-touch support
Operating Temp Range-10°C to 55°C
Mounting StylePanel-mount (flush or surface)
Dimensions285mm x 190mm x 55mm (W x H x D)
WeightApproximately 1.3kg
Interface/Bus2 x Ethernet ports, 2 x USB ports, RS485
ComplianceCE, UL 61010, RoHS
Supported ProtocolsModbus RTU, Modbus TCP/IP, Ethernet/IP, Profibus DP
Typical Power Draw18W
Storage Capacity8GB internal flash, expandable via microSD card
Operating SystemEmbedded Linux with enhanced security features
Security FeaturesUser authentication, authorization, data encryption

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

XVS-440-10MPI-1-1AD

Main features and advantages:

Engineered for reliability and security, the Eaton XVS-440-10MPI-1-1AD offers numerous real-world benefits. Its robust construction and wide operating temperature range make it suitable for use in harsh industrial environments, ensuring continuous operation without interruptions. The high-resolution touchscreen provides a clear and intuitive user interface, reducing the learning curve for operators and minimizing the risk of human error.

The advanced security features of the Eaton XVS-440-10MPI-1-1AD are particularly valuable in today’s connected industrial landscape. By implementing strict access control and data encryption, it protects industrial systems from unauthorized access, cyberattacks, and data breaches, safeguarding critical infrastructure and sensitive information. This not only helps companies comply with regulatory requirements but also gives them peace of mind knowing that their operations are secure.

In terms of operational efficiency, the HMI’s customizable dashboards and real-time data visualization capabilities enable operators to quickly identify issues, optimize processes, and make informed decisions. Its compatibility with remote monitoring and management systems allows supervisors to access system data from anywhere, facilitating remote troubleshooting and maintenance. These features combined result in reduced downtime, improved productivity, and lower operational costs.

XVS-440-10MPI-1-1AD

Application areas:

The Eaton XVS-440-10MPI-1-1AD is well-suited for a wide range of industrial applications. In power plants, it is used to monitor and control generators, transformers, switchgear, and other electrical equipment. Operators can use the HMI to view real-time electrical parameters, such as voltage, current, and power factor, and adjust settings to optimize power generation and distribution. Its security features are crucial in protecting the power grid from cyber threats.

In the automotive manufacturing industry, this HMI plays a vital role in monitoring and controlling robotic assembly lines, painting systems, and quality control processes. It provides operators with real-time information on production status, equipment performance, and quality metrics, allowing them to make adjustments on the fly to ensure product quality and production efficiency.

Water treatment plants also benefit from the Eaton XVS-440-10MPI-1-1AD. It is used to monitor and control water treatment processes, including filtration, disinfection, and pumping systems. Operators can use the HMI to adjust process parameters, monitor water quality, and receive alerts in case of any abnormalities, ensuring the delivery of clean and safe water.

XVS-440-10MPI-1-1AD

Related products:

Eaton XVS-440-10MPI-1-2AD – An upgraded version with increased storage capacity and enhanced processing power for more complex applications.

Eaton XVS-450-12MPI-1-1AD – A 12-inch display model for applications that require a larger screen for better data visualization.

Eaton XVS-430-07MPI-1-1AD – A compact 7-inch HMI, ideal for space-constrained control panels or small-scale automation projects.

Eaton EasyE4 HMI – An entry-level HMI option, suitable for basic monitoring and control tasks in less demanding environments.

Eaton XVS-440-10MPI-1-3AD – A variant with additional communication interfaces for greater connectivity options.

Eaton XVS-440-10MPI-2-1AD – A model with enhanced cybersecurity features, designed for highly secure industrial environments.

Installation and maintenance:

Before installing the Eaton XVS-440-10MPI-1-1AD, it is essential to verify the compatibility of the communication protocols of the connected devices with the HMI. Ensure that the power supply voltage matches the requirements of the HMI and that the mounting location has adequate ventilation to prevent overheating. During the setup process, configure the user authentication and authorization settings to establish secure access to the system. Calibrate the touchscreen to ensure accurate touch responses, especially for multi-touch operations.

For ongoing maintenance, regularly clean the touchscreen with a soft, lint-free cloth to remove dust, fingerprints, and other contaminants. Check the cable connections periodically to ensure they are secure and free from damage, as loose or damaged connections can cause data transmission issues. Update the HMI’s firmware regularly to benefit from the latest features, security patches, and performance improvements. It is also advisable to back up the system configuration and data regularly to a secure external storage device to prevent data loss in case of system failures or emergencies.
