The EATON XV-442-57CQB-1-10 functions as a core interface between operators and industrial systems, connecting to PLCs, sensors, drives, and other automation equipment via supported communication protocols. It collects real-time data from these devices, processes it, and displays key information on its high-quality screen, allowing operators to monitor system performance at a glance.
Model NumberXV-442-57CQB-1-10
Brand EATON
TypeAdvanced Touchscreen HMI
Display12.1-inch TFT LCD, 1280×800 resolution, high-brightness LED backlight
Touch TechnologyResistive touch, suitable for operation with gloves
Operating Temp Range-10°C to 60°C
Mounting StylePanel-mount (flush)
Dimensions320mm x 240mm x 60mm (W x H x D)
WeightApproximately 1.5kg
Interface/Bus2 x Ethernet ports, 2 x USB ports, RS232/RS485
ComplianceCE, UL 60950-1, RoHS
Supported ProtocolsModbus RTU, Modbus TCP/IP, Ethernet/IP
Typical Power Draw20W
Storage Capacity8GB internal flash, expandable via SD card
Operating SystemEmbedded Linux with real-time kernel
The EATON XV-442-57CQB-1-10 functions as a core interface between operators and industrial systems, connecting to PLCs, sensors, drives, and other automation equipment via supported communication protocols. It collects real-time data from these devices, processes it, and displays key information on its high-quality screen, allowing operators to monitor system performance at a glance.
XV-442-57CQB-1-10
This HMI integrates seamlessly into the automation architecture, positioned between field devices and upper-level control systems. It translates raw data into actionable insights, such as graphical representations of production flows or alert notifications for abnormal conditions. For example, in a warehouse automation system, the EATON XV-442-57CQB-1-10 can display the status of each conveyor segment, inventory levels, and robot movement paths, enabling operators to intervene promptly if a jam or delay occurs.
Equipped with versatile communication capabilities, it supports protocols like Modbus and Ethernet/IP, ensuring compatibility with both EATON and third-party automation components. Its modular design allows for easy customization of screens and control logic, adapting to specific operational needs. Whether deployed in a new system or as an upgrade, this HMI enhances the connectivity and controllability of industrial processes.
XV-442-57CQB-1-10
Technical specifications:
Model NumberXV-442-57CQB-1-10
Brand EATON
TypeAdvanced Touchscreen HMI
Display12.1-inch TFT LCD, 1280×800 resolution, high-brightness LED backlight
Touch TechnologyResistive touch, suitable for operation with gloves
Operating Temp Range-10°C to 60°C
Mounting StylePanel-mount (flush)
Dimensions320mm x 240mm x 60mm (W x H x D)
WeightApproximately 1.5kg
Interface/Bus2 x Ethernet ports, 2 x USB ports, RS232/RS485
ComplianceCE, UL 60950-1, RoHS
Supported ProtocolsModbus RTU, Modbus TCP/IP, Ethernet/IP
Typical Power Draw20W
Storage Capacity8GB internal flash, expandable via SD card
Operating SystemEmbedded Linux with real-time kernel
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
XV-442-57CQB-1-10
Main features and advantages:
Engineered for durability, the EATON XV-442-57CQB-1-10 delivers reliable performance in harsh industrial conditions. Its rugged design withstands extreme temperatures, vibrations, and dust, ensuring uninterrupted operation even in demanding environments like foundries or outdoor manufacturing facilities. The high-brightness display remains visible in both low-light and direct sunlight, while the resistive touchscreen maintains responsiveness despite frequent use or exposure to contaminants.
The intuitive interface of the EATON XV-442-57CQB-1-10 reduces operator training time significantly. Customizable dashboards allow users to prioritize critical data, enabling quick decision-making. For instance, in a automotive assembly line, operators can configure the HMI to display real-time error codes and corresponding troubleshooting guides, minimizing downtime.
Its advanced data logging capabilities enable historical analysis, helping identify trends and optimize processes over time. Additionally, the HMI’s compatibility with remote monitoring systems allows supervisors to access real-time data from off-site, facilitating timely interventions and improving overall operational efficiency. These benefits translate to lower operational costs and enhanced productivity.
XV-442-57CQB-1-10
Application areas:
The EATON XV-442-57CQB-1-10 is widely used in logistics centers, where it monitors and controls conveyor systems, automated storage and retrieval machines (AS/RS), and sorting equipment. Operators can track package flow, adjust conveyor speeds, and resolve jams quickly, ensuring efficient order fulfillment.
In the food processing industry, this HMI plays a key role in monitoring temperature-controlled zones, mixing equipment, and packaging lines. Its ability to operate in harsh, washdown environments (with appropriate protection) ensures compliance with hygiene standards while providing real-time data on process parameters.
Heavy machinery manufacturing facilities also rely on the EATON XV-442-57CQB-1-10 to oversee assembly processes, including robotic welding stations and material handling robots. It provides operators with detailed insights into equipment performance, enabling proactive maintenance and reducing unplanned downtime.
XV-442-57CQB-1-10
Related products:
EATON XV-442-57CQB-1-20 – Higher storage variant with 16GB internal flash for extensive data logging.
EATON XV-452-65CQB-1-10 – 15-inch display model for applications requiring larger visual data representation.
EATON XV-432-43CQB-1-10 – Compact 7-inch HMI ideal for space-constrained control panels.
EATON EasyE4 200 – Entry-level HMI for small-scale automation with basic monitoring needs.
Siemens SIMATIC HMI TP1200 Comfort – Competitor HMI with similar features, suitable for mixed-vendor systems.
EATON XV-442-57CQB-2-10 – Variant with enhanced security features for sensitive industrial applications.
EATON XV-442-57CQB-1-05 – Lower power consumption model for energy-efficient installations.
Installation and maintenance:
Before installing the EATON XV-442-57CQB-1-10, verify that the communication protocols of connected devices (PLCs, sensors) are compatible with the HMI’s supported protocols. Check the mounting cutout dimensions to ensure a proper fit, and ensure the installation location has adequate ventilation to prevent overheating. Calibrate the touchscreen during setup to ensure accurate input, especially when using gloves.
For ongoing maintenance, clean the display regularly with a soft, dry cloth to remove dust and debris. Inspect cable connections quarterly to ensure they are secure, as loose connections can cause data transmission issues. Update the HMI’s firmware periodically using EATON’s software tools to access new features and security updates. Back up configuration files to an external storage device to facilitate quick recovery in case of system errors.
