Name: EATON XV-440-10TVB-1-20 10-inch Touchscreen Human-Machine Interface | Qiming Automation
Brand: EATON

Description

The EATON XV-440-10TVB-1-20 serves as the nerve center of industrial control systems, seamlessly integrating with a wide range of devices including programmable logic controllers (PLCs), sensors, and actuators. It utilizes standard communication protocols to collect real-time data from these components, which is then processed and presented on its high-resolution 10-inch touchscreen display.

XV-440-10TVB-1-20

Positioned at the interface between the physical machinery and the control layer, this HMI acts as a translator, converting raw data into actionable insights for operators. Its modular software architecture allows for extensive customization, enabling users to create tailored dashboards, set up alarms, and configure control interfaces according to their specific operational requirements. For instance, in a chemical processing plant, the EATON XV-440-10TVB-1-20 can display real-time chemical concentrations, flow rates, and safety parameters, and operators can use the touchscreen to adjust valves, start or stop pumps, and initiate emergency shutdown procedures.

With support for multiple communication protocols such as Modbus RTU, Modbus TCP/IP, Ethernet/IP, and Profibus DP, the EATON XV-440-10TVB-1-20 ensures compatibility with both EATON’s own automation products and third-party systems, facilitating seamless integration into existing industrial networks. Whether deployed in a new automation project or as an upgrade to an existing system, this HMI enhances the overall functionality and efficiency of the control ecosystem.

XV-440-10TVB-1-20

Technical specifications:
Model NumberXV-440-10TVB-1-20
Brand EATON
Type10-inch Touchscreen Human-Machine Interface
Display10.1-inch TFT LCD, 1024×600 resolution, LED backlight
Touch TechnologyProjected capacitive touch, multi-touch support
Operating Temp Range0°C to 50°C
Mounting StylePanel-mount (flush or surface mounting options)
Dimensions285mm x 190mm x 55mm (W x H x D)
WeightApproximately 1.2kg
Interface/BusEthernet (2 ports), USB (2 ports), RS485
ComplianceCE, UL 508, RoHS
Supported ProtocolsModbus RTU, Modbus TCP/IP, Ethernet/IP, Profibus DP
Typical Power Draw15W
Storage Capacity4GB internal flash memory, expandable via microSD card
Operating SystemEmbedded Linux for stable and efficient performance

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

XV-440-10TVB-1-20

Main features and advantages:

Engineered for industrial resilience, the EATON XV-440-10TVB-1-20 offers exceptional reliability in demanding environments. Its rugged construction can withstand dust, vibrations, and temperature fluctuations commonly encountered in industrial settings, ensuring continuous operation without interruptions. The high-brightness display remains clearly visible even under bright factory lighting, while the durable touchscreen can endure frequent use, including operation with gloves, making it suitable for industries with strict hygiene or safety requirements.

The intuitive interface of the EATON XV-440-10TVB-1-20 significantly reduces the learning curve for operators, minimizing training time and errors. Its user-friendly design allows for quick navigation between screens, easy access to critical information, and seamless execution of commands. This streamlines operations, increases productivity, and reduces the risk of human error. For example, in a packaging plant, operators can effortlessly adjust packaging parameters, monitor production rates, and troubleshoot issues, ensuring consistent product quality and output.

Moreover, the HMI’s compatibility with remote monitoring and management software enables supervisors to access real-time data and control systems from anywhere, facilitating remote diagnostics, maintenance, and decision-making. This feature is particularly valuable for large-scale operations with multiple sites or for addressing urgent issues outside of regular working hours, ultimately enhancing overall operational efficiency and reducing downtime.

XV-440-10TVB-1-20

Application areas:

The EATON XV-440-10TVB-1-20 finds extensive application in automotive manufacturing, where it plays a crucial role in monitoring and controlling robotic assembly lines, paint shops, and quality control processes. Operators can use the HMI to adjust robot movements, monitor paint thickness, and analyze quality inspection results, ensuring the production of high-quality vehicles with minimal defects.

In the water and wastewater treatment industry, this HMI is utilized to monitor and manage various treatment processes, including filtration, disinfection, and sludge handling. It provides real-time data on water quality parameters, flow rates, and equipment statuses, allowing operators to optimize treatment processes, ensure regulatory compliance, and prevent environmental contamination.

Food and beverage production facilities also benefit from the EATON XV-440-10TVB-1-20. It is used to monitor and control mixing, cooking, filling, and packaging operations, ensuring product consistency, safety, and hygiene. The HMI’s washdown-resistant design makes it suitable for cleanroom environments, where strict sanitation standards are required.

Related products:

EATON XV-450-12TWB-1-20 – A larger 12-inch display variant, ideal for applications that require more screen space for comprehensive data visualization and control.

EATON XV-300-07TVB-1-20 – A compact 7-inch HMI, suitable for space-constrained control panels or for applications where a smaller form factor is preferred.

EATON XV-440-10TWB-2-20 – An enhanced model featuring a built-in camera for visual inspection integration, enabling operators to remotely view and monitor processes.

EATON EasyE4 HMI – An entry-level option for small-scale automation projects with basic monitoring and control requirements.

EATON XV-440-10TVB-1-21 – A variant with additional connectivity options or enhanced security features, catering to specific application requirements.

Installation and maintenance:

Before installing the EATON XV-440-10TVB-1-20, it is essential to verify compatibility with existing PLCs and other connected devices. Ensure that the communication protocols and firmware versions are compatible to avoid integration issues. When mounting the HMI, choose a location with adequate ventilation to prevent overheating, as prolonged exposure to high temperatures can affect its performance and lifespan. Calibrate the touchscreen during the initial setup to ensure accurate touch responses, especially if operators will be using gloves.

For ongoing maintenance, regularly clean the touchscreen with a soft, lint-free cloth and a suitable screen cleaner to remove dirt, smudges, and fingerprints. Check all cable connections periodically to ensure they are secure and free from damage, as loose or faulty connections can lead to data loss or communication issues. Update the HMI’s firmware as recommended by EATON to access the latest features, security patches, and performance improvements. Additionally, back up all custom configurations and data regularly to prevent loss in case of system failures or upgrades.
