Name: EATON MPB1-TP Busbar Plug-in Module | Qiming Automation
Brand: EATON

Description

The EATON MPB1-TP operates on the principle of a plug-in design, which simplifies installation and ensures a secure electrical connection. It features a unique contact mechanism that provides a low-resistance path for electrical current, minimizing power losses and heat generation. The module is designed to be easily plugged into busbar systems, creating a reliable connection without the need for complex tools or extensive wiring.

MPB1-TP

This module fits seamlessly into the power distribution stack, serving as a vital link between electrical components and busbars. It can be installed in switchboards, motor control centers, or other electrical enclosures where busbar systems are used. Once installed, it enables the quick and easy connection of electrical devices, such as circuit breakers, contactors, or transformers, to the busbar. The EATON MPB1-TP is compatible with a wide range of EATON products and other industry-standard busbar systems, ensuring flexibility in system design and integration. Its modular design also allows for easy expansion or modification of electrical systems as needs change, making it a future-proof solution for power distribution.

MPB1-TP

Technical specifications:
Model NumberMPB1-TP
Brand EATON
TypeBusbar Plug-in Module
Rated Current1000 A
Rated Voltage690 V AC
Short-Circuit Current Rating100 kA
Operating Temp Range-40°C to +70°C
Mounting StylePlug-in to busbar
Interface/BusCompatible with standard busbar systems
ComplianceMeets relevant IEC and UL standards
Contact ResistanceExtremely low for efficient power transfer
Material High-quality conductive materials for durability

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

MPB1-TP

Main features and advantages:

Engineered for reliability and performance, the EATON MPB1-TP offers significant real-world benefits. Its secure connection design ensures long-term performance, reducing the risk of connection failures and the associated downtime. The low contact resistance of the module minimizes power losses, contributing to energy efficiency and cost savings over the lifespan of the electrical system.

In industrial settings, the EATON MPB1-TP simplifies maintenance. The plug-in design allows for quick and easy replacement or inspection of components, reducing maintenance time and costs. This is particularly valuable in applications where downtime must be minimized, such as continuous manufacturing processes. In commercial buildings, the module’s reliability helps maintain stable power supply to critical systems, ensuring uninterrupted operations and protecting sensitive equipment. Its compatibility with a wide range of products also reduces the complexity of system design and integration, making it a versatile choice for various power distribution applications.

MPB1-TP

Application areas:

The EATON MPB1-TP is widely used in industrial manufacturing plants, where it provides reliable connections for power distribution to large machinery, production lines, and control systems. In automotive factories, for example, it ensures stable power supply to robotic assembly lines, reducing the risk of production disruptions due to electrical issues.

In data centers, the module plays a crucial role in maintaining the integrity of power distribution systems. It enables secure connections between power sources, UPS systems, and server racks, ensuring continuous power supply to critical IT equipment. The EATON MPB1-TP’s ability to handle high current loads and its reliability make it an ideal choice for these power-hungry environments.

Commercial buildings, such as shopping malls, hotels, and office complexes, also benefit from the EATON MPB1-TP. It helps distribute power efficiently to various electrical systems, including lighting, HVAC, and elevators, ensuring a comfortable and functional environment for occupants. Its ease of installation and maintenance make it a practical solution for these applications.

Related products:

EATON MPB2-TP – Higher current rating version (1600 A) for more demanding applications.

EATON MPB1-SP – Similar design with a focus on simplified installation for smaller-scale projects.

EATON MPB1-HC – High-capacity module for applications requiring enhanced short-circuit protection.
EATON MPB1-EXP – Expansion module that can be used in conjunction with MPB1-TP to increase the number of connection points.

Installation and maintenance:

Before installing the EATON MPB1-TP, it is essential to ensure that the busbar system is properly rated for the module’s current and voltage requirements. Verify that the busbar is clean and free of any debris or contaminants that could affect the connection. When plugging the module into the busbar, apply firm and even pressure to ensure a secure connection. Avoid over-tightening or applying excessive force, as this could damage the module or the busbar.

For ongoing maintenance, periodically inspect the module for any signs of wear, overheating, or loose connections. Check the contact surfaces for any discoloration or oxidation, which could indicate excessive resistance. If any issues are detected, replace the module or clean the contact surfaces as necessary. It is also recommended to perform regular electrical tests, such as insulation resistance tests and continuity tests, to ensure the module is functioning properly.
