The EABT3 B9302 997009302 operates as a dual-channel safety relay, a design that ensures fail-safety by requiring both channels to confirm a safe state before allowing machine operation. When a safety device (such as an emergency stop button or light curtain) is triggered, the module immediately breaks the control circuit to the machine’s power supply, halting operation in milliseconds—faster than human reaction time.
Model Number EABT3 B9302 997009302
Type Safety Relay Module
Input Voltage 24V DC (18-30V range)
Operating Temp Range -25°C to 70°C (-13°F to 158°F)
Mounting Style DIN rail (35mm)
Dimensions 65mm x 90mm x 60mm (LxWxH)
Weight 280g
Safety Rating PL e, Category 4 (ISO 13849-1), SIL 3 (IEC 61508)
Inputs 2 x normally closed (NC) safety device inputs
Outputs 3 x normally open (NO) safety contacts (6A @ 250V AC)
Response Time <10ms
Compliance CE, UL 508, RoHS
The EABT3 B9302 997009302 operates as a dual-channel safety relay, a design that ensures fail-safety by requiring both channels to confirm a safe state before allowing machine operation. When a safety device (such as an emergency stop button or light curtain) is triggered, the module immediately breaks the control circuit to the machine’s power supply, halting operation in milliseconds—faster than human reaction time.
EABT3 B9302 997009302
What distinguishes the EABT3 B9302 997009302 is its self-monitoring capability: it continuously checks internal components (contacts, coils, wiring) for faults, triggering a safe state if any irregularity is detected. This diagnostic feature eliminates the need for manual testing cycles, a critical advantage for maintaining compliance without disrupting production. The module integrates with standard machine control systems via its auxiliary contacts, allowing for status monitoring in HMI or SCADA systems, while its pluggable terminals simplify installation and reduce wiring errors.
EABT3 B9302 997009302
Technical specifications:
Model Number EABT3 B9302 997009302
Type Safety Relay Module
Input Voltage 24V DC (18-30V range)
Operating Temp Range -25°C to 70°C (-13°F to 158°F)
Mounting Style DIN rail (35mm)
Dimensions 65mm x 90mm x 60mm (LxWxH)
Weight 280g
Safety Rating PL e, Category 4 (ISO 13849-1), SIL 3 (IEC 61508)
Inputs 2 x normally closed (NC) safety device inputs
Outputs 3 x normally open (NO) safety contacts (6A @ 250V AC)
Response Time <10ms
Compliance CE, UL 508, RoHS
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
EABT3 B9302 997009302
Main features and advantages:
The EABT3 B9302 997009302 delivers tangible value by balancing uncompromising safety with operational efficiency. Its dual-channel design and self-monitoring features ensure compliance with global safety standards, reducing the risk of regulatory fines and liability in the event of an incident. For maintenance teams, the module’s diagnostic LEDs provide instant status updates—green for normal operation, red for fault conditions—eliminating the need for time-consuming multimeter checks during troubleshooting.
In operation, the EABT3 B9302 997009302 minimizes production disruptions caused by false triggers, a common issue with lower-quality safety relays. Its robust design resists electrical noise and voltage spikes, ensuring that transient interference from nearby motors or welders doesn’t inadvertently trigger shutdowns. Over time, this reliability translates to fewer unplanned stoppages, higher overall equipment effectiveness (OEE), and a safer workplace—where operators and maintenance staff can work with confidence around machinery.
EABT3 B9302 997009302
Application areas:
The EABT3 EABT3 B9302 997009302 excels in applications where rapid, reliable safety responses are non-negotiable. In automotive assembly plants, it’s integrated into robotic workcells, monitoring safety gates and emergency stops to protect operators from moving machinery; its fast response time ensures that even a momentary breach of the safety zone halts operation before contact occurs.
In food and beverage processing, the EABT3 B9302 997009302 safeguards workers around mixing tanks and filling lines, where rotating agitators or high-pressure nozzles present constant hazards. Its resistance to humidity and temperature fluctuations ensures consistent performance in washdown environments.
Material handling facilities rely on the EABT3 B9302 997009302 to protect personnel near conveyor systems and automated guided vehicles (AGVs), integrating with laser scanners and bumper switches to prevent collisions. In all these scenarios, the module’s compliance with strict safety standards provides peace of mind, whether undergoing third-party audits or daily operations.
EABT3 B9302 997009302
Related products:
EABT3 B9302 997009303 – Higher current rating (10A) for larger machinery with higher power demands
EABT4 B9302 997009402 – Expandable version supporting up to 8 safety inputs for complex systems
EABT3 B9302 997008302 – Timer-equipped model for controlled restart delays after safety triggers
EABT3 B9302 997009302-EX – ATEX-certified variant for hazardous environments with flammable materials
B9302-ACC-001 – Test adapter for periodic functional checks of the EABT3 B9302 997009302
B9302-CAB-005 – Pre-wired cable harness for faster, error-free installation
Installation and maintenance:
Before installing the EABT3 B9302 997009302, verify that all connected safety devices (emergency stops, light curtains) are rated for the same safety category (PL e) to avoid creating a weak link in the system. Ensure the mounting location is free from excessive vibration, which can degrade relay contacts over time, and confirm that input voltage is stable—voltage dips can cause false triggers. Check that wiring follows safety standards (separate conduit for safety circuits vs. control circuits) to prevent electromagnetic interference from disrupting signals.
For ongoing maintenance, the EABT3 B9302 997009302 simplifies compliance through its built-in test points, allowing functional checks without disconnecting wiring. Monthly, verify that the status LED remains green during normal operation; a red LED indicates a fault requiring immediate attention. Annually, perform a full functional test using the test adapter, simulating emergency stops and safety gate closures to ensure the module triggers a shutdown within the specified response time. Unlike standard relays, the EABT3 B9302 997009302 does not require contact cleaning, but inspecting terminal screws for tightness (especially after washdowns) prevents intermittent connections.
