The E2384-E4-1100 functions as a multi-channel I/O module, serving as the interface between field devices and central control systems (PLCs, DCSs, or edge controllers). Its design focuses on flexibility: it supports a mix of analog inputs (for temperature, pressure, and flow sensors), analog outputs (for controlling valves or variable speed drives), and digital I/O (for on/off devices like pumps or alarms). This versatility eliminates the need for multiple specialized modules, reducing cabinet space and simplifying wiring.
Model Number E2384-E4-1100
Type High-Density Mixed-Signal I/O Module
Input Voltage 24V DC (18-30V range)
Operating Temp Range -30°C to 70°C (-22°F to 158°F)
Mounting Style DIN rail (35mm) with locking clips
Dimensions 160mm x 100mm x 45mm (LxWxH)
Weight 420g
Interface/Bus Ethernet/IP, PROFINET, Modbus TCP/IP
I/O Configuration 16 analog inputs (4-20mA, 0-10V), 8 analog outputs (4-20mA), 16 digital I/O
Compliance IEC 61131-2, CE, UL 508, RoHS, IP20
Signal Conditioning 16-bit resolution, built-in EMI/RFI filtering
Typical Power Draw 18W
The E2384-E4-1100 functions as a multi-channel I/O module, serving as the interface between field devices and central control systems (PLCs, DCSs, or edge controllers). Its design focuses on flexibility: it supports a mix of analog inputs (for temperature, pressure, and flow sensors), analog outputs (for controlling valves or variable speed drives), and digital I/O (for on/off devices like pumps or alarms). This versatility eliminates the need for multiple specialized modules, reducing cabinet space and simplifying wiring.
E2384-E4-1100
What sets theE2384-E4-1100 apart is its advanced signal conditioning technology, which filters out electromagnetic interference (EMI) and radio frequency interference (RFI)—common in industrial environments with heavy machinery or high-voltage equipment. This ensures that even weak sensor signals are transmitted accurately to the control system. The module also features built-in diagnostic capabilities, continuously monitoring for open circuits, short circuits, or signal drift, and alerting the control system to issues before they affect process stability. Its hot-swappable design allows for replacement without shutting down the entire system, a critical advantage for applications requiring 24/7 operation.
E2384-E4-1100
Technical specifications:
Model Number E2384-E4-1100
Type High-Density Mixed-Signal I/O Module
Input Voltage 24V DC (18-30V range)
Operating Temp Range -30°C to 70°C (-22°F to 158°F)
Mounting Style DIN rail (35mm) with locking clips
Dimensions 160mm x 100mm x 45mm (LxWxH)
Weight 420g
Interface/Bus Ethernet/IP, PROFINET, Modbus TCP/IP
I/O Configuration 16 analog inputs (4-20mA, 0-10V), 8 analog outputs (4-20mA), 16 digital I/O
Compliance IEC 61131-2, CE, UL 508, RoHS, IP20
Signal Conditioning 16-bit resolution, built-in EMI/RFI filtering
Typical Power Draw 18W
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
E2384-E4-1100
Main features and advantages:
The E2384-E4-1100 delivers tangible value through its ability to simplify system design while enhancing performance. Its high-density design reduces the number of modules needed in control cabinets by up to 40% compared to lower-channel alternatives, freeing up space for future expansions and improving airflow—critical for maintaining optimal operating temperatures. For maintenance teams, this translates to faster troubleshooting: the module’s diagnostic data (available via the control system or web interface) pinpoints issues to specific channels or devices, eliminating the need for time-consuming manual testing.
In operation, the E2384-E4-1100 ensures signal integrity even in challenging conditions. Its robust filtering minimizes the impact of electrical noise, which is especially valuable in environments with motors, welders, or high-voltage equipment. This accuracy reduces false alarms and control errors, leading to more stable processes and fewer unplanned shutdowns. Over time, the module’s durability—backed by a rugged housing and wide operating temperature range—lowers replacement costs and ensures consistent performance in harsh industrial settings.
E2384-E4-1100
Application areas:
The E2384-E4-1100 excels in applications where signal diversity and density are essential. In automotive manufacturing, it manages inputs from dozens of sensors monitoring robotic arm positions, conveyor speeds, and part quality, while controlling outputs to adjust grippers and welding equipment. Its ability to handle mixed signals simplifies the integration of new sensors as production lines are reconfigured for different vehicle models.
In water and wastewater treatment, the E2384-E4-1100 monitors pH levels, turbidity, and flow rates across multiple treatment stages, using its analog outputs to adjust chemical dosing pumps and valve positions. Its diagnostic features quickly identify failed sensors, preventing process disruptions that could compromise water quality.
In renewable energy facilities, such as solar farms or wind parks, the module tracks voltage, current, and temperature across arrays of panels or turbines, sending data to edge controllers that optimize energy production. Its compact design fits easily in weatherproof enclosures, while its wide temperature range ensures reliability in outdoor environments.
E2384-E4-1100
Related products:
E2384-E4-1200 – Higher-resolution variant (24-bit) for precision applications like laboratory automation
E2384-E4-1050 – Lower-channel model (8 analog inputs, 4 outputs) for smaller systems
E2384-E8-1100 – 8-channel analog output expansion module for the E2384-E4-1100
E2384-R4-1100 – Redundant power supply version for safety-critical applications
E2384-E4-1100-W – Weatherproof enclosure model for outdoor installations
E2384-COMM-002 – Wireless adapter for connecting the E2384-E4-1100 to IoT platforms
E2384-CAL-001 – Calibration kit for periodic accuracy verification of analog channels
Installation and maintenance:
Before installing theE2384-E4-1100, verify that the power supply can deliver stable 24V DC within the 18-30V range—voltage fluctuations can affect analog signal accuracy. Ensure the mounting rail is properly grounded to maximize noise immunity, especially in high-interference environments. Check that wiring distances from field devices match the module’s specifications (up to 1000m for 4-20mA signals) to avoid signal degradation. Prior to power-up, confirm that analog input ranges are configured to match connected sensors (e.g., 0-10V for pressure transducers vs. 4-20mA for temperature probes).
For ongoing maintenance, the E2384-E4-1100 simplifies monitoring through front-panel LEDs that indicate power status, communication activity, and channel faults. Monthly inspections should include checking terminal block connections for tightness—vibration can loosen screws over time, causing intermittent signal loss. Every six months, review diagnostic logs via the control system to identify trends like increasing noise on specific channels, which may indicate aging sensors or wiring issues. Annual calibration using the optional kit ensures analog accuracy is maintained, though the module’s drift-resistant design minimizes the need for frequent adjustments.
