The E1460A functions as a managed industrial Ethernet switch, directing data traffic across automation networks with precision and speed. Its core capability lies in prioritizing critical data—such as real-time control signals from PLCs—over less time-sensitive traffic like status updates, ensuring that time-critical operations aren’t delayed by network congestion. This Quality of Service (QoS) functionality is complemented by advanced network management features, including VLAN support, which isolates different types of traffic to prevent interference between systems.
Model Number E1460A
Type Managed Industrial Ethernet Switch
Input Voltage 24V DC (12-48V range, dual redundant inputs)
Operating Temp Range -40°C to 75°C (-40°F to 167°F)
Mounting Style DIN rail (35mm) or wall mount
Dimensions 120mm x 85mm x 60mm (LxWxH)
Weight 580g
Ports 8 x 10/100/1000BASE-TX (RJ45), 2 x SFP slots for fiber
Compliance IEC 61800-5-1, CE, UL 508, ATEX Zone 2, RoHS
Network Protocols IEEE 802.3, STP/RSTP/MSTP, QoS, VLAN, IGMP Snooping
Security Features 802.1X, MAC address filtering, SSH/HTTPS encryption
Typical Power Draw 12W
The E1460A functions as a managed industrial Ethernet switch, directing data traffic across automation networks with precision and speed. Its core capability lies in prioritizing critical data—such as real-time control signals from PLCs—over less time-sensitive traffic like status updates, ensuring that time-critical operations aren’t delayed by network congestion. This Quality of Service (QoS) functionality is complemented by advanced network management features, including VLAN support, which isolates different types of traffic to prevent interference between systems.
E1460A
Positioned at the intersection of field devices and control systems, theE1460A acts as a secure gateway, supporting both legacy and modern network protocols to ensure compatibility with existing infrastructure while enabling future upgrades. What sets the E1460A apart is its redundant design: dual power inputs and support for ring topologies mean that if one connection fails, data automatically reroutes through a backup path, eliminating single points of failure. This resilience is further enhanced by built-in diagnostic tools that alert engineers to issues like cable faults or port errors before they escalate into network outages.
E1460A
Technical specifications:
Model Number E1460A
Type Managed Industrial Ethernet Switch
Input Voltage 24V DC (12-48V range, dual redundant inputs)
Operating Temp Range -40°C to 75°C (-40°F to 167°F)
Mounting Style DIN rail (35mm) or wall mount
Dimensions 120mm x 85mm x 60mm (LxWxH)
Weight 580g
Ports 8 x 10/100/1000BASE-TX (RJ45), 2 x SFP slots for fiber
Compliance IEC 61800-5-1, CE, UL 508, ATEX Zone 2, RoHS
Network Protocols IEEE 802.3, STP/RSTP/MSTP, QoS, VLAN, IGMP Snooping
Security Features 802.1X, MAC address filtering, SSH/HTTPS encryption
Typical Power Draw 12W
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
E1460A
Main features and advantages:
The E1460Adelivers tangible value by ensuring that industrial networks operate at peak efficiency, even under the most demanding conditions. Its ability to prioritize critical data reduces latency in control loops, which translates to smoother operation of machinery and faster response times to process changes—vital in applications like high-speed packaging lines or precision assembly systems. For network administrators, the E1460A simplifies management through a user-friendly web interface and support for industry-standard management protocols, reducing the need for specialized training and minimizing configuration errors.
In terms of long-term reliability, the E1460A is engineered to withstand the rigors of industrial environments. Its rugged metal housing protects against vibration, dust, and moisture, while wide operating temperature ranges ensure performance in unheated enclosures or outdoor installations. The switch’s redundant power inputs and fault-tolerant network topologies mean that even in the event of a power surge or cable damage, network traffic continues uninterrupted—saving companies from the costs of downtime, which can exceed thousands of dollars per minute in critical industries.
Application areas:
The E1460A excels in applications where network reliability directly impacts safety, productivity, or compliance. In power generation facilities, it connects turbine control systems, transformers, and substation equipment, ensuring that real-time data on voltage and current flows reaches monitoring systems without delay—critical for preventing blackouts or equipment damage. Its rugged design withstands the electrical noise and temperature fluctuations common in these environments.
In pharmaceutical manufacturing, theE1460A secures network communications between production equipment and batch management systems, using its advanced security features to protect against unauthorized access and ensure data integrity for regulatory compliance. Its ability to isolate traffic via VLANs prevents cross-contamination of data between different production lines.
In transportation systems, such as automated warehouses or airport baggage handling, the E1460A manages high-speed data flows between conveyor controls, barcode scanners, and central management systems, ensuring that goods move efficiently and on schedule. Its low-latency performance is essential for synchronizing the hundreds of devices involved in these complex operations.
Related products:
E1460A-16 – 16-port variant for larger networks requiring more device connections
E1460A-F – Full fiber-optic model with SFP ports for long-distance, EMI-resistant communication
E1450A – Entry-level managed switch with basic QoS for less demanding applications
E1460A-S – Secure hardened version with enhanced cybersecurity certifications (IEC 62443)
E1460A-R – Rail-mounted compact variant with reduced footprint for space-constrained cabinets
E1460A-POE – Power over Ethernet model for powering IP cameras and wireless access points
E1460A-XT – Extreme temperature version rated for -50°C to 85°C for arctic or desert applications
E1460A-M – Modular version allowing custom port configuration with pluggable modules
Installation and maintenance:
Before installing the E1460A, verify that the switch’s power requirements match the available supply—dual power inputs should be connected to separate circuits to maximize redundancy. Ensure the mounting location provides adequate airflow; while the E1460A is designed for high temperatures, sustained operation above 60°C may require additional cooling in densely packed cabinets. Check that network cabling meets industrial standards (Cat5e or higher for copper, single-mode/multimode fiber as needed) and that cable lengths do not exceed recommended limits to avoid signal degradation.
For ongoing maintenance, the E1460Asimplifies monitoring through its front-panel LEDs, which indicate power status, port activity, and network faults. Monthly checks should include inspecting cable connections for tightness and corrosion, especially in humid or dusty environments. Quarterly, review network performance logs via the switch’s web interface to identify bandwidth bottlenecks or unusual traffic patterns that may indicate emerging issues. Annually, update firmware to the latest version to ensure access to new security features and performance improvements—this can be done remotely via the network to avoid downtime.
