The E1043 functions as a bridge between field sensors and control/monitoring systems, converting analog and digital signals from diverse sources into actionable data. Its core strength lies in its ability to handle multiple input types simultaneously: from 4-20mA current loops and 0-10V voltage signals to digital on/off states, it consolidates data from thermocouples, pressure transducers, flow meters, and proximity sensors into a unified stream.
Model Number E1043
Type Compact Data Acquisition Module
Input Voltage 12-24V DC
Operating Temp Range -25°C to 70°C (-13°F to 158°F)
Mounting Style DIN rail (35mm) or panel mount
Dimensions 85mm x 65mm x 32mm (LxWxH)
Weight 180g
Interface/Bus RS-485 (Modbus RTU), USB (configuration)
Compliance CE, UL 61010, RoHS, IP20
Supported Input Types 8 x analog (4-20mA, 0-10V), 4 x digital (dry contact)
Outputs 2 x digital (relay, 5A @ 250V AC)
Typical Power Draw 2.8W
The E1043 functions as a bridge between field sensors and control/monitoring systems, converting analog and digital signals from diverse sources into actionable data. Its core strength lies in its ability to handle multiple input types simultaneously: from 4-20mA current loops and 0-10V voltage signals to digital on/off states, it consolidates data from thermocouples, pressure transducers, flow meters, and proximity sensors into a unified stream.
E1043
Positioned at the edge of the automation network, the E1043 communicates seamlessly with PLCs, SCADA systems, and cloud platforms via its integrated communication ports, ensuring that data flows efficiently to where it’s needed most. What distinguishes the E1043 is its edge processing capability: it can filter, scale, and timestamp data locally, reducing bandwidth usage and ensuring that only meaningful information is sent upstream. This local intelligence also enables basic alarm functionality, triggering alerts when sensor readings exceed predefined thresholds—critical for catching issues before they escalate.
E1043
Technical specifications:
Model Number E1043
Type Compact Data Acquisition Module
Input Voltage 12-24V DC
Operating Temp Range -25°C to 70°C (-13°F to 158°F)
Mounting Style DIN rail (35mm) or panel mount
Dimensions 85mm x 65mm x 32mm (LxWxH)
Weight 180g
Interface/Bus RS-485 (Modbus RTU), USB (configuration)
Compliance CE, UL 61010, RoHS, IP20
Supported Input Types 8 x analog (4-20mA, 0-10V), 4 x digital (dry contact)
Outputs 2 x digital (relay, 5A @ 250V AC)
Typical Power Draw 2.8W
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
E1043
Main features and advantages:
The E1043 delivers tangible value through its ability to democratize data access across industrial operations. By consolidating inputs from multiple sensors into a single, network-accessible device, it eliminates the need for separate data loggers or specialized interface modules, reducing both hardware costs and integration complexity. For maintenance teams, this means faster troubleshooting: instead of checking individual sensors, technicians can access all relevant data from a central dashboard, pinpointing issues like pressure drops or temperature spikes in minutes rather than hours.
In operation, the E1043ensures data integrity even in challenging conditions. Its built-in surge protection shields against electrical noise and transient voltage spikes common in factory environments, while its wide operating temperature range guarantees performance in unconditioned cabinets or outdoor enclosures. Over time, this reliability translates to fewer data gaps, more accurate trend analysis, and better-informed decisions—whether optimizing energy use, scheduling preventive maintenance, or ensuring regulatory compliance through detailed audit trails.
E1043
Application areas:
TheE1043excels in applications where space, versatility, and durability are equally critical. In automotive manufacturing, it’s used on production lines to monitor robotic arm performance metrics—tracking motor current, joint temperature, and cycle times to predict wear and prevent unexpected downtime. Its compact size allows it to fit alongside other control components in tight robot cabinets.
In water and wastewater treatment, the E1043 monitors pump pressure, flow rates, and valve positions across distributed stations, sending data to a central SCADA system to optimize water distribution and detect leaks early. Its rugged design withstands the humidity and chemical exposure typical in these facilities.
Renewable energy installations, such as solar farms, rely on the E1043 to log panel temperatures, inverter output, and ambient conditions, helping operators maximize energy yield by identifying underperforming arrays. In all these scenarios, the E1043 thrives where continuous data collection is essential but space and resources are limited.
E1043
Related products:
E1043-EXT – Extended input version with 16 analog channels for larger sensor networks
E1044 – Wireless variant with Wi-Fi and Bluetooth for remote, cable-free installations
E1043-PRO – Advanced model with Ethernet/IP support for integration with modern PLCs
E1023 – Legacy predecessor with basic functionality; upgrade path available
E1043-HV – High-voltage compatible version for monitoring up to 600V AC signals
E1043-IO – Expansion module adding 8 digital inputs for machine status monitoring
E1043-CFG – Configuration tool with preloaded templates for fast setup of common sensor types
E1043
Installation and maintenance:
Before installing the E1043, verify that the input signals match the module’s specifications—overvoltage beyond 30V DC can damage the analog input circuitry. Check that the mounting location provides adequate ventilation, especially in enclosures with heat-generating equipment; while the E1043 handles high temperatures, prolonged exposure to 70°C should be avoided where possible. Ensure the communication bus (RS-485) is properly terminated and grounded to prevent data corruption from electrical noise.
For ongoing maintenance, the E1043 simplifies oversight with status LEDs indicating power, communication activity, and input overloads. Monthly checks should include inspecting sensor connections for tightness—vibration can loosen terminals over time, causing intermittent signal loss. Every six months, clean the module’s exterior to remove dust buildup, which can insulate heat and affect long-term reliability. The E1043’s self-test function, accessible via its configuration software, runs diagnostic checks on input circuits and communication ports, helping identify issues before they impact data collection.
