Name: DPS112 high-performance digital power supply module | Qiming Automation
Brand: other
Price: 44500.00 CNY
Availability: InStock

Description

The DPS112 is a high-performance digital power supply module designed to be a key component in industrial power distribution systems. It serves as a regulated power source, converting incoming AC power into stable DC power that can be precisely controlled and monitored. This module is part of a comprehensive power management ecosystem, integrating seamlessly with PLCs, HMIs, and other control devices. In the architecture of a control system, it sits between the main power supply and the field-level equipment, ensuring that each device receives the exact voltage and current it requires.

DPS112

What makes theDPS112 invaluable to engineers and facility managers is its ability to maintain consistent power output even in the face of input voltage variations, protecting expensive equipment and ensuring uninterrupted production.

DPS112

Main features and advantages:

One of the standout technical features of theDPS112 is its exceptional voltage regulation capability. It can maintain output voltage within ±0.5% of the set value, even when the input voltage fluctuates by up to ±10%. This level of precision is crucial in applications such as laboratory testing equipment and medical device manufacturing, where even minor voltage changes can affect results. The module’s hardware design is both robust and compact, with a rugged casing that can withstand the harsh conditions of industrial environments, including exposure to dust, moisture, and mechanical shocks. Its efficient heat dissipation system ensures that it operates reliably even at high ambient temperatures.

Compatibility is another major strength of the DPS112. It supports a wide range of input voltages, from 100V AC to 240V AC, making it suitable for use in different regions around the world. It also features multiple communication interfaces, including RS-485 and Ethernet, allowing for seamless integration with industrial control systems. This enables remote monitoring and control of the power supply, giving operators real-time visibility into power consumption and performance. Long-term reliability is ensured by its high-quality components and advanced protection features, such as overcurrent, overvoltage, and short-circuit protection. These features not only extend the lifespan of the DPS112 but also protect connected equipment from damage.

DPS112

Technical specifications:
Model DPS112
Type Digital Power Supply Module
Input Voltage 100-240V AC
Output Voltage 24V DC ±0.5%
Output Current 5A
Operating Temperature -10°C to +60°C (14°F to 140°F)
Mounting DIN rail (35mm standard)
Dimensions 100mm x 60mm x 40mm (W x H x D)
Weight 250g (8.8oz)
Interfaces RS-485, Ethernet
Certifications IEC 60950, UL 60950, CE
Protection Features Overcurrent, overvoltage, short-circuit
Efficiency Up to 92%
Environmental Rating IP20

contact us:
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

DPS112

Application areas:

In the intricate landscape of industrial automation, where precise power management is the backbone of seamless operations, the DPS112 emerges as a vital solution. Consider a busy automotive assembly line, where a multitude of robotic arms, conveyor belts, and testing equipment rely on a stable power supply. Even a momentary power fluctuation can disrupt the entire production process, leading to costly delays and defective parts. Similarly, in a semiconductor fabrication plant, where sensitive microchip manufacturing equipment operates with extreme precision, consistent power delivery is non-negotiable. A single power spike could render thousands of chips useless. This is where the DPS112 proves its worth. Used in industrial automation across sectors such as electronics manufacturing, packaging, and material handling, it ensures that power is distributed efficiently and reliably to critical equipment. It acts as a safeguard against power irregularities, providing the stability needed to keep industrial processes running smoothly.

Related products:

DPS105 – A lower current variant, ideal for powering small-scale industrial devices such as sensors and small actuators.

DPS120 – A higher current model, designed to provide power to larger equipment like industrial pumps and motors.

PLC-300S – A programmable logic controller that can communicate with the DPS112 via its RS-485 interface, enabling centralized power management.

HMI-200T – A touchscreen human-machine interface that displays real-time power data from the DPS112, allowing operators to monitor and adjust settings.

SEN-400C – A current sensor that works with the DPS112 to provide accurate current measurement for load monitoring.

SWT-500E – An Ethernet switch that facilitates communication between the DPS112 and other networked devices in large industrial setups.

FUP-600P – A fuse protection unit that adds an extra layer of safety to the DPS112, preventing damage from excessive current.

BKP-700U – A backup power supply that can seamlessly take over from the DPS112 during power outages, ensuring uninterrupted operation.

Installation and maintenance:

Before installing the DPS112, ensure that the mounting location is clean and dry, with adequate ventilation. The module should be mounted on a 35mm DIN rail, and there should be at least 20mm of clearance on all sides to allow for proper airflow and heat dissipation. Check that the input voltage matches the module’s specifications to avoid damage. When connecting the output to the load, use appropriately sized cables to minimize voltage drop. For installations in areas with high electromagnetic interference, such as near large transformers or welding equipment, use shielded cables for the communication interfaces.

Maintenance of the DPS112 is focused on ensuring reliable performance and longevity. Conduct a visual inspection every three months to check for loose connections, signs of overheating, or physical damage. Clean the module’s exterior with a dry cloth to remove dust and debris. Monitor the output voltage and current regularly using the connected HMI or monitoring software to ensure they remain within the specified ranges. If any abnormalities are detected, check the input voltage and load conditions before troubleshooting the module itself. It is also recommended to update the module’s firmware periodically to benefit from the latest performance improvements and security enhancements.
