The DeltaDOP-110WS is a high – performance HMI that acts as the communication bridge between operators and industrial control systems. It features a 10 – inch widescreen display, providing a clear and intuitive interface for users to interact with. With its powerful built – in processor, it can quickly handle complex graphical displays and real – time data updates.
DOP-110WS
In the architecture of a control system, it sits at the operator – facing end, receiving commands from workers and relaying them to programmable logic controllers (PLCs) or other control devices. What makes it particularly valuable for engineers and integrators is its flexibility. It can be easily customized to fit the specific needs of different industrial applications, whether it’s a simple conveyor belt system or a highly complex multi – stage manufacturing process.
DOP-110WS
Main features and advantages:
One of the most remarkable features of the Delta DOP – 110WS is its high – resolution display. With a resolution of 800 x 480 pixels, it offers sharp and vivid visuals, making it easy for operators to read even the smallest details on the screen. This is especially beneficial in applications where precision is key, such as in electronics manufacturing. The display also has excellent visibility in various lighting conditions, including bright sunlight and dimly lit factory floors. The module’s hardware is designed for durability. It is housed in a rugged enclosure that can withstand dust, moisture, and mechanical impacts, ensuring long – term reliable operation in harsh industrial environments.
Compatibility is a major strength of the Delta DOP-110WS. It supports a wide range of communication protocols, including Modbus RTU, Modbus TCP, and Ethernet/IP. This allows it to integrate seamlessly with different types of industrial devices, such as sensors, actuators, and PLCs from various manufacturers. Long – term reliability is ensured through its advanced power management system, which reduces power consumption and heat generation, extending the lifespan of the device. It also has a wide operating temperature range, from – 10°C to + 55°C (14°F to 131°F), making it suitable for use in diverse environments, from cold storage facilities to hot industrial ovens.
DOP-110WS
Technical specifications:
Model DOP-110WS
Brand Delta
Type Human – Machine Interface (HMI)
Power Supply 24V DC (18 – 30V range)
Operating Temperature – 10°C to + 55°C (14°F to 131°F)
Mounting
Panel – mount Dimensions 297mm x 211mm x 42mm (W x H x D)
Weight 1.2kg (2.65lb)
Display 10 – inch widescreen, 800 x 480 pixels
Interfaces Ethernet, USB, RS – 232, RS – 485
Certifications CE, UL
Backlight Life Up to 50,000 hours
Environmental Rating IP65 front panel
contact us:
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
DOP-110WS
Application areas:
In the bustling world of industrial automation, having a reliable and efficient human – machine interface (HMI) is essential for seamless operations. Consider a food and beverage production line, where the continuous monitoring and adjustment of temperature, filling levels, and packaging speeds are critical to maintain product quality and meet high – volume demands. Any miscommunication between operators and the control system can lead to product waste, equipment malfunctions, or safety hazards. This is where the Delta DOP-110WS steps in as a game – changing solution.
The DeltaDOP-110WS finds its applications in a wide range of industrial settings. In manufacturing plants, it serves as the central point of interaction between workers and automated machinery. For instance, in an automotive parts manufacturing facility, operators use the DOP – 110WS to input production parameters, monitor the progress of robotic assembly lines, and receive real – time alerts about equipment status. In the energy sector, such as power generation plants, it helps engineers manage complex processes like turbine control and power distribution. By providing a user – friendly interface, it enables quick and accurate control, reducing the likelihood of errors and enhancing overall productivity. It’s designed to overcome the challenges of industrial environments, including high – noise levels and frequent vibrations, ensuring stable operation at all times.
DOP-110WS
Related products:
Delta DOP – 070WS – A smaller 7 – inch variant with a more compact footprint, ideal for applications where space is limited, such as small – scale test benches or portable industrial equipment.
Delta DOP – 150WE – An advanced version with a larger 15 – inch display and enhanced processing power, designed for complex industrial control rooms where operators need to monitor and manage multiple processes simultaneously.
Delta PLC – AS Series – Pairs perfectly with the Delta DOP – 110WS, as the HMI can be used to program and monitor the PLC, enabling seamless control of industrial processes.
Delta Sensor – T Series – These sensors can be connected to the Delta DOP – 110WS via its various interfaces, providing real – time data on temperature, pressure, and other physical parameters for operators to monitor and act upon.
Delta Inverter – C2000 Series – The DOP – 110WS can be used to adjust the speed and operation parameters of the C2000 series inverters, optimizing motor performance in industrial applications.
Delta Switch – S Series – The S series switches can be integrated with the Delta DOP – 110WS to provide additional control inputs, enhancing the flexibility of the overall industrial control system.
Delta Relay – R Series – These relays can be controlled through the DOP – 110WS, allowing for the automation of electrical circuits in industrial setups.
DOP-110WS
Installation and maintenance:
Before installing the Delta DOP-110WS, it is crucial to ensure that the mounting location has enough space for proper ventilation. Leave at least 30mm of clearance around the unit to prevent overheating. Check the electrical supply to ensure it meets the specified voltage range. For installations in areas with high electromagnetic interference, use shielded cables for all connections to the HMI. In outdoor applications, make sure the enclosure provides sufficient protection against environmental elements, as the DOP – 110WS has an IP65 – rated front panel but may require additional shielding for the sides and back.
Maintenance of the DeltaDOP-110WS is relatively straightforward. Conduct a visual inspection monthly to check for any signs of physical damage, such as cracks on the display or loose connections. Clean the screen regularly using a soft, non – abrasive cloth to maintain optimal visibility. Schedule software updates annually to ensure compatibility with the latest industrial software and to benefit from new features and security patches. In case of any display anomalies or communication issues, use the built – in diagnostic tools to troubleshoot. These tools can help identify problems such as incorrect communication settings or hardware failures quickly.
