The DEIF DLQ144-PC-NB functions as a multi-purpose interface module, serving as the translator between diverse components in industrial control architectures. Here’s how it integrates: mounted in control cabinets alongside PLCs, DCS nodes, or machine controllers, it converts analog signals (4–20 mA, 0–10 V) to digital data, processes discrete inputs/outputs, and manages serial communication via RS-485. This allows it to connect older equipment lacking modern protocols to contemporary automation systems.
Model Number DLQ144-PC-NB
Brand DEIF
Type Multi-Signal Interface Module
Input Voltage 24 VDC (18–30 VDC range)
Operating Temp Range -40°C to +70°C
Mounting Style Panel-mounted, 144 mm x 144 mm cutout
Dimensions 160 mm x 160 mm x 80 mm (W x H x D)
Weight 1.2 kg
Interface/Bus RS-485, 8 analog inputs, 16 digital I/O
Compliance CE, UL 508, IEC 61010-1
Supported Protocols Modbus RTU, Modbus ASCII
Typical Power Draw 24 VDC @ 300 mA max
The DEIF DLQ144-PC-NB functions as a multi-purpose interface module, serving as the translator between diverse components in industrial control architectures. Here’s how it integrates: mounted in control cabinets alongside PLCs, DCS nodes, or machine controllers, it converts analog signals (4–20 mA, 0–10 V) to digital data, processes discrete inputs/outputs, and manages serial communication via RS-485. This allows it to connect older equipment lacking modern protocols to contemporary automation systems.
DLQ144-PC-NB
In operation, the DEIF DLQ144-PC-NB acts as a middleware device: it receives signals from sensors or actuators, normalizes them into a standardized format, and transmits them to higher-level control systems. It supports Modbus RTU/ASCII protocols, enabling compatibility with most industrial SCADA and HMI platforms. What sets it apart is its modular design—users can configure input/output ratios to match specific application needs, from 8 analog inputs and 16 digital outputs to a mix of serial and discrete signals. This flexibility makes it ideal for both greenfield installations and retrofits, where system requirements often evolve during implementation.
DLQ144-PC-NB
Main features and advantages:
The DEIF DLQ144-PC-NB delivers tangible benefits by reducing the engineering overhead of system integration. Its ability to handle multiple signal types eliminates the need for separate conversion modules, shrinking control panel footprint by up to 40% in mixed-signal applications. This consolidation not only cuts hardware costs but also simplifies wiring, reducing installation time and potential points of failure.
In operation, its robust design ensures consistent performance in harsh environments. With immunity to electrical noise (100 V/m EMC rating) and wide temperature tolerance, it maintains signal integrity in steel mills, marine engine rooms, and outdoor power substations—settings where lesser modules would falter. The DEIF DLQ144-PC-NB also includes built-in diagnostics, such as signal drift detection and open-circuit alerts, which reduce troubleshooting time by pinpointing issues before they cause system failures. For maintenance teams, this means fewer unplanned shutdowns and more predictable uptime in critical processes.
DLQ144-PC-NB
Technical specifications:
Model Number DLQ144-PC-NB
Brand DEIF
Type Multi-Signal Interface Module
Input Voltage 24 VDC (18–30 VDC range)
Operating Temp Range -40°C to +70°C
Mounting Style Panel-mounted, 144 mm x 144 mm cutout
Dimensions 160 mm x 160 mm x 80 mm (W x H x D)
Weight 1.2 kg
Interface/Bus RS-485, 8 analog inputs, 16 digital I/O
Compliance CE, UL 508, IEC 61010-1
Supported Protocols Modbus RTU, Modbus ASCII
Typical Power Draw 24 VDC @ 300 mA max
