The DEIF AGC242 is an advanced genset controller, designed to be the nerve center of power generation and distribution control systems. It is part of DEIF’s renowned AGC200 series, which is celebrated for its reliability and cutting – edge functionality in the power management domain.
Model AGC242
Brand DEIF
Type Advanced Genset Controller
Measured Voltage 100 – 690 VAC, < 0.5 mA, 50/60Hz
UL/CUL Voltage Rating Max. 600 VAC
Measured Current -/1 A or -/5 A, < 0.3 VA (UL/CUL: use listed or r/c (xo dw 2.8) ct)
Power Supply 12/24 VDC, 12A fuse
Relay Outputs 250VAC/24VDC, 8/16A (UL/CUL: 250 VAC/DC 6A B 300, 24 VAC/DC 8/16A)
Communication Options Ethernet TCP/IP Modbus RTU (with option “N”), other possible interfaces for different applications
Operating Temperature -20°C to +55° C (varies depending on installation environment and additional cooling/heating measures)
Mounting DIN – rail mountable for easy installation in control panels
Certifications UL, CUL, and potentially others depending on specific product version and market requirements
Diagnostic Features Over – current, over – voltage, under – voltage, frequency deviation, engine – related fault detection (such as oil pressure, coolant temperature)
The DEIF AGC242 is an advanced genset controller, designed to be the nerve center of power generation and distribution control systems. It is part of DEIF’s renowned AGC200 series, which is celebrated for its reliability and cutting – edge functionality in the power management domain.
AGC242
This controller acts as a bridge between the generator, engine, and associated electrical systems. It interfaces with an array of sensors and actuators, collecting real – time data from the genset components. By analyzing this data, the AGC242 makes informed decisions to optimize the genset’s performance. For example, it can regulate the engine’s speed to maintain the generator’s frequency within the required range. It also controls the excitation system to ensure a stable output voltage, regardless of the load variations.
The DEIF AGC242 is highly adaptable, compatible with a wide range of generator types, whether they run on diesel, gas, or natural gas. It can be seamlessly integrated into both simple single – genset setups and complex multi – genset configurations found in large – scale power plants. For engineers and integrators, its flexibility is a major draw. It supports user – defined logic and control strategies, allowing for customization to meet the unique demands of different applications. Whether it’s a small – scale backup power solution or a large industrial power generation hub, the AGC242 can be programmed to deliver optimal performance and reliable operation.
AGC242
Main features and advantages:
One of the most impressive features of the DEIF AGC242is its precision in measurement. It can accurately measure voltage within the range of 100 – 690 VAC, with a current draw of less than 0.5 mA, and can precisely track the frequency at 50/60Hz. This high – level of accuracy is crucial for maintaining power quality. With such precise measurements, the controller can make minute adjustments to the genset’s output, ensuring that the power supplied is stable and suitable for even the most sensitive electrical equipment.
The controller is equipped with multiple relay outputs, rated at 250VAC/24VDC with a substantial current capacity of 8/16A (UL/CUL: 250 VAC/DC 6A B 300, 24 VAC/DC 8/16A). These relay outputs are incredibly versatile, used to control a variety of external devices. From circuit breakers that protect the electrical system from over – current situations to contactors that switch electrical loads, and even alarms that notify operators of potential issues, the AGC242‘s relay outputs can handle it all. Their high – current capacity simplifies the system design, as they can directly control many industrial – grade components without the need for additional amplification.
In terms of communication, the AGC242 is well – equipped. Options such as Ethernet TCP/IP Modbus RTU enable seamless data exchange with other devices, sensors, and monitoring systems. This connectivity is a game – changer for remote monitoring and control. Engineers can access real – time data about the genset’s performance from a control room located far away or even via the internet. This not only allows for quick decision – making but also enables proactive maintenance. By remotely monitoring the genset’s parameters, potential problems can be detected early, and maintenance can be scheduled before a major breakdown occurs.
The DEIFAGC242 is built to last. Its hardware is ruggedized, designed to withstand the harshest environmental conditions. High temperatures, humidity, and vibrations, common in industrial settings, are no match for this controller. Additionally, it comes with built – in diagnostic features that continuously monitor the health of the genset. It can detect issues like over – current, over – voltage, and engine – related problems, such as low oil pressure or high coolant temperature. When such issues are detected, the AGC242 can take appropriate action, such as shutting down the genset to prevent further damage. This proactive approach not only extends the lifespan of the genset but also minimizes unplanned downtime, which is critical for industrial operations.
AGC242
Technical specifications:
Model AGC242
Brand DEIF
Type Advanced Genset Controller
Measured Voltage 100 – 690 VAC, < 0.5 mA, 50/60Hz
UL/CUL Voltage Rating Max. 600 VAC
Measured Current -/1 A or -/5 A, < 0.3 VA (UL/CUL: use listed or r/c (xo dw 2.8) ct)
Power Supply 12/24 VDC, 12A fuse
Relay Outputs 250VAC/24VDC, 8/16A (UL/CUL: 250 VAC/DC 6A B 300, 24 VAC/DC 8/16A)
Communication Options Ethernet TCP/IP Modbus RTU (with option “N”), other possible interfaces for different applications
Operating Temperature -20°C to +55° C (varies depending on installation environment and additional cooling/heating measures)
Mounting DIN – rail mountable for easy installation in control panels
Certifications UL, CUL, and potentially others depending on specific product version and market requirements
Diagnostic Features Over – current, over – voltage, under – voltage, frequency deviation, engine – related fault detection (such as oil pressure, coolant temperature)
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
AGC242
Application areas:
In the complex world of industrial power management and automation, the DEIF AGC242stands as a reliable and versatile solution. Consider a large – scale construction site where multiple diesel generators are operating to power various equipment. The DEIF AGC242 controller takes charge of synchronizing these generators, ensuring seamless power supply. It monitors crucial parameters such as voltage, current, and frequency. If there’s a sudden increase in power demand due to the startup of heavy machinery, theAGC242 quickly adjusts the generators’ output, maintaining stable power supply and preventing any disruptions to the construction work.
Onboard ships, power reliability is non – negotiable. The DEIF AGC242 plays a pivotal role in controlling the ship’s gensets. It manages the start – stop sequences of the generators, adjusts their load based on the ship’s electrical requirements, and safeguards against electrical faults. For example, during rough sea conditions when the ship’s electrical load can fluctuate rapidly, theAGC242 ensures that the gensets respond promptly, keeping all onboard systems, from navigation equipment to living quarters’ power supply, running smoothly.
In off – grid or backup power systems, like those in remote communication stations or hospitals, the DEIF AGC242 is equally essential. It enables the efficient operation of diesel or gas – powered generators. In a hospital setting, in the event of a mains power failure, the AGC242 immediately starts the backup generator, monitors its performance, and seamlessly transfers the hospital’s critical loads to the generator, ensuring that life – saving equipment and lighting systems remain operational.
AGC242
Related products:
DEIF AGC243 – This controller is also part of the AGC200 series. While the AGC242 is focused on multi – genset control with advanced power management for plants up to 16 generators, the AGC243 can control single or multiple gensets, providing a more flexible option for smaller setups or those with different control requirements.
DEIF AGC244 – It serves as a bus – tie breaker controller. In multi – genset systems, the AGC244 works in tandem with the AGC242. The AGC242 manages the overall genset operation, and the AGC244 controls the bus – tie breakers, ensuring proper power distribution between different sections of the power system.
DEIF AGC245 – Functioning as a main – grid switch controller, the AGC245 is crucial when integrating gensets with the main power grid. The AGC242 controls the gensets’ operation, and the AGC245 manages the connection to the main grid, including functions like synchronizing the genset output with the grid voltage and frequency before connecting.
DEIF AGC246 – This controller is designed for both main – grid and 联络开关 control. Similar to the AGC245, but with additional capabilities for handling 联络开关 operations. In complex power systems where multiple power sources and distribution paths exist, the AGC246, along with the AGC242, helps in coordinating the flow of power.
DEIF IOM200 – An analog – to – digital converter module, the IOM200 is compatible with the AGC242. It expands the AGC242’s input capabilities by allowing it to interface with analog sensors. For example, it can convert analog signals from sensors measuring engine oil pressure or coolant temperature into digital signals that the AGC242 can process.
DEIF AGC252 – For large – scale power plants with up to 256 generators, the AGC252 offers advanced power management. It can be used in parallel with the AGC242 in scenarios where the power generation capacity needs to be significantly scaled up. The AGC242 can handle a subset of the generators, while the AGC252 manages the overall power distribution and coordination for the entire plant.
DEIF ASC – 4 – This controller is suitable for hybrid power solutions. When used in combination with the AGC242, it can help manage the integration of different power sources, such as solar panels and gensets, in a hybrid power system. The AGC242 controls the genset side, and the ASC – 4 coordinates the overall power flow and energy management between the different sources.
AGC242
Installation and maintenance:
Before installing the DEIF AGC242, ensure that the control panel where it will be mounted has sufficient space. The DIN – rail mounting requires a clean and stable rail with enough clearance around the controller for proper ventilation. Since the controller operates with electrical signals, proper grounding is essential. Connect the ground terminal of the AGC242 to a reliable earth ground to prevent electrical interference and ensure safe operation. Also, check the power supply voltage in the installation area to confirm it falls within the 12 – 24 VDC range required by the controller.
For maintenance, regular visual inspections are recommended. Check for any signs of physical damage, such as cracks in the enclosure or loose connections. Monthly inspections can help catch minor issues before they escalate. Periodically, perform diagnostic tests using the built – in diagnostic features of the AGC242. This can involve checking for any fault codes related to voltage, current, or engine parameters. Additionally, if the controller is connected to a network for remote monitoring, ensure that the communication lines are secure and free from interference. Update the controller’s firmware when new versions are available from DEIF. Firmware updates often contain bug fixes, performance improvements, and new features that can enhance the operation of the AGC242.
