The ABB DCC2223A 3EST125-977 operates as a critical interface between field devices and ABB’s AC 800M distributed control system (DCS), translating and routing both digital and analog signals with minimal latency. It fits into the middle layer of the automation stack, processing inputs from sensors (pressure, temperature, flow) and sending precise commands to actuators, valves, and motor drives. What sets this module apart is its dual-core processing architecture, which handles real-time control logic and communication tasks simultaneously without performance degradation.
DCC2223A 3EST125-977
It integrates seamlessly with ABB’s S800 I/O system via a high-speed backplane, while supporting open protocols for interoperability with third-party equipment. The ABB DCC2223A 3EST125-977 also includes advanced diagnostics that monitor signal integrity, module health, and communication status, alerting operators to potential issues before they escalate into failures—critical for maintaining continuous operation in 24/7 industrial environments.
DCC2223A 3EST125-977
Technical specifications:
Model NumberDCC2223A 3EST125-977
Brand ABB
Type Control & Communication Module
Input Voltage 24V DC (redundant power option)
Operating Temp Range -25°C to 70°C (-13°F to 158°F)
Mounting Style S800 I/O Backplane Mount
Dimensions 145mm x 110mm x 80mm (5.7in x 4.3in x 3.1in)
Weight 320g (0.7lbs)
Interface/Bus ABB S800 Backplane, Ethernet
Compliance CE, UL 61010, IEC 61131-2, RoHS
Supported Protocols Profibus DP, Modbus TCP/IP, ABB AC 800M Protocol
Typical Power Draw 6.5W (operating), 1.2W (standby)
Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
DCC2223A 3EST125-977
Main features and advantages:
Choosing the ABB DCC2223A 3EST125-977 delivers tangible benefits that directly impact operational performance and cost efficiency. Its ability to process 128 digital and 32 analog signals simultaneously reduces the need for multiple standalone modules, streamlining cabinet design and cutting down on wiring complexity—this alone can reduce installation time by up to 25% in new systems. The module’s robust signal isolation (2.5kV) eliminates ground loops and electromagnetic interference (EMI), ensuring measurement accuracy even in high-noise environments like near large motors or transformers. For maintenance teams, the ABB DCC2223A 3EST125-977 simplifies troubleshooting with self-diagnostic features that pinpoint issues to specific channels or connections, reducing downtime during repairs. Its design for long-term reliability—including conformal coating and extended temperature tolerance—also minimizes replacement cycles, lowering lifecycle costs in harsh industrial settings.
DCC2223A 3EST125-977
Application areas:
The ABB DCC2223A 3EST125-977 excels in environments where precision and uptime are non-negotiable. In combined cycle power plants, it coordinates gas turbine fuel valves, heat recovery steam generators (HRSGs), and emissions monitoring systems, ensuring efficient energy conversion and compliance with environmental regulations. In chemical processing facilities, it manages reactor temperature controls, pressure valves, and material feed systems, maintaining tight process tolerances to reduce waste and ensure batch consistency. It also plays a critical role in metallurgical plants, where it synchronizes rolling mill speed, cooling system flow, and quality inspection sensors—supporting high-throughput production with minimal defects. In each application, the ABB DCC2223A 3EST125-977 thrives under demanding conditions, from the high temperatures of industrial boilers to the vibration of heavy machinery.
DCC2223A 3EST125-977
Related products:
Before installing the ABBDCC2223A 3EST125-977, verify that the S800 backplane firmware is version 5.0 or higher to support the module’s advanced communication features. Check that the mounting rail is properly grounded to minimize EMI, as noise interference can affect signal accuracy. Ensure there’s at least 40mm of clearance above and below the module for airflow—sustained temperatures above 60°C may reduce component lifespan. Confirm that the 24V DC power supply can deliver at least 1A when multiple modules are installed, and use redundant power feeds for critical applications.
During maintenance, perform monthly checks of the status LEDs: steady green indicates normal operation, while amber signals a warning (e.g., high temperature) and red indicates a critical fault. Every six months, inspect terminal block connections for tightness, especially in vibrating environments, and clean backplane connectors to prevent dust buildup that could cause communication errors.
