D4-32TD2 Digital Output Module

Description

The AutomationDirect D4-32TD2 functions as a high-density digital output module, serving as the critical interface between programmable logic controllers (PLCs) and field devices like solenoids, contactors, and indicator lights. It connects seamlessly to AutomationDirect’s D4-series PLC backplanes, fitting into the middle layer of the automation stack—translating PLC commands into actionable signals for field equipment while providing status feedback to the controller.

D4-32TD2

What makes this module stand out is its ability to handle 32 discrete outputs with individual channel isolation, preventing cross-talk and ensuring that a fault in one channel doesn’t affect the entire system. The AutomationDirect

Technical specifications:
Model Number D4-32TD2
Brand AutomationDirect
Type Digital Output Module
Input Voltage 24V DC (logic), 120V AC (output)
Operating Temp Range 0°C to 60°C (32°F to 140°F)
Mounting Style DIN Rail, Backplane Mount
Dimensions 5.2in x 3.8in x 1.6in (132mm x 96mm x 41mm)
Weight 1.2 lbs (0.54kg)
Interface/Bus D4-series PLC Backplane
Compliance CE, UL 508, RoHS
Supported Protocols Native D4-series communication
Typical Power Draw 8W (logic) + 30W (max output)

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

D4-32TD2 supports real-time status monitoring via the PLC, with diagnostic capabilities that flag open circuits or overload conditions, allowing for quick troubleshooting. It operates on standard industrial communication protocols, ensuring compatibility with both new installations and retrofits of older D4-series systems, making it a versatile choice for expanding or upgrading existing automation setups.

D4-32TD2

Technical specifications:
Model Number D4-32TD2
Brand AutomationDirect
Type Digital Output Module
Input Voltage 24V DC (logic), 120V AC (output)
Operating Temp Range 0°C to 60°C (32°F to 140°F)
Mounting Style DIN Rail, Backplane Mount
Dimensions 5.2in x 3.8in x 1.6in (132mm x 96mm x 41mm)
Weight 1.2 lbs (0.54kg)
Interface/Bus D4-series PLC Backplane
Compliance CE, UL 508, RoHS
Supported Protocols Native D4-series communication
Typical Power Draw 8W (logic) + 30W (max output)

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

Main features and advantages:

Choosing the AutomationDirect D4-32TD2 delivers tangible operational benefits that directly impact productivity and maintenance efficiency. Its high-density design—packing 32 outputs into a compact form factor—reduces the required backplane space, allowing for more streamlined control cabinet layouts and easier expansion of I/O capacity without major enclosure upgrades. The module’s relay outputs are rated for 5A per channel, with surge protection to withstand voltage spikes common in industrial environments, ensuring long-term performance even with frequent on/off cycles. This durability translates to fewer replacements and lower maintenance costs over the module’s lifespan. For engineers, the AutomationDirect D4-32TD2 simplifies system design by eliminating the need for external relay banks, reducing wiring complexity and potential failure points. Its plug-and-play integration with D4-series PLCs also cuts down on setup time, getting systems operational faster and reducing engineering overhead during commissioning.

Application areas:

The AutomationDirect D4-32TD2finds its stride in applications where reliable digital control is non-negotiable. In automotive manufacturing, it’s used to control conveyor belt actuators, robotic grippers, and station indicators, ensuring that parts move through assembly stations with precise timing—critical for maintaining production quotas and preventing misalignment errors. Food and beverage processing facilities rely on it to operate valve manifolds, pump starters, and sorting gates, where consistent actuation is necessary to maintain hygiene standards and batch accuracy. It also excels in packaging lines, controlling sealing mechanisms, label applicators, and reject gates, where split-second timing ensures packages are sealed correctly and defective items are removed without disrupting the entire line. In each of these environments, the AutomationDirectD4-32TD2 thrives under the demands of continuous operation, withstanding the dust, temperature variations, and mechanical vibration that characterize industrial settings.
