Name: D201138 Wired high-channel digital I/O module with enhanced isolation | Qiming Automation
Brand: METSO
Price: 36722.00 CNY
Availability: InStock

Description

The D201138 functions as a wired high-channel digital input/output module with advanced channel isolation. It processes digital signals from a multitude of field devices such as sensors, switches, and actuators, ensuring that each channel is electrically isolated from the others. This isolation prevents the spread of electrical noise and ground loops between channels, maintaining signal purity.

D201138

It connects to the control system via a robust backplane or bus, supporting standard industrial protocols for seamless communication with PLCs, DCS, and SCADA systems. The module’s enhanced surge protection circuitry diverts excess voltage away from sensitive components, while the isolation feature adds an extra layer of protection against electrical faults. The D201138 fits into the automation stack as a central processing unit for digital signals, managing multiple devices simultaneously in complex industrial setups.

D201138

Technical specifications:
Model Number D201138
Brand METSO
Type Wired high-channel digital I/O module with enhanced isolation
Input Voltage 24V DC
Operating Temp Range -25°C to 70°C
Mounting Style DIN-rail mount
Dimensions 150mm x 120mm x 80mm
Weight 550g
Interface/Bus Profibus DP, Ethernet/IP
Compliance CE, RoHS, UL 508, ATEX
Supported Protocols Modbus RTU, Profibus DP, Ethernet/IP
Typical Power Draw 8W
