Name: D0-06DD1-D Digital I/O Module | Qiming Automation
Brand: other
Price: 49700.00 CNY
Availability: InStock

Description

The D0-06DD1-D functions as a compact digital input/output module, designed to integrate with standard PLC backplanes in the lower tier of the automation stack. It connects to the main controller via a proprietary bus interface, translating controller commands into actionable signals for field devices while feeding real-time status data back to the PLC. What sets it apart is its balanced configuration: 6 digital inputs and 6 digital outputs, each rated for 24V DC operation, making it versatile for mixed signal applications.

D0-06DD1-D

The module supports both sinking and sourcing output configurations, eliminating the need for additional signal converters when working with diverse field equipment. Equipped with built-in surge protection (up to 2kV) on all I/O channels, the D0-06DD1-D safeguards against voltage spikes common in industrial environments, reducing the risk of damage to both the module and connected devices. It also features channel-level diagnostics, with LED indicators for each input and output to simplify troubleshooting—critical for minimizing downtime during system faults.

D0-06DD1-D

Technical specifications:
Model Number D0-06DD1-D
Type Digital I/O Module
Input Voltage 24V DC (±10%)
Operating Temp Range 0°C to 60°C (32°F to 140°F)
Mounting Style DIN rail (35mm)
Dimensions 85mm x 55mm x 120mm (W x H x D)
Weight 180g
Interface/Bus DirectLOGIC DL06 PLC backplane
Compliance CE, UL 508, RoHS
Supported Protocols Proprietary DL06 bus protocol
Typical Power Draw 3.8W

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

D0-06DD1-D

Main features and advantages:

Choosing the D0-06DD1-D delivers tangible operational benefits that extend beyond basic signal management. Engineered for durability, its rugged plastic enclosure with reinforced mounting points withstands the mechanical stress of panel installations and vibration typical in industrial settings, ensuring consistent performance over time. The module’s high channel density reduces the number of required components in a system, cutting down on panel space usage by up to 40% compared to discrete I/O solutions—ideal for retrofitting older control cabinets or designing compact new systems. For maintenance teams, theD0-06DD1-D simplifies troubleshooting: each I/O channel has a dedicated status LED, allowing quick identification of faulty signals without specialized test equipment. Its pluggable terminal blocks further reduce repair time, enabling fast replacement of wiring harnesses during upgrades or Troubleshooting Most importantly, the module’s low power consumption (3.8W typical) minimizes heat generation, contributing to a cooler, more reliable control panel environment.

D0-06DD1-D

Application areas:

The D0-06DD1-D excels in applications where space efficiency and reliable digital signal handling are paramount. In packaging machinery, it manages signals from conveyor sensors, sealers, and label applicators, ensuring synchronized operation to maintain production throughput—where a single missed signal could disrupt the entire packaging sequence. In material handling systems, the module controls motor starters, limit switches, and pneumatic actuators, providing precise coordination of lifting and conveying equipment in warehouses and distribution centers. HVAC control panels also benefit from the D0-06DD1-D, as it manages damper actuators, fan relays, and temperature sensor inputs, supporting energy-efficient climate control in commercial and industrial facilities. In each scenario, the module’s ability to operate reliably in environments with fluctuating temperatures and electrical noise makes it a trusted component for maintaining consistent system performance.

D0-06DD1-D

Related products:

D0-08DD1-D – Higher channel count (8 inputs/8 outputs) for larger I/O requirements

D0-04DD1-D – Compact variant (4 inputs/4 outputs) for space-constrained panels

D0-06DD2-D – Enhanced version with higher current outputs (2A per channel) for heavy-duty devices

D0-06AD1-D – Analog I/O counterpart (6 inputs/6 outputs) for sensor signal processing

D0-06DD1-E – Extended temperature range model (-20°C to 70°C) for harsh environments

D0-06DD1-R – Redundant I/O version for mission-critical systems requiring failover capability

D0-06DD1-C – Cost-optimized model with basic features for non-critical applications

D0-06DD1-D

Installation and maintenance:

Before installing the D0-06DD1-D, verify compatibility with the target PLC—specifically, it is designed for use with AutomationDirect DL06 series controllers, and backplane firmware should be version 2.1 or higher for full functionality. Check that the control panel has sufficient vertical space (allow 10mm above and below) for heat dissipation, as the module relies on passive cooling. Ensure the 24V DC power supply can deliver at least 500mA of current to accommodate the module’s needs, plus additional capacity for connected field devices. During installation, use 16-22 AWG wire for I/O connections, torquing terminal screws to 0.5 Nm to prevent loose connections. Pay special attention to wiring polarity on output channels, as reverse voltage can damage the module’s internal protection circuitry. For initial setup, configure input filtering (0-10ms adjustable) via the PLC programming software to reduce false triggers from electrical noise.

Ongoing maintenance for the D0-06DD1-D is straightforward but critical for long-term reliability. Weekly visual inspections should check for illuminated fault LEDs—steady red indicates a channel-level issue, while a flashing red light signals a module-wide problem (refer to the user manual for fault codes). Quarterly checks should include verifying terminal block tightness, as vibration can loosen connections over time, and inspecting for signs of corrosion on terminals in humid environments. Every six months, test input responsiveness by manually triggering connected sensors and confirming signal reception in the PLC—this helps identify degraded channels before they cause system errors. Firmware updates are rare for this module but should be applied if released, via the PLC’s programming software during scheduled maintenance windows.

D0-06DD1-D
