Name: CXP-544A KOMS-A2 Industrial Communication Gateway | Qiming Automation
Brand: other
Price: 45000.00 CNY
Availability: InStock

Description

The CXP-544A KOMS-A2 functions as a protocol conversion and data synchronization gateway, positioned at the intersection of field-level devices and upper-level control systems in the automation architecture. It connects to standard industrial networks via its dual Ethernet ports and integrates with popular PLCs, HMIs, and SCADA systems through its multi-protocol support. What distinguishes it is its ability to handle concurrent data streams—up to 16 independent channels—without compromising speed or accuracy, making it ideal for large-scale installations with numerous distributed devices.

CXP-544A KOMS-A2

The module features built-in time-synchronization capabilities (supporting IEEE 1588 PTP), ensuring that all connected devices operate on a unified timeline—a critical requirement for coordinated processes like assembly line robotics or batch processing. The CXP-544A KOMS-A2 also includes advanced traffic management features, prioritizing critical control signals over non-essential data to prevent congestion during peak operation.

CXP-544A KOMS-A2

Technical specifications:
Model Number CXP-544A KOMS-A2
Type Industrial Communication Gateway
Input Voltage 12-24V DC (wide-range)
Operating Temp Range -30°C to 65°C (-22°F to 149°F)
Mounting Style DIN rail (35mm) or panel-mount
Dimensions 145mm x 90mm x 60mm (W x H x D)
Weight 380g
Interface/Bus 2 x 10/100/1000 Ethernet, RS-485
Compliance CE, FCC, UL 61010, RoHS
Supported Protocols PROFINET, EtherNet/IP, Modbus TCP, MQTT, OPC UA
Typical Power Draw 6.2W

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

CXP-544A KOMS-A2

Main features and advantages:

Selecting the CXP-544A KOMS-A2 delivers operational advantages that extend beyond basic connectivity. Engineered for high-availability environments, it features a ruggedized enclosure with IP30 protection, shielding internal components from dust and mechanical stress—ensuring reliable performance in factory-floor conditions. Its redundant power input design eliminates single points of failure, a critical feature for applications where unplanned downtime could result in significant losses. For system integrators, the module’s web-based configuration interface simplifies setup, allowing engineers to map data points, set protocol parameters, and monitor network health without specialized software. The CXP-544A KOMS-A2 also reduces long-term costs by supporting future protocol updates via firmware upgrades, eliminating the need for hardware replacement when control systems evolve. Perhaps most importantly, its low latency (under 2ms for critical signals) ensures that control actions are executed precisely when needed, maintaining process stability even in fast-paced environments.

Application areas:

The CXP-544A KOMS-A2 is deployed in scenarios where reliable, high-speed communication is non-negotiable. In automotive manufacturing, it connects robotic arms, conveyor systems, and quality inspection sensors to the central PLC, ensuring synchronized operation of assembly lines where timing errors can lead to product defects or equipment damage. In pharmaceutical production, the module facilitates secure data transfer between batch controllers and compliance monitoring systems, supporting strict regulatory requirements for process traceability and data integrity. Food and beverage processing facilities rely on the CXP-544A KOMS-A2 to link temperature controllers, flow meters, and filling machines, ensuring consistent product quality by maintaining tight control over critical process variables. In each case, the module’s ability to operate reliably in environments with frequent washdowns (IP30-rated with conformal coating) and electrical noise makes it a trusted component in demanding settings.

Related products:

CXP-544B KOMS-A2 – Higher channel count (32 channels) for large-scale networks

CXP-542A KOMS-A2 – Compact version with reduced I/O for space-constrained panels

CXP-544A KOMS-A1 – Previous generation model with limited protocol support (no MQTT)

CXP-544A KOMS-B2 – Fiber-optic interface variant for long-distance, EMI-resistant communication

CXP-564A KOMS-A2 – Advanced model with integrated cybersecurity features (firewall, encryption)

CXP-544A KOMS-C2 – Explosion-proof certified version for hazardous areas (Class I, Div 2)

CXP-540A KOMS-A2 – Cost-optimized variant for basic protocol conversion needs

Installation and maintenance:

Before installing the CXP-544A KOMS-A2 , verify that the target network infrastructure supports the module’s Ethernet speed (10/100/1000 Mbps) to avoid bottlenecks. Check that the mounting location provides adequate ventilation—allow at least 20mm of clearance above and below to prevent overheating, as the module dissipates up to 6W during peak operation. Ensure the power supply can deliver stable 12-24V DC with sufficient current (minimum 1A) to accommodate the module and any daisy-chained peripherals.

During installation, use twisted-pair shielded Ethernet cables (Cat 6 or higher) for all network connections, and ground the shield at both ends to minimize EMI. For initial setup, confirm that firmware is updated to the latest version via the web interface to access the full range of protocol features.

Ongoing maintenance for the CXP-544A KOMS-A2 focuses on network health monitoring. Weekly checks of the front-panel status LEDs are recommended: a steady green power light and flashing amber activity lights indicate normal operation, while a red fault light signals issues like network disconnects or protocol mismatches (check the built-in event log for details). Quarterly inspections should include verifying tightness of power and network connectors, as vibration in industrial settings can loosen connections over time. Annual firmware updates are advised to address emerging protocol standards and security patches, which can be applied remotely via the web interface without disrupting operation.
