CX1100-0001 Universal I/O Interface Module

Description

The CX1100-0001 functions as a compact, high-performance I/O module that fits into the middle layer of the automation stack, connecting field devices to the main control platform. It interfaces with standard backplane systems, making it compatible with most major PLC and DCS architectures. What sets it apart is its ability to handle both digital and analog signals, converting and conditioning them to ensure optimal communication with the control system.

CX1100-0001

The module supports redundant communication paths, a feature that minimizes the risk of single points of failure—vital for applications requiring continuous uptime. Equipped with advanced diagnostic capabilities, the CX1100-0001 provides real-time status updates, allowing engineers to monitor signal quality and module health remotely, which simplifies troubleshooting and reduces response times. It supports industry-standard protocols like Modbus TCP/IP and Profinet, ensuring seamless integration into existing networks without the need for extensive reconfiguration.

CX1100-0001

Technical specifications:
Model Number CX1100-0001
Type Universal I/O Interface Module
Input Voltage 24V DC ±10%
Operating Temp Range -25°C to 70°C (-13°F to 158°F)
Mounting Style DIN Rail (35mm)
Dimensions 100mm x 80mm x 62mm (W x H x D)
Weight 220g
Interface/Bus Profinet, Modbus TCP/IP
Compliance CE, UL 61010-1, RoHS
Supported Protocols Modbus TCP/IP, Profinet IO, Ethernet/IP
Typical Power Draw 4.5W

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

CX1100-0001

Main features and advantages:

Choosing the CX1100-0001 delivers tangible benefits that extend beyond basic functionality. Engineered for durability, it ensures long-term performance in harsh industrial conditions, with a rugged design that withstands vibration, temperature extremes, and electrical noise—reducing the need for frequent replacements. Its plug-and-play architecture simplifies integration, cutting down on installation time and engineering overhead, which is especially valuable in time-sensitive projects. The module’s ability to maintain signal integrity across extended cable runs means engineers can design more flexible system layouts without sacrificing performance. Additionally, the CX1100-0001’s low power consumption contributes to overall energy efficiency in the control system, aligning with modern sustainability goals. For maintenance teams, its intuitive diagnostic features mean faster issue identification and resolution, minimizing downtime and keeping processes running smoothly.

CX1100-0001

Application areas:

The CX1100-0001 finds its place in a variety of critical applications across industries. In power plants, it plays a vital role in monitoring and controlling turbine systems, where accurate signal transmission is essential for maintaining stable operation and preventing costly shutdowns. In chemical processing facilities, the module excels in handling the demands of corrosive environments, ensuring that valve positions and flow rates are communicated reliably to the DCS, supporting safe and efficient production. Water and wastewater treatment plants also benefit from the CX1100-0001, as it enables precise control of pumps and treatment processes, ensuring compliance with strict regulatory standards. In each of these settings, the module’s ability to operate continuously under heavy loads and in harsh conditions makes it indispensable for maintaining critical system uptime.

CX1100-0001
