CSR70 Power and signal management module

Description

CSR70 is a multifunctional power and signal management module that can be flexibly integrated into various system architectures. Its compact exterior design allows it to adapt to various standard or customized equipment chassis, and achieve efficient collaboration with other components within the system, such as power modules, processors, and sensors, through standardized interfaces.

CSR70

From the perspective of system interaction, CSR70 has strong power regulation capabilities, can handle a wide range of input voltages (90-264V AC), and accurately output stable DC voltage according to load requirements. The maximum output current can reach 70A, which can meet the power supply needs of different power devices. It supports multiple communication protocols, such as Modbus TCP, DNP3, etc., and can achieve seamless data interaction with the upper computer or other intelligent devices, providing real-time feedback on device operating status and power parameters. This module also has advanced overcurrent, overvoltage, and overheating protection mechanisms built-in. When abnormal conditions are detected, the circuit can be quickly cut off to protect the system from damage. In addition, its modular design allows users to flexibly add or replace functional sub modules according to actual needs, such as adding additional communication interfaces or upgrading power filtering functions, without the need for large-scale modifications to the entire system.

CSR70

Technical specifications:
Model CSR70
Type: Power and Signal Management Module
Input voltage 90-264V AC
The output voltage can be configured with DC output (typical values are 12V, 24V, 48V)
Maximum output current 70A
Working temperature range -40 ° C to+85 ° C
Installation method: rail installation, panel installation
Size 150mm x 100mm x 60mm
Weight 800g
Interface/bus RS-485, RJ45 (Ethernet), used for communication; Power input and output terminals
Compliance certification CE, UL, RoHS
Supports protocols Modbus TCP, DNP3, IEC 61850 (optional)
Typical power consumption 6VA (no-load); When fully loaded, it depends on the output load

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

CSR70

Main features and advantages:

CSR70has demonstrated many significant advantages in practical applications. Its efficient power regulation function ensures the stability of equipment operation, reduces the risk of equipment failure caused by voltage fluctuations or abnormal current, and extends the service life of equipment. For example, in medical equipment that requires extremely high power supply stability, CSR70 can provide pure and stable electricity, ensuring the precise operation of medical diagnosis and treatment equipment. The module supports multiple communication protocols, making it easy to integrate into existing intelligent systems, breaking down communication barriers between different devices, and achieving efficient data sharing and collaborative control. This is particularly important in the automated production line of smart factories, which can greatly improve production efficiency and management accuracy.
CSR70 also greatly simplifies the system design and maintenance process. Its compact modular design reduces device space occupation and facilitates device integration within limited space. For maintenance personnel, the built-in fault diagnosis function can provide real-time feedback on equipment operation status, output detailed fault information through indicator lights and communication interfaces, help quickly locate and solve problems, effectively shorten equipment downtime, and reduce maintenance costs.

CSR70

Application areas:

CSR70 has excellent application performance in many fields. In the smart grid, it is responsible for monitoring and regulating power distribution, optimizing grid operation efficiency, ensuring the reliability and stability of power supply, and achieving effective management of distributed energy. In an automated production line, it coordinates equipment power supply and signal transmission to ensure close coordination between various production processes, improve production accuracy and efficiency, and can flexibly adjust power output according to production needs to achieve energy conservation and efficiency improvement. In the field of communication base stations, CSR70 optimizes power management, reduces base station energy consumption, improves energy utilization efficiency, while ensuring stable operation of communication equipment in complex environments and enhancing communication quality.

CSR70

Related products:

CSR50: Lower current output version (maximum output current 50A), suitable for devices or small systems with low power requirements.
CSR100: High current output model (maximum output current 100A), designed specifically for large industrial equipment or high load systems.
CSR70-E: Enhanced, with a higher protection level (IP65), capable of stable operation in harsh environments such as dust and humidity.
CSR70-S: Simplified version, removing some non core functions, lower cost, suitable for scenarios with relatively simple functional requirements.
CSR70-M: Multi protocol enhanced version, in addition to standard protocols, also supports more niche but commonly used communication protocols in specific industries, meeting the needs of special industries.
CSR70-H: High temperature environment specific version, with an extended working temperature range of -55 ° C to+125 ° C, suitable for high-temperature industrial kiln monitoring, electronic equipment power supply management in automotive engine compartments, and other high-temperature scenarios.
CSR70-C: Compact, further reduced in size (120mm x 80mm x 50mm), suitable for equipment integration with extremely limited space.

Installation and maintenance:

Before installing CSR70, it is necessary to carefully check the installation environment. Confirm that the specifications of the guide rail or installation panel match the installation method of CSR70, ensuring that the installation position is stable and can withstand the weight of the module. Check if the voltage range and frequency of the input power supply are within the specifications of CSR70, while ensuring that the power supply capacity is sufficient to provide the current required for full load operation of the module. In addition, it is necessary to plan the connection of communication lines in advance to ensure smooth communication between RS-485 or Ethernet interfaces and other devices, and avoid signal interference.
During the daily maintenance of the equipment, the status indicator light of CSR70 should be regularly observed. Green constant light indicates that the device is running normally. If the indicator light flashes or turns red, the device status needs to be checked immediately and detailed fault information needs to be read through the communication interface. Conduct a comprehensive parameter check on the module once a month, comparing the actual operating parameters with the initial set values to ensure normal power output and communication functions. Clean the dust on the surface and interface of the equipment once a quarter to prevent poor heat dissipation or poor contact caused by dust accumulation. Conduct in-depth testing on the module once a year, including simulating abnormal situations such as overcurrent, overvoltage, and overheating, to verify whether the protection mechanism is working properly, and update the firmware version of the device to obtain the latest features and performance optimizations.
