Name: CPS-H32524 Industrial AC-DC Power Supply | Qiming Automation
Brand: other
Price: 49793.00 CNY
Availability: InStock

Description

The CPS-H32524 is a high-performance industrial power supply, serving as a critical component in the power distribution chain of industrial systems. It converts AC input voltage to a stable DC output, providing power to various devices such as control modules, sensors, and actuators. It is designed to fit into standard industrial enclosures, leveraging a compact form factor to save space while ensuring reliable operation.

CPS-H32524

In terms of system interaction, the CPS-H32524 accepts a wide AC input range (85 – 264V AC), making it suitable for use in different regions with varying power grids. It delivers a stable 24V DC output with a maximum current of 13.5A, capable of powering multiple devices simultaneously. It integrates with industrial control systems by providing overvoltage, overcurrent, and short-circuit protection, ensuring the safety of connected equipment. A standout feature is its high efficiency (up to 92%), which reduces energy consumption and minimizes heat generation. It also includes a remote sense function that compensates for voltage drops in long cables, ensuring that the connected devices receive the accurate voltage they need.

CPS-H32524

Technical specifications:
Model Number CPS-H32524
Type Industrial AC-DC Power Supply
Input Voltage 85 – 264V AC
Operating Temp Range -20°C to +70°C
Mounting Style DIN Rail, Panel Mount
Dimensions 125mm x 85mm x 65mm
Weight 480g
Interface/Bus DC output terminals, AC input connector
Compliance CE, UL, RoHS
Supported Protocols N/A (Power supply, no communication protocols)
Typical Power Draw 324W (maximum output)

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

CPS-H32524

Main features and advantages:

Engineered for stability and efficiency, the CPS-H32524 offers significant benefits in real-world operations. Its stable 24V DC output ensures that connected devices operate reliably, reducing the risk of malfunctions caused by voltage fluctuations. This is critical for applications like precision control systems, where even small voltage variations can affect performance. The high efficiency of the CPS-H32524 not only reduces energy costs but also lowers the heat generated, extending the lifespan of the power supply and surrounding components.

TheCPS-H32524 also simplifies system design and maintenance. Its compact size allows for easy installation in crowded industrial enclosures, saving space. The built-in protection features eliminate the need for additional external protection devices, reducing system complexity and cost. For maintenance teams, the power supply’s status indicators (LEDs) provide quick visual feedback on its operating status, making troubleshooting easier.

CPS-H32524

Application areas:

The CPS-H32524 is widely used in various industrial applications. In industrial automation, it powers control modules, sensors, and actuators in production lines, ensuring smooth and efficient operation. In telecommunications, it provides stable power to communication equipment in base stations, ensuring uninterrupted communication. In renewable energy systems, such as solar power plants, it converts the AC power from the grid or generator to DC power for charging batteries or powering DC – based equipment. Its ability to operate in a wide temperature range makes it suitable for use in harsh environments.

CPS-H32524

Related products:

CPS-H31224 – Lower power variant with 12V DC output, ideal for low – power devices.

CPS-H52524 – Higher power model with 25A current output, suitable for power – hungry applications.

CPS-H32548 – Similar power rating but with 48V DC output, for devices requiring higher voltage.

CPS-H32512 – 12V DC output version with the same input range, compatible with specific low – voltage equipment.

CPS-H32505 – 5V DC output, designed for small electronic components and sensors.

CPS-H32524-R – Redundant version, allowing for hot – swapping to ensure uninterrupted power supply.

CPS-H32524-IP67 – Waterproof and dustproof variant, suitable for outdoor or harsh industrial environments.

CPS-H32524

Installation and maintenance:

Before installing the CPS-H32524 , check the AC input voltage to ensure it matches the power supply’s input range. Verify that the load current does not exceed the maximum output current of 13.5A. Ensure there is sufficient space around the power supply for heat dissipation, as it generates some heat during operation. It is also important to check the mounting location to ensure it is secure and can support the weight of the power supply.

For ongoing maintenance, regularly inspect the power supply’s status LEDs. A green LED indicates normal operation, while a red LED signals a fault. Check the input and output connections periodically to ensure they are tight and free from corrosion. Clean the surface of the power supply to remove dust and debris, which can affect heat dissipation. It is recommended to perform a functional test annually to verify the output voltage and protection features are working correctly.
