ABB CI857K01 3BSE018144R1 Product Introduction:
ABB CI857K01 3BSE018144R1 is an INSUM Ethernet interface module that is a key component in ABB’s industrial automation ecosystem. It is integrated into the infrastructure of the control system, especially for interfacing with the backplane system. This module is powered by the processor unit through the CEX bus and does not require an additional external power supply. It supports the INSUM communication protocol and is designed to be used in conjunction with ABB’s AC800M controller and other automation components. This module has two Ethernet ports, supports 10/100/1000 Base TX standards, and has automatic negotiation and automatic MDIX functions. It also supports popular industrial protocols such as TCP/IP, UDP, Modbus TCP, and IEC 61850, ensuring compatibility with various devices. In addition, it also provides hot swappable redundancy options, which means that in the event of module failure, replacement can be carried out without shutting down the entire system, thereby minimizing interference with operations.
CI857K01 3BSE018144R1
Technical specifications:
Model CI857K01
Brand ABB
Type INSUM Ethernet Interface Module
The input voltage is powered by the processor unit through the CEX bus (no external power supply required)
Working temperature range -40 ° C to+70 ° C
Installation method designed for installation on a suitable backplane system (specific application details)
Dimensions: Depth/Length: 127.5 millimeters, Height: 186 millimeters, Width: 59 millimeters
Weight 0.7 kilograms
Interface/Bus Ethernet (RJ-45 female, 8-pin), CEX bus power supply
Compliance with CE, UL, EAC, RoHS (en 50581:2012), WEEE (Directive 2012/19/EU) standards
Supported protocols TCP/IP, UDP, Modbus TCP, IEC 61850
Typical power consumption 24V consumption, typical value 150mA
