Name: CAS200 CLS216 Multi-Axis Motion Control Module | Qiming Automation
Brand: WATLOW ANAFAZE
Price: 29800.00 CNY
Availability: InStock

Description

The CAS200 CLS216 functions as a multi-axis motion controller, positioned between the main PLC or HMI and the drive systems in the automation architecture. It connects to servo and stepper drives via a high-speed serial bus, while communicating with the upper-level control system through Ethernet/IP and PROFINET protocols.

CAS200 CLS216

What distinguishes it is its advanced trajectory planning capability, supporting linear, circular, and helical interpolation across all 16 axes—enabling complex motion sequences that would be impractical with basic controllers. The module features a 32-bit floating-point processor that calculates motion profiles in real time, ensuring smooth acceleration and deceleration to prevent mechanical stress on machinery. Equipped with built-in safety functions (STO, SS1 according to EN 61800-5-2), the CAS200 CLS216 provides safe torque-off capabilities, critical for protecting operators and equipment during emergency stops. It also includes a removable memory module for storing motion programs, allowing quick swapping between different production recipes without reconfiguration.

CAS200 CLS216

Technical specifications:
Model Number CAS200 CLS216
Brand WATLOW ANAFAZE
Type Multi-Axis Motion Control Module
Input Voltage 24V DC ±15%
Operating Temp Range 0°C to 55°C (32°F to 131°F)
Mounting Style DIN rail (35mm) with locking clips
Dimensions 140mm x 80mm x 120mm (W x H x D)
Weight 420g
Interface/Bus Ethernet/IP, PROFINET, SERCOS III
Compliance CE, UL 61800-5-1, RoHS
Supported Protocols Ethernet/IP, PROFINET, Modbus TCP, SERCOS III
Typical Power Draw 8.5W
