BG65X50SI Brushless DC Motor

Description

The Dunkermotoren BG65X50SI motor adopts advanced brushless DC motor technology, combined with optimized magnetic circuit design, to achieve excellent performance in a compact 65mm diameter body. The rated output torque of the motor can reach 50mNm, and with an efficient heat dissipation structure, it can maintain stable torque output even under continuous high load operation, effectively avoiding performance degradation caused by overheating. Its maximum speed can reach 6000 revolutions per minute, and its fast speed response characteristics enable the motor to complete actions such as starting, accelerating, decelerating, and turning in a very short time, accurately meeting the needs of automation equipment for fast and precise positioning. The motor achieves position feedback through high-precision encoders, ensuring that each movement can achieve micrometer level positioning accuracy, greatly improving the accuracy and stability of equipment operation. In terms of driving mode, the motor supports multiple control protocols and can seamlessly integrate with various mainstream motion controllers. Whether it is complex multi axis linkage control or simple single axis positioning operation, it can be easily adapted, providing great convenience for system integration.

BG65X50SI

Technical specifications:
Model Number BG65X50SI
Brand Dunkermotoren
Type Brushless DC Motor
Rated Torque 50mNm
Max Speed 6000 RPM
Diameter 65mm
Length 120mm (standard version)
Weight 1.2kg
Rated Voltage 24 – 48V DC (adjustable)
Efficiency Up to 90%
Encoder Resolution 1024 PPR (pulses per revolution)
Protection Class IP54 (dust and water splash protection)
Operating Temperature Range -20°C to 60°C
Control Modes PWM, speed control, position control

contact us:
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

BG65X50SI

Main features and advantages:

Choosing Dunkermotoren BG65X50SI motor will bring many significant advantages to automation equipment. Its sturdy and durable all metal casing, combined with IP54 protection level, can effectively resist the erosion of dust and water splashes. Even in industrial workshops filled with dust or environments with occasional water droplet splashes, it can operate stably, greatly reducing the occurrence rate of failures caused by environmental factors and extending the overall service life of the equipment. The high torque density design of the motor enables it to output powerful power within a limited installation space, which is undoubtedly a key advantage for compact automation equipment. It not only optimizes the internal structure of the equipment, but also improves its performance without increasing its volume. In addition, the high-efficiency and energy-saving characteristics of this motor can reduce energy consumption by about 30% compared to traditional brushed motors, and can save considerable electricity costs for enterprises during long-term operation.

BG65X50SI

Application areas:

Dunkermotoren BG65X50SI motor has excellent performance in various automation application scenarios. In the SMT mounting machine of the electronic manufacturing industry, its precise position control and fast response speed ensure that electronic components can be accurately mounted on circuit boards, greatly improving the mounting efficiency and product qualification rate. In the field of medical equipment, such as automated blood testing analyzers, the stable operation and high-precision positioning of motors ensure the accurate transportation of samples and the precise execution of detection actions during the detection process, providing reliable data support for medical diagnosis. In the automatic sorting system of logistics warehousing, the powerful torque output of the motor can drive the belt conveyor to operate quickly and stably, achieving efficient sorting and transportation of goods and effectively improving the efficiency of logistics operations. In every application scenario, the Dunkermotoren BG65X50SI motor, with its outstanding performance, has become the core power source to ensure stable operation of equipment and improve production efficiency.

BG65X50SI

Related products:

BG65X80SI – High torque version, with a rated torque increased to 80mNm, suitable for heavy-duty applications that require greater power output, such as large automated handling equipment.
BG65X50SIL – Long life version, using special bearings and insulation materials, extends the service life by about 50% in harsh working conditions, suitable for use in environments with long continuous operation time and difficult maintenance.
BG65X50SI – HV – High voltage version, supports 80-120V DC input voltage, can work stably in scenarios where power supply is unstable or long-distance power transmission is required.
BG65X50SI – EZ – Easy Installation Version, optimized motor installation structure, equipped with quick installation interface, reduces installation time by about 40%, making it easy to quickly complete motor replacement and debugging on site.
BG65X50SI – COMBO – Package version, including motor, matching driver, encoder cable, and installation accessories, providing users with a one-stop solution to reduce system integration difficulty.
DM-DRIVE – BG65- A driver specially designed for BG65 series motors, which can fully utilize motor performance and has overcurrent and overheat protection functions to ensure safe motor operation.
DM – MOUNT – KIT – Multiple mounting bracket kits suitable for BG65X50SI motors, meeting the installation needs of different devices and providing flexible installation methods.

Installation and maintenance:

Before installing the Dunkermotoren BG65X50SImotor, it is necessary to carefully confirm the load characteristics and operating requirements of the equipment to ensure that the rated torque and speed of the motor can meet the actual working conditions and avoid motor overload operation. Check the flatness and rigidity of the motor installation position to ensure that the installation surface can withstand the vibration and torque reaction force generated during motor operation, and prevent abnormal motor operation caused by unstable installation. During the wiring process, it is necessary to strictly follow the motor wiring diagram to ensure that the positive and negative poles of the power supply are connected correctly, the encoder cable is firmly connected, and to avoid damaging the motor or causing control abnormalities due to wiring errors.

After installation, before starting the motor for the first time, a multimeter or other tools should be used to check whether the circuit connection is normal and measure whether the resistance value of the motor winding is within the normal range. During the operation of the motor, regularly check the temperature and vibration of the motor. If abnormal temperature rise or increased vibration is found, the machine should be stopped in time to troubleshoot. At the same time, lubrication and maintenance of the motor bearings should be carried out every six months to ensure the long-term stable operation of the motor.
