BG02.510 Modular Low-Voltage Power Distribution Block

Description

The BG02.510 functions as a DIN-rail mounted power distribution module, designed to distribute a single input power source (typically 24V DC) to multiple output circuits while providing overload protection for each channel. It features 10 individually fused output channels, each rated for up to 5A, allowing precise power allocation to different devices based on their current requirements. What sets it apart is its compact, modular design—occupying just 60mm of DIN rail space—making it ideal for crowded control cabinets where space is at a premium. The module accepts input power via a screw-terminal connector and distributes it through spring-clamp output terminals, ensuring secure connections that resist vibration-induced loosening.

BG02.510

The BG02.510  integrates seamlessly into existing cabinet architectures, with LED indicators for each channel that provide instant visual confirmation of power status, simplifying troubleshooting when a circuit trips. Unlike traditional terminal blocks with external fuses, this module consolidates protection and distribution into a single unit, reducing wiring complexity and installation time.

BG02.510

Technical specifications:
Model Number BG02.510
Brand SAFETEC
Type Modular Low-Voltage Power Distribution Block
Input Voltage 24V DC (18-30V DC range)
Output Channels 10 (individually fused)
Max Output Current per Channel 5A
Operating Temp Range -25°C to 70°C (-13°F to 158°F)
Mounting Style DIN Rail (35mm)
Dimensions 60mm x 90mm x 65mm (2.4″ x 3.5″ x 2.6″)
Weight 220g (7.8oz)
Protection Features Overload, short-circuit (via replaceable fuses)
Compliance EN 60947-1, CE, UL 508
Terminal Type Spring-clamp (input), screw-clamp (outputs)
Typical Power Loss <1.5W (full load)

contact us:
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

BG02.510

Main features and advantages:

Choosing the BG02.510 delivers tangible benefits for control system design and maintenance. Its rugged construction—with a polyamide housing rated IP20—ensures durability in harsh industrial environments, resisting dust, chemicals, and temperature fluctuations. The module’s individual channel protection prevents a single device failure from taking down an entire system, reducing downtime and simplifying fault isolation. Engineers will appreciate the flexible configuration; replaceable 5x20mm fuses allow quick adaptation to changing load requirements, while clear labeling and color-coded terminals minimize wiring errors during installation. Most importantly, theBG02.510 reduces cabinet clutter by consolidating 10 circuits into a compact footprint, freeing up space for other components and improving airflow around heat-sensitive devices like drives and power supplies.

BG02.510

Application areas:

The BG02.510 excels in applications where organized, protected power distribution is critical. In packaging machinery, it distributes power to photoeyes, solenoid valves, and small motors, ensuring that a single jammed sensor doesn’t shut down the entire line. In food and beverage processing, it powers control panel components in washdown areas, with its chemical-resistant housing standing up to regular cleaning protocols. The module also performs reliably in material handling systems, where it distributes power to conveyor sensors and position encoders, preventing nuisance shutdowns caused by temporary overloads. In each case, the BG02.510 provides the protection and flexibility needed to maintain consistent operation, directly contributing to higher equipment availability and lower maintenance costs.
