BG0090 PC0006 High-Density Signal Terminal Block

Description

The BG0090 PC0006 functions as a modular signal terminal block, designed to terminate and distribute low-voltage signal lines (up to 30V DC) in control cabinets. It features 90 individual terminals arranged in a compact, dual-row configuration, each capable of accepting wire sizes from 28AWG (0.08mm²) to 14AWG (2.5mm²)—accommodating everything from delicate sensor leads to heavier-duty communication cables. What sets it apart is its integrated shielding design, which minimizes electromagnetic interference (EMI) between adjacent signal lines, a common issue in crowded cabinets with both power and signal wiring.

BG0090 PC0006

The terminal block uses a push-in connection mechanism that ensures secure, vibration-resistant terminations without the need for tools, reducing installation time while preventing accidental disconnections. The BG0090 PC0006  integrates seamlessly into DIN rail-mounted cabinet setups, with clear labeling and color-coded markers that simplify wire tracing and maintenance. Unlike traditional screw-terminal blocks, its tool-free design eliminates the risk of over-tightening, which can damage fine wires, making it ideal for both high-volume installations and precision applications.

BG0090 PC0006

Technical specifications:
Model Number BG0090 PC0006
Brand TEAM
Type High-Density Signal Terminal Block
Rated Voltage 30V DC (max)
Rated Current 8A per terminal
Number of Terminals 90 (dual-row)
Wire Size Range 28AWG (0.08mm²) to 14AWG (2.5mm²)
Operating Temp Range -40°C to 85°C (-40°F to 185°F)
Mounting Style DIN Rail (35mm)
Dimensions 120mm x 95mm x 45mm (4.7″ x 3.7″ x 1.8″)
Weight 380g (13.4oz)
Connection Type Tool-free push-in
Protection Features EMI shielding, vibration resistance
Compliance EN 60947-7-1, CE, UL 1059
Material Polyamide housing (flame-retardant)
