BENTLY 350093-01-00-00 Display Interface Module (DIM)

Description

BENTLY 350093-01-00-00 is a Display Interface Module (DIM) designed specifically for the BENTLY 3500 series, which is a leading turbomachinery monitoring system. As the human-machine interface (HMI) of the 3500 system, it serves as the primary entry point for operators to monitor and interact with mechanical equipment health data. This module is typically installed in Slot 15 of a 3500 rack and can seamlessly integrate with other 3500 components such as vibration monitors and communication gateways, providing a unified view of system status.

350093-01-00-00

This module supports intuitive navigation through menus, trend charts, and alert summaries, reducing the learning curve for operators. Its compatibility with the 3500 system architecture ensures plug and play integration, making it an ideal choice for upgrading traditional monitoring settings or new installations. Unlike standalone human-machine interfaces,350093-01-00-00 is designed specifically for harsh industrial environments, combining robust hardware with software optimized for real-time data processing.

350093-01-00-00

Main features and advantages:
High performance display screen and user experience
350093-01-00-00 is equipped with a 10.4-inch color LCD display that can simultaneously display up to 100 parameters, including trend charts and bar charts. Its sun readable display ensures clarity in bright industrial environments, while the responsive touch interface (or optional keyboard) enables intuitive navigation. This module supports configurable alarms and indicators, allowing users to prioritize key parameters such as shaft vibration or bearing temperature.

Robust industrial design
This module is designed to withstand harsh conditions and can operate reliably within a temperature range of -20 ° C to 65 ° C. It also has the ability to prevent dust, moisture, and electromagnetic interference (EMI). Its compact external dimensions (19 inch rack installable) are suitable for standard control cabinets, while the hinged design (for panel installation) facilitates access to the rear connectors during maintenance. The durable casing of this module meets industry standards for impact and vibration resistance, ensuring a long lifespan in high motion environments such as rotating machinery areas.

Seamless system integration
As part of the 3500 ecosystem, 350093-01-00-00 communicates natively with other 3500 modules through the system’s internal data bus. It supports external connections through Ethernet ports (used for remote monitoring through BENTLY’s Asset Condition Monitor software) and serial interfaces (RS-232/485, used for traditional systems). This flexibility allows it to function as an independent human-machine interface or integrate with SCADA networks across the factory.

Long term reliability
This module uses non-volatile memory to store data during power outages and retains configuration settings without the need for battery backup. Regular firmware updates (delivered through BENTLY’s System 1 software) enhance functionality, such as adding new sensor types or improving alarm logic, ensuring that modules evolve continuously with operational needs. Its mean time between failures (MTBF) exceeds 100000 hours, reflecting BENTLY’s reputation for industrial grade durability.

350093-01-00-00

Technical specifications:
Model 350093-01-00-00
Brand BENTLY
Type Display Interface Module (DIM)
Power supply 100-240 VAC, 50/60 Hz (automatic range)
Working temperature -20 ° C to 65 ° C
Installation method: Panel installation (3500 rack), 19 inch EIA rack, panel installation or remote installation
Dimensions 483 millimeters (width) x 133 millimeters (height) x 305 millimeters (depth) [19 inch rack mount]
Weight 4.5 kilograms
10.4-inch color LCD display screen with 800 x 600 resolution
Interface Ethernet (10/100 Mbps), RS-232/485, USB (for firmware updates)
Certified UL, CE, CSA, ATEX (for hazardous areas)
Environmental grade IP20 (front panel), compliant with IEC 61000-4-2/3/4 (electromagnetic compatibility)
Alarm capability: 50 configurable alarms with priority levels

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

350093-01-00-00

Application areas:
In the steam turbine system, 350093-01-00-00 can display real-time vibration, temperature, and speed data, allowing engineers to detect early signs of misalignment or bearing wear before faults occur.
In petrochemical refineries, it monitors the operating status of compressors and pumps, provides instant alarms for parameter deviations (such as excessive axial displacement or thermal stress), thereby preventing unexpected shutdowns and safety accidents.

350093-01-00-00

Related products:
BENTLY 3500/15 Communication Gateway – enables data integration with enterprise systems through OPC UA or Modbus.
BENTLY 350040M Proximity Sensor Monitor – provides shaft vibration and displacement data for display on 350093.
BENTLY 350022M Speed/Trip Monitor – Provides speed and overspeed trip data to the module.
BENTLY 350032 TSI Modular Rack – a physical enclosure designed to accommodate 350093 and other 3500 modules.
BENTLY 350053 Dual Channel Temperature Monitor – Provides temperature data for bearings and processes.

350093-01-00-00

Installation and maintenance:
Considerations before installation
Installation location: For panel installation, ensure that Slot 15 of the 3500 rack is available and properly grounded. For remote installation (up to 100 feet away), please use shielded cables to prevent signal attenuation.
Power and cooling: Verify that the power supply meets module specifications and ensure sufficient air circulation around the rack to prevent overheating.
Cable management: Separate the wiring of sensors and communication cables from power cables to reduce electromagnetic interference (EMI).
Maintenance suggestions
Monthly inspection: Check for loose connections, clear screens, and proper functioning of alarm indicators.
Firmware update: Schedule quarterly updates to leverage new features and security patches (seamless deployment using BENTLY’s System 1 software).
Calibration check: Verify the accuracy of sensor to display data annually using calibration tools such as BENTLY Nevada 2080 Plus.
