BENTLY 3500 – 4 – 1 High performance data acquisition and transmission module

Description

BENTLY 3500-4-1 is a high-performance data acquisition and transmission module designed specifically for industrial monitoring and control systems. It occupies a critical position in the Bentley 3500 series system, responsible for collecting data from various sensors and accurately transmitting the processed data to the central control system.

3500-4-1

This module is compatible with multiple control platforms and enables efficient data exchange through a standard backplane system. In terms of data acquisition, it supports multiple industrial standard I/O signal interfaces, which can accurately obtain both analog and digital signals. At the same time, the module integrates advanced data processing algorithms internally, which can preprocess the raw data before data transmission, eliminate noise and invalid data, and ensure the authenticity and reliability of the data transmitted to the upper layer system. In the system architecture, Bentley3500-4-1serves as the front-end device for data acquisition, closely connected to on-site sensors, while also working in conjunction with back-end data analysis, storage, and control units to form a complete data flow loop.

3500-4-1

Technical specifications:
Model 3500-4-1
Brand Bentley Nevada
Type Data Collection and Transmission Module
Input signal type: analog signal, digital signal
Working temperature range -20 ° C to+60 ° C
Installation method: Rack installation (compatible with Bentley 3500 series rack)
Interface/bus supports industrial standard bus
Compliance with relevant international standards such as CE and RoHS
Supports protocol compatibility with common industrial communication protocols such as Modbus, Profibus, etc

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

3500-4-1

Main features and advantages:
Its sturdy and durable hardware design can withstand vibrations, dust, and temperature fluctuations in industrial environments, ensuring normal operation under harsh conditions and greatly improving the reliability of the system. Efficient data processing and transmission capabilities ensure real-time and accurate data, enabling operators to adjust production processes in a timely manner based on the latest data, improving production efficiency and product quality. From a maintenance perspective, this module is designed to be simple, easy to inspect and maintain, reducing downtime caused by equipment failures and lowering maintenance costs. Moreover, its good compatibility with existing systems greatly reduces the difficulty of integration, reduces the complexity and time cost of engineering implementation.

3500-4-1

Application areas:
In the manufacturing industry, it is used for real-time monitoring of production lines, collecting equipment operation data such as vibration, temperature, etc., to timely detect potential faults and ensure the continuous operation of production lines.
In the power industry, this module plays an important role in power plants, collecting various operating parameters of the generator set, helping staff to grasp the real-time status of the unit, and ensuring the stability and efficiency of the power generation process.
The chemical industry also relies on BENTLY 3500-4-1 to monitor complex production processes, accurately collect key data such as reactor temperature and pressure, and provide strong support for safety production and quality control.

Related products:
Bentley 3500-5-1: Compared to 3500-4-1, it has higher data processing capabilities and more I/O channels, making it suitable for industrial scenarios with more complex data acquisition requirements and larger scales.
Bentley 3500-3-1: focuses on basic data acquisition functions, with relatively low cost, suitable for small industrial projects with low requirements for data processing capabilities and limited budget.
Bentley 3500-4-2: Based on 3500-4-1, optimized support for specific types of sensors to better adapt to sensor devices in certain special industrial environments.

Installation and maintenance:
Before installing BENTLY 3500-4-1, carefully check the compatibility between the fieldbus and module interfaces to ensure smooth communication connections. At the same time, sufficient heat dissipation space should be reserved, as the module will generate a certain amount of heat during continuous operation, and good heat dissipation conditions can help maintain its stable performance. In addition, check whether the type and quantity of connected sensors match the design specifications of the module to avoid data collection abnormalities caused by overload or mismatch.
In daily maintenance, regularly check the status of the LED indicator lights on the module, and determine the operation status of the module based on the color and flashing frequency of the indicator lights. Regularly inspect the connecting cables and interfaces to prevent data transmission from being affected by looseness, oxidation, and other issues. It is recommended to conduct a comprehensive functional test once a year to ensure that all performance indicators of the module meet the standards.
