BENTLY 3500/15 106M1081-01 AC power module

Description

BENTLY 3500/15 106M1081-01 AC power module is designed for seamless integration in the Bentley 3500 series architecture, which is widely used in industrial vibration monitoring and process control systems.

106M1081 – 01

This module can be connected to various sensors, monitors, and other devices within the system to supply them with the necessary power. It can be installed in the designated slot on the left side of the 3500 rack. In a dual power configuration, the module in the lower slot serves as the main power source, while the module in the upper slot serves as the backup power source. This ensures continuous power supply even in the event of a failure in the main power unit. This module supports a wide input voltage range of 85-264 VAC RMS, which is extremely practical when facing different power sources in industrial environments. In addition, it is compatible with other modules of the 3500 series, making it easy to expand and integrate within existing control architectures.

106M1081 – 01

Technical specifications:

Model 106M1081-01
Brand Bentley Nevada
Type: AC power module
Input voltage 85-264 VAC RMS
Working temperature range -30 ° C to+65 ° C
Installation method: Rack installation (for 3500 series racks)
Size 25.15 cm x 5.08 cm x 12.07 cm
Weight 3 kg
The interface/bus is mainly used for power distribution within the 3500 series system
Compliance with relevant industrial standards

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

106M1081 – 01

Main features and advantages:
Its high-quality electronic components and advanced circuit design ensure reliable operation even in harsh industrial environments. The wide input voltage range reduces the need for additional voltage conversion equipment, thereby lowering engineering costs. In terms of maintenance efficiency, the design of this module is easy to inspect and replace if necessary. In the long run, its reliable performance helps minimize unexpected downtime, ensuring production continuity and maximizing investment returns.

106M1081 – 01

Application areas:
In power plants, it provides a stable power source for monitoring systems to track turbine vibration and generator health, which is crucial for maintaining continuous power generation and preventing equipment failures that may cause power outages.
In the chemical industry, as the production process usually requires 24/7 uninterrupted operation, this module ensures that the process control system is always powered on, thereby achieving real-time monitoring and adjustment of chemical reactions. Oil and gas facilities also rely on this module to power their equipment health monitoring systems, which is essential for achieving safe and efficient operation in typically harsh and remote environments.

106M1081 – 01

Related products:
Bentley 3500/15 106M1079-01: Similar in functionality to 106M1081-01, but may differ in certain power processing capabilities or adaptability to specific application scenarios.
Bentley 3500/15 DC Power Module: Suitable for applications that prefer or require DC power, it provides another power solution in the 3500 series ecosystem.
Bentley’s early power module: 106M1081-01 in the 3500 series, may still be suitable for legacy systems or situations that meet specific compatibility requirements.

106M1081 – 01

Installation and maintenance:
Before installing Bentley 3500/15 106M1081-01, it is essential to check the compatibility of the power input requirements with the existing electrical infrastructure. Ensure that the voltage range and frequency of the power supply match the specifications of the module. At the same time, confirm the available space for installation in the 3500 series rack, as proper installation is key to its performance.
In terms of continuous maintenance, the module should be regularly checked for signs of overheating or physical damage, and the connection parts should be checked to ensure its stability. Conducting functional testing once a year can also help confirm whether the module is operating within the expected parameter range.
