BENTLY 3500/15 106M1079-01 AC power module

Description

The Bentley 3500/15 106M1079-01 AC power module is designed for seamless integration with the Bentley 3500 series framework, which is widely used in industrial vibration monitoring and process control systems.

106M1079-01

This module can be connected to various sensors, monitors, and other devices in the system to provide necessary power. It can be installed in the designated slot on the left side of the 3500 rack. In a configuration using two power sources, the module located in the lower slot serves as the main power source, while the module in the upper slot serves as the backup power source, ensuring continuous power supply in the event of a failure in the main power unit. This module supports a wide range of input voltages, which is very advantageous when dealing with different power sources in industrial environments. In addition, it is compatible with other modules in the 3500 series, making it easy to expand and integrate within existing control architectures.

106M1079-01

Main features and advantages:
Its high-quality electronic components and advanced circuit design ensure reliable operation even in harsh industrial environments. The wide input voltage range reduces the need for additional voltage conversion equipment, thereby lowering engineering costs. In terms of maintenance efficiency, the design of this module facilitates easy inspection and replacement when needed. In the long run, its reliable performance helps reduce unexpected downtime, ensuring continuous production and maximizing return on investment.

106M1079-01

Technical specifications:
Model:106M1079-01
Brand: Bentley Nevada
Type: AC power module
Input voltage: 85-264 VAC RMS (root mean square value)
Working temperature range: -30 ° C to+65 ° C
Installation method: Rack installation (installed in 3500 series racks)
Size: 25.15cm x 5.08cm x 12.07cm
Weight: 3 kilograms
Interface/Bus: None (primarily used for power distribution within 3500 series systems)
Compliance: Complies with relevant industry standards

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

106M1079-01

Application areas:
In power plants, it provides a stable power source for monitoring systems to track turbine vibration and generator health. This is crucial for maintaining continuous power generation and preventing equipment failures that may lead to power outages.
In the chemical industry, due to the 24-hour uninterrupted operation of the production process, this module ensures that the process control system is always powered, enabling real-time monitoring and adjustment of chemical reactions.
Oil and gas facilities also rely on this module to power their mechanical health monitoring systems, which is crucial for achieving safe and efficient operation in typically harsh and remote environments.

106M1079-01

Related products:
Bentley 3500/15 106M1081-01: A universal AC power input module with similar functions, but may differ in power processing capabilities or additional features, suitable for different application requirements.
Bentley 3500/15 DC Power Module: Suitable for applications that require or demand the use of DC power, it provides another power solution in the 3500 series ecosystem.

106M1079-01

Installation and maintenance:
Before installing Bentley 3500/15 106M1079-01, it is necessary to check the compatibility of the power input requirements with the existing power infrastructure. Ensure that the voltage range and frequency of the power supply match the specifications of the module. In addition, it is necessary to confirm the available installation space in the 3500 series rack, as proper installation is crucial for its performance.
For continuous maintenance, modules should be regularly checked for signs of overheating or physical damage. Check if the connection is secure. It is also possible to conduct a functional test once a year to confirm whether the module is running within the expected parameter range.
