Name: BENTLY 125680-01Measurement and Signal Processing Module | Qiming Automation
Brand: Bently Nevada

Description

The BENTLY 125680-01 functions as a versatile and high-performance measurement module, seamlessly integrating into a variety of industrial monitoring and protection systems. It interfaces with a range of sensors, such as proximity probes, which are used to measure the displacement of a shaft relative to its bearing, or velocity sensors that detect vibration levels. Once connected to these sensors, the module processes the incoming analog signals, converting them into digital data that can be easily analyzed by higher-level control and monitoring systems.

125680-01

This module is designed to communicate with BENTLY’s comprehensive suite of machinery protection systems, as well as many third-party platforms. It utilizes industry-standard communication protocols, like MODBUS and Ethernet/IP, to transmit the processed data efficiently. In a typical setup, it can be installed within a control cabinet and connected to the backplane of a larger monitoring system. Its modular design allows for easy installation and replacement, reducing downtime during system upgrades or maintenance. Additionally, the BENTLY 125680-01 incorporates advanced signal conditioning features, which filter out noise and interference, ensuring that the data sent to the monitoring system is clean and accurate. This makes it an ideal component for creating a reliable and comprehensive machinery health monitoring network, where every piece of data contributes to the overall safety and efficiency of industrial operations.

125680-01

Technical specifications:
Model 125680-01
BrandBENTLY
TypeMeasurement and Signal Processing Module
Input Voltage24V DC (±10%)
Operating Temp Range-40°C to +70°C (-40°F to +158°F)
Mounting StyleDIN Rail Mount or Panel Mount
Interface/BusMODBUS RTU, Ethernet/IP
ComplianceCE, RoHS, UL
Supported Protocols
MODBUS, Ethernet/IP, Profibus

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

125680-01

Main features and advantages:

Selecting the BENTLY 125680-01offers a plethora of significant benefits in real-world industrial applications. Its high-precision measurement capabilities ensure that even the slightest changes in equipment parameters are detected promptly. This allows maintenance teams to identify potential issues long before they escalate into major problems, enabling them to schedule maintenance during planned downtimes and avoid costly unplanned outages. The module’s reliability also means fewer false alarms, reducing unnecessary disruptions to production processes and allowing operators to focus on core tasks with confidence.

Engineered to withstand harsh industrial environments, the BENTLY125680-01 features a rugged construction and advanced environmental protection measures. It can operate reliably in extreme temperatures, high humidity, and environments with significant electromagnetic interference. This durability not only extends the product’s lifespan but also minimizes the need for frequent replacements and repairs, resulting in substantial cost savings over time. Furthermore, its seamless integration with existing monitoring systems reduces the complexity and cost of system upgrades, making it a cost-effective choice for enhancing industrial automation and machinery protection.

125680-01

Application areas:

The BENTLY 125680-01 finds extensive use across multiple industries. In the power generation sector, it is employed to monitor the displacement and vibration of turbine shafts in power plants. By continuously measuring these parameters, operators can ensure that the turbines are running smoothly and efficiently, preventing potential failures that could disrupt power supply to large areas. In the oil and gas industry, it is used to monitor the position and movement of critical components in pumps, compressors, and drilling equipment. This helps in maintaining the integrity of the equipment and preventing leaks or breakdowns that could lead to environmental hazards and significant financial losses.

Manufacturing plants also benefit greatly from the BENTLY 125680-01. It can be used to monitor the vibration and displacement of motors, spindles, and other rotating machinery, ensuring optimal performance and product quality. In facilities where precision is paramount, such as automotive manufacturing or semiconductor fabrication, accurate measurements provided by this module are essential for maintaining production consistency and minimizing defects. Whether it’s in a high-volume production line or a critical infrastructure operation, the BENTLY 125680-01 plays a crucial role in ensuring the reliability and safety of industrial machinery.

350022M 138607-01V

Related products:

BENTLY 125681-01 – An upgraded version with enhanced signal processing capabilities, suitable for more complex monitoring requirements.

BENTLY 125679-01 – A cost-effective alternative with basic measurement functions, ideal for smaller-scale industrial setups.

BENTLY 125682-01 – Offers additional input channels, enabling the monitoring of more sensors simultaneously for comprehensive machinery health assessment.

BENTLY 125683-01 – Designed for high-temperature environments, featuring improved thermal resistance and durability.

BENTLY 125684-01 – Integrates advanced diagnostic functions, providing more detailed insights into sensor and module performance.

BENTLY 125685-01 – Optimized for high-speed applications, capable of accurately measuring rapid changes in equipment parameters.

350022M 138607-01V

Installation and maintenance:

Before installing the BENTLY 125680-01, it is crucial to verify the compatibility of the module with your existing monitoring system and sensors. Check the communication protocols supported by your system to ensure seamless integration. Additionally, confirm that the power supply meets the module’s requirements (24V DC ±10%). During installation, ensure proper grounding to minimize electrical interference. If using DIN rail mounting, make sure the rail is securely fastened and that there is sufficient space around the module for proper ventilation.

For ongoing maintenance, regularly inspect the module’s connections to ensure they are secure and free from corrosion. Check the status indicators on the module to identify any potential issues early. Periodically clean the module using a dry, lint-free cloth to remove dust and debris, especially in dusty environments. It is also advisable to perform calibration checks at regular intervals, following BENTLY’s recommended procedures, to ensure the accuracy of measurements. If any issues are detected, refer to the product manual or contact BENTLY’s technical support team for assistance.
