Bentley 350093 PN135785-02 is a display screen monitoring module that is an essential component of the Bentley 3500 monitoring system. This system is widely recognized in the field of industrial automation for its reliability and accuracy in mechanical monitoring. As part of the 3500 system architecture, the 350093 PN135785-02 module serves as a visual interface, allowing operators to access and interpret data collected by other components of the system.
350093 PN135785-02
It is connected to a 3500 rack, which houses various other modules for data acquisition, processing, and communication. By presenting processed data in an easily understandable way, it simplifies the task of engineers and operators analyzing the health status of machinery. Its value lies in the ability to transform complex technical data into visual prompts, enabling non-technical personnel to grasp the overall status of the monitored equipment.
350093 PN135785-02
Main features and advantages:
In terms of functional performance, it has a high-resolution display screen that can clearly show the subtle details of data. The screen is designed to be easily readable even in bright industrial environments, ensuring that operators can access information without obstruction. It also has a fast refresh rate and provides real-time data updates to immediately display any changes in mechanical performance.
The hardware design of this module is robust and compact. Its sturdy structure enables it to withstand the harsh conditions commonly found in industrial environments, including vibration, dust, and temperature fluctuations. The compact size makes it easy to install in various locations, whether directly on a 3500 rack or in a separate control panel. It offers multiple installation options, increasing flexibility. You can choose to install it from the front, where the display screen is directly mounted on the front panel of the full-size 3500 rack using a special hinge bracket. This method facilitates access to the buffer output connectors and user interface buttons of the rack. It should be noted that when selecting this option, the Display Interface Module (DIM) must be installed in slot 15 (rightmost slot) of the rack, and this option is not compatible with the 3500 small rack. Another option is a 19 inch EIA rack installation, where the display screen can be mounted on a 19 inch EIA rail and can be located up to 100 feet away from the 3500 system (up to 4000 feet when using an external power source). Panel installation is also an option, where the display screen is installed in the panel cutout, which can be located in the same cabinet or up to 100 feet away from the 3500 system (up to 4000 feet when using an external power source). Finally, independent installation allows the display screen to be installed tightly against the wall or panel, with the same distance capability as mentioned above.
Compatibility is a major advantage of this module. It is designed to seamlessly collaborate with other components of the Bentley 3500 system. It can effectively communicate with different types of sensors and data acquisition modules within the system, ensuring smooth transmission of information. It is also equipped with a display communication port, allowing it to interface with other external systems when needed.
From a long-term reliability perspective, the module is designed to operate within a wide temperature range of -20 ° C to 65 ° C. Its maximum power consumption is 15.5 W, which is quite efficient considering its functionality. Bentley regularly provides firmware updates that not only improve its performance, but also add new features and enhance security over time.
350093 PN135785-02
Technical specifications:
Model 350093 PN135785-02
Brand Bentley
Type Display Screen Monitoring Module
Power options of 115 VAC and 230 VAC
Working temperature -20 ° C to 65 ° C
Installation methods include front installation, 19 inch EIA rack installation, panel installation, and independent installation
Interface display communication port
Cooling method: natural convection (based on typical design speculation)
The environmental level is suitable for industrial environments, with dust prevention and a certain degree of moisture protection
contact us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
350093 PN135785-02
Application areas:
In power plants, operators need to continuously monitor the operational status of turbines, generators, and other critical equipment. Bentley 350093 PN135785-02 provides a clear and concise visual interface for displaying real-time data related to mechanical health conditions, including vibration levels, temperature differences, and rotational speeds. This enables operators to make quick decisions, ensuring timely handling of any potential issues, thereby avoiding costly failures and power outages.
In oil and gas refineries, numerous pumps, compressors, and processing units are in operation, and this module provides a convenient way to monitor the status of these devices. Technicians can easily view the data displayed on the screen, which helps optimize equipment operation, reduce energy consumption, and improve the efficiency of the entire factory.
Related products:
Bentley 350092 is a communication module gateway that can be used in conjunction with 350093 PN135785-02 to enable data transmission between different components of the system and external devices.
The Bentley 3500/16 is a sensor related module that provides input data that can be displayed on the 350093 PN135785-02 screen, helping operators monitor specific parameters of the machinery.
Bentley 3500/25 is another module that can contribute to the overall mechanical monitoring process, and its data can be presented through 350093 PN135785-02 to provide a comprehensive view. The Bentley 3500/12 and Bentley 3500/15 are also related modules in the 3500 series, which can be integrated with the 350093 PN135785-02 to enhance the functionality of the monitoring system.
Installation and maintenance:
Before installing Bentley 350093 PN135785-02, it is important to ensure that there is sufficient space in the installation location, especially when choosing front or panel installation. The power supply voltage should be carefully checked to ensure it meets the requirements of the module. When using the front installation option, please ensure that the DIM is installed in the correct slot (slot 15) of the 3500 rack.
For maintenance, it is recommended to conduct regular visual inspections of the display screen to see if there are any signs of damage or abnormal display. Regularly check whether the module connections are loose. Please keep the module firmware updated to take advantage of the latest improvements. If you encounter any problems, you can use the built-in diagnostic function of the 3500 system to troubleshoot issues related to 350093 PN135785-02.
