Name: BENTLEY 136711-01 Advanced Machinery Monitoring Module | Qiming Automation
Brand: Bently Nevada

Description

The BENTLEY 136711-01 is a state – of – the – art monitoring module that seamlessly integrates into the BENTLEY Nevada 3500 machinery protection system. Acting as a vital link between field sensors and the central control infrastructure, it plays a pivotal role in the data acquisition and analysis workflow.

136711-01

When connected to vibration sensors, proximity probes, or other relevant transducers, the module immediately begins processing the incoming raw electrical signals. It applies a series of advanced filtering and amplification techniques to eliminate background noise and interference, ensuring that only the most relevant data is passed through. These refined signals are then converted into digital format with high precision, making them readily analyzable by the 3500 system’s main processing unit.

Communication within the system is optimized through its connection to the 3500 system’s backplane. This allows for seamless data sharing with other modules, enabling a holistic view of the machinery’s operational status. The BENTLEY 136711-01 supports multiple industry – standard communication protocols, such as Modbus RTU and Profibus, facilitating easy integration with external control systems and SCADA platforms. Its built – in diagnostic functions continuously monitor the module’s internal health and the integrity of connected sensors. In the event of any irregularities, it can promptly generate alerts, providing operators with the information needed to take immediate corrective action.

136711-01

Technical specifications:
Model Number 136711-01
Brand BENTLEY
Type Advanced Machinery Monitoring Module
Compatibility BENTLEY Nevada 3500 system
Input Channels 4 channels
Power Supply 24 VDC ± 10%
Operating Temp Range – 40°C to + 70°C
Humidity Range 0% – 95% (non – condensing)
Communication Protocol Modbus RTU, Profibus, BENTLEY proprietary
Dimensions (WxHxD) 175 mm x 38 mm x 105 mm
Weight Approximately 0.7 kg
Interface/Bus Connects to 3500 system backplane
Compliance CE, UL, ISO 13849 – 1
Supported Protocols Modbus RTU, Profibus, BENTLEY protocol
Typical Power Draw 5 W
