Name: BENTLEY 135473-01 high - performance module | Qiming Automation
Brand: Bently Nevada

Description

The BENTLEY 135473-01 is a high – performance module that serves as a crucial link in the BENTLEY Nevada 3500 machinery protection system. It is designed to interface with a variety of sensors, including proximity probes and accelerometers, which are used to measure vibration, displacement, and other key parameters of rotating equipment.

135473-01

Once connected to the sensors, the module receives raw electrical signals and applies advanced signal conditioning techniques to filter out noise and interference. It then converts these signals into digital data that can be easily processed and analyzed by the 3500 system’s mainframe. The BENTLEY 135473-01 communicates with other modules in the 3500 system via the backplane, ensuring seamless integration and data sharing. This allows for real – time monitoring and control, as well as the generation of alarms and alerts in the event of abnormal conditions.

The module supports multiple communication protocols, making it compatible with a wide range of control systems and software platforms. It also features built – in diagnostic capabilities, which continuously monitor its own performance and the integrity of the connected sensors. This proactive approach to diagnostics helps to identify potential issues before they escalate, minimizing the risk of system failures and ensuring the reliability of the overall monitoring system.

135473-01

Technical specifications:
Model Number 135473-01
Brand BENTLEY
Type Machinery Monitoring and Signal Conditioning Module
CompatibilityBENTLEY Nevada 3500 system
Input Channels4 channels
Power Supply24 VDC
Operating Temp Range- 40°C to + 70°C
Humidity Range0% – 95% (non – condensing)
Communication ProtocolBENTLEY Nevada proprietary protocol, Modbus RTU
Interface/BusConnects to 3500 system backplane
ComplianceCE, UL
Supported ProtocolsBENTLEY Nevada protocol, Modbus RTU

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

135473-01

Main features and advantages:

Selecting the BENTLEY 135473-01 module offers a plethora of real – world benefits that can significantly enhance the performance and reliability of industrial operations. Engineered for rugged industrial environments, this module ensures long – term performance and stability. Its robust construction and advanced signal processing capabilities enable it to accurately capture and analyze critical data, providing a clear and comprehensive view of equipment health.

The module’s modular design and compatibility with the BENTLEY Nevada 3500 system make it easy to integrate into existing setups, reducing engineering overhead and minimizing disruption to ongoing operations. Its built – in diagnostic features provide real – time insights into the module’s status and the condition of connected sensors, enabling proactive maintenance and reducing the risk of unexpected failures. By enabling early fault detection and timely intervention, the BENTLEY 135473-01 helps to extend the lifespan of machinery, improve production efficiency, and reduce maintenance costs.

135473-01

Application areas:

The BENTLEY 135473-01module is widely used in industries where the reliable operation of rotating machinery is essential. In power plants, it is used to monitor the condition of turbines, generators, and other critical equipment, ensuring the continuous and efficient generation of electricity. By detecting early signs of issues such as rotor imbalance, bearing wear, or misalignment, it helps to prevent costly breakdowns and power outages.

In the oil and gas industry, the module plays a crucial role in monitoring the performance of pumps, compressors, and other rotating equipment in refineries and offshore platforms. In these harsh environments, where equipment failure can have severe consequences, the BENTLEY 135473-01 provides accurate and reliable data for early fault detection, helping to maintain safe and continuous production.

It is also commonly used in manufacturing plants, where it is used to monitor the performance of high – speed rotating machinery, such as spindles and motors. By ensuring that these critical components operate within optimal parameters, it helps to maintain product quality, improve production efficiency, and reduce the risk of costly downtime.

135473-01

Related products:

BENTLEY 3500/42M – A multi – channel vibration monitor with enhanced data processing capabilities, suitable for more complex monitoring requirements.

BENTLEY 135474 – 01 – An upgraded version with additional input channels and advanced diagnostic features, ideal for large – scale industrial applications.

BENTLEY 135472 – 01 – A more cost – effective alternative with basic monitoring functions, suitable for smaller facilities or less critical equipment.

135473-01

Installation and maintenance:

Before installing the BENTLEY 135473-01 module, it is essential to verify its compatibility with the existing BENTLEY Nevada 3500 system. Check the backplane configuration to ensure that there are available slots for installation and that the power supply meets the module’s requirements. Also, make sure that all necessary communication cables are properly connected and that the sensors are calibrated correctly.

During installation, handle the module with care to avoid any physical damage. Follow the installation instructions provided by BENTLEY carefully to ensure proper wiring and connection. After installation, perform a thorough system check to verify that the module is communicating correctly with the 3500 system and that all sensors are functioning properly.

For ongoing maintenance, regularly review the module’s diagnostic information to detect any potential issues early. Clean the module periodically to remove dust and debris, especially in dusty industrial environments. It is also recommended to perform routine calibration of the sensors connected to the module to ensure accurate data acquisition. In case of any alarms or abnormal conditions, refer to the module’s manual or contact BENTLEY’s technical support for assistance.
