Name: BENTLEY 128229-01 Vibration Signal Conditioning Module | Qiming Automation
Brand: Bently Nevada

Description

The BENTLEY 128229-01 functions as a high-performance vibration signal conditioning module, acting as a bridge between sensors and monitoring systems in industrial automation setups. It integrates seamlessly with BENTLEY’s 3500 machinery protection system, as well as other compatible control platforms, fitting into the I/O architecture to process and transmit vibration data.

128229-01

This module receives raw signals from vibration sensors, applies advanced filtering and amplification to eliminate noise and interference, and converts them into standardized digital signals. It supports high-speed data acquisition, capable of capturing high-frequency vibration components that are crucial for early fault detection. The BENTLEY 128229-01 connects to the system backplane, enabling communication with the main processing unit and allowing for centralized data analysis and alarm generation. Its design includes built-in diagnostics to monitor its own performance, ensuring that any issues with signal processing are quickly identified, maintaining the integrity of the entire monitoring system.

128229-01

Technical specifications:
Model Number 128229-01
Brand BENTLEY
Type Vibration Signal Conditioning Module
Input Voltage 24 VDC ± 10%
Operating Temp Range 0°C to 65°C
Mounting Style Rack-mount (compatible with 3500 system racks)
Dimensions 102mm x 165mm x 229mm
Weight Approximately 500g
Interface/Bus 3500 backplane interface
Compliance CE, UL
Supported Protocols Compatible with 3500 system communication protocols
Typical Power Draw 3.5W

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

128229-01

Main features and advantages:

Choosing the BENTLEY 128229-01 brings significant advantages to industrial operations focused on machinery reliability. Engineered for precision, it ensures that vibration data is accurate and consistent, enabling maintenance teams to make informed decisions about equipment health. This accuracy reduces the risk of false alarms, which can lead to unnecessary shutdowns, and ensures that genuine issues are not missed, preventing costly failures.

The module’s robust design ensures long-term performance even in harsh industrial environments, withstanding temperature fluctuations and electrical noise. This reliability translates to reduced maintenance overhead, as the module requires minimal servicing over its lifespan. Additionally, its seamless integration with existing BENTLEY systems and other control platforms reduces engineering time during installation, allowing for quicker deployment of the monitoring system. By providing high-quality vibration data, the BENTLEY 128229-01 helps extend machinery lifespan, optimize maintenance schedules, and ultimately improve overall operational efficiency.

Application areas:

The BENTLEY 128229-01 is widely deployed in industries where rotating machinery is critical to operations. In power generation, it is used in steam and gas turbine monitoring systems, capturing vibration data to detect issues like rotor imbalance and bearing degradation, ensuring continuous power supply. In the oil and gas industry, it plays a key role in monitoring compressors and pumps in pipeline systems, where equipment failure can lead to environmental hazards and significant financial losses.

In chemical processing plants, the module is utilized to monitor agitators and centrifuges, which operate under demanding conditions. These applications require the BENTLEY 128229-01 to perform reliably in high-temperature and corrosive environments, providing accurate data to maintain process stability. The module’s ability to handle high-frequency signals makes it ideal for detecting early-stage faults in high-speed machinery, ensuring critical system uptime and safety.

Related products:

BENTLEY 125740-01 – A similar vibration conditioning module with additional analog output channels for legacy systems.

BENTLEY 3500/42M – A multi-channel vibration monitor that integrates signal conditioning and processing for larger systems.

BENTLEY 128230-01 – A higher-channel version of the 128229-01, suitable for monitoring multiple machinery points.

BENTLEY 17711-01 – A cost-effective alternative for basic vibration monitoring in less critical applications.

BENTLEY 3500/22M – A dual-channel module designed for combined vibration and position monitoring.

BENTLEY 128228-01 – A predecessor model, still supported for legacy system upgrades.

BENTLEY 3500/92 – A communication gateway module that works with the 128229-01 for data transmission to SCADA systems.

Installation and maintenance:

Before installing the BENTLEY 128229-01, verify compatibility with the existing machinery protection system, ensuring the backplane firmware is up to date for seamless communication. Check the sensor wiring to confirm proper insulation and shielding, as this prevents electrical interference from affecting signal quality. Ensure the mounting rack is properly grounded to avoid ground loops, which can corrupt vibration data.

For ongoing maintenance, regularly inspect the module’s status indicators on the front panel to confirm normal operation—steady green lights indicate proper functioning, while amber or red lights signal issues that require attention. Periodically check the connections between the module and sensors, ensuring they are tight and free from corrosion, especially in humid or dusty environments. It is recommended to perform a calibration check annually using BENTLEY’s calibration tools to maintain measurement accuracy, ensuring the module continues to provide reliable data for machinery condition monitoring.
