The ALSTOM LC105A-1 functions as a high – performance contactor. It is primarily used to switch electrical loads on and off in industrial control circuits. With its robust construction, it can handle significant electrical currents, making it suitable for powering motors, heaters, and other high – power industrial equipment. The contactor operates based on an electromagnetic principle. When an electrical signal is applied to its coil, it generates a magnetic field that attracts the contacts, closing the circuit and allowing current to flow to the connected load.
Model Number LC105A-1
Brand ALSTOM
Type Contactor
Rated Operational Voltage 24 – 690V AC (suitable for a wide range of industrial power systems)
Rated Operational Current 105A (capable of handling high – power loads)
Coil Voltage Available in multiple standard voltages (e.g., 24V DC, 110V AC, 220V AC) for flexibility in different control circuits
Contact Material Silver – alloyed contacts for low contact resistance and long – lasting performance
Operating Temp Range -25°C to +70°C (able to function in a variety of environmental conditions)
Mounting Style Screw – mounting or DIN – rail mounting (35mm), providing installation options to suit different control panel setups
Dimensions 110mm x 80mm x 100mm (W x H x D) (compact size for space – efficient installation)
Weight 500g
Compliance IEC 60947 – 4 – 1, CE, UL 508 (meeting international safety and quality standards)
Number of Pole3 – pole (standard configuration for three – phase industrial applications)
Auxiliary Contacts
1NO + 1NC (normally – open and normally – closed auxiliary contacts for additional control and signaling functions)
The ALSTOM LC105A-1 functions as a high – performance contactor. It is primarily used to switch electrical loads on and off in industrial control circuits. With its robust construction, it can handle significant electrical currents, making it suitable for powering motors, heaters, and other high – power industrial equipment. The contactor operates based on an electromagnetic principle. When an electrical signal is applied to its coil, it generates a magnetic field that attracts the contacts, closing the circuit and allowing current to flow to the connected load.
LC105A-1
One of the key features of the LC105A-1 is its high – breaking capacity. It can safely interrupt large currents, protecting the connected equipment from damage in the event of short circuits or overloads. This is achieved through advanced arc – quenching technology, which rapidly extinguishes the electrical arcs that form when the contacts open, preventing overheating and electrical fires.
The contactor also offers a high degree of reliability. It is designed to withstand a large number of switching cycles, reducing the need for frequent replacements and minimizing downtime. Its compact design allows for easy installation in control panels, saving valuable space. Additionally, it is equipped with auxiliary contacts, which can be used for signaling, interlocking, or controlling other devices in the industrial control system.
LC105A-1
Technical specifications:
Model Number LC105A-1
Brand ALSTOM
Type Contactor
Rated Operational Voltage 24 – 690V AC (suitable for a wide range of industrial power systems)
Rated Operational Current 105A (capable of handling high – power loads)
Coil Voltage Available in multiple standard voltages (e.g., 24V DC, 110V AC, 220V AC) for flexibility in different control circuits
Contact Material Silver – alloyed contacts for low contact resistance and long – lasting performance
Operating Temp Range -25°C to +70°C (able to function in a variety of environmental conditions)
Mounting Style Screw – mounting or DIN – rail mounting (35mm), providing installation options to suit different control panel setups
Dimensions 110mm x 80mm x 100mm (W x H x D) (compact size for space – efficient installation)
Weight 500g
Compliance IEC 60947 – 4 – 1, CE, UL 508 (meeting international safety and quality standards)
Number of Pole3 – pole (standard configuration for three – phase industrial applications)
Auxiliary Contacts
1NO + 1NC (normally – open and normally – closed auxiliary contacts for additional control and signaling functions)
