ALSTOM EP3-E-4-EN Intelligent Switched-Mode Power Supply Module
Sale!
ALSTOM EP3-E-4-EN Intelligent Switched-Mode Power Supply Module
The ALSTOM EP3-E-4-EN functions as an intelligent switched-mode power supply module. Like the EP3-E-4-A, it converts AC input (85-264V AC) into a stable 24V DC output with a maximum continuous current of 4A. However, it adds an Ethernet interface, which is a key difference. This interface supports standard industrial communication protocols such as Modbus TCP/IP, enabling the module to transmit real-time power data (including input voltage, output current, temperature, and operating status) to the central control system or IIoT platform.
Model Number EP3-E-4-EN
Brand ALSTOM
Type Intelligent Switched-Mode Power Supply Module
Input Voltage 85 – 264V AC (50/60Hz)
Output Voltage 24V DC ± 0.5V
Output Current 4A (maximum continuous)
Operating Temp Range -25°C to +70°C
Mounting Style DIN rail (35mm)
Dimensions 130mm x 60mm x 100mm (W x H x D) (slightly wider due to Ethernet interface)
Weight 380g
Efficiency ≥ 91% at full load (slightly higher than EP3-E-4-A)
Compliance IEC 60950-1, CE, UL 508, IEC 61850 (for network communication)
Protection Features Overvoltage, overcurrent, short-circuit, overtemperature, with fault logging
Communication Interface Ethernet (10/100 Mbps), supporting Modbus TCP/IP
Typical Power Draw Dependent on load (up to 96W at full output, additional 2W for communication)
The ALSTOM EP3-E-4-EN functions as an intelligent switched-mode power supply module. Like the EP3-E-4-A, it converts AC input (85-264V AC) into a stable 24V DC output with a maximum continuous current of 4A. However, it adds an Ethernet interface, which is a key difference. This interface supports standard industrial communication protocols such as Modbus TCP/IP, enabling the module to transmit real-time power data (including input voltage, output current, temperature, and operating status) to the central control system or IIoT platform.
EP3-E-4-EN
Another notable feature is its enhanced monitoring and diagnostic capabilities. In addition to the protection mechanisms of the EP3-E-4-A (overvoltage, overcurrent, short-circuit, and overtemperature protection), theEP3-E-4-EN can record fault logs, including the time, type, and duration of each fault. This helps maintenance personnel analyze the cause of faults and take preventive measures. Moreover, it has a built-in web server, allowing users to configure and monitor the module through a web browser without the need for special software, simplifying on-site operations.
EP3-E-4-EN
Technical specifications:
Model Number EP3-E-4-EN
Brand ALSTOM
Type Intelligent Switched-Mode Power Supply Module
Input Voltage 85 – 264V AC (50/60Hz)
Output Voltage 24V DC ± 0.5V
Output Current 4A (maximum continuous)
Operating Temp Range -25°C to +70°C
Mounting Style DIN rail (35mm)
Dimensions 130mm x 60mm x 100mm (W x H x D) (slightly wider due to Ethernet interface)
Weight 380g
Efficiency ≥ 91% at full load (slightly higher than EP3-E-4-A)
Compliance IEC 60950-1, CE, UL 508, IEC 61850 (for network communication)
Protection Features Overvoltage, overcurrent, short-circuit, overtemperature, with fault logging
Communication Interface Ethernet (10/100 Mbps), supporting Modbus TCP/IP
Typical Power Draw Dependent on load (up to 96W at full output, additional 2W for communication)
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
EP3-E-4-EN
Main features and advantages:
The ALSTOM EP3-E-4-EN offers several unique benefits. The addition of the Ethernet interface enables remote monitoring and management, which is particularly valuable for industrial facilities spread over large areas or with harsh on-site environments. For instance, in a remote mining operation, engineers can monitor the power supply status of the control system from the central office, reducing the need for on-site inspections and improving work efficiency.
The enhanced efficiency (≥91%) further reduces energy consumption, which is in line with the trend of industrial energy conservation and environmental protection. The fault logging function provides valuable data for predictive maintenance, helping to minimize unplanned downtime. The web-based configuration simplifies the setup process, allowing technicians with basic IT knowledge to complete the configuration quickly, reducing the reliance on specialized personnel.
EP3-E-4-EN
Application areas:
The ALSTOM EP3-E-4-EN is widely applicable in various industries. In smart grids, it can supply power to the monitoring equipment of substations and transmit real-time power data to the grid management system, facilitating grid dispatching and fault handling. In data centers, where the stability of power supply to server cabinets is critical, it ensures a stable 24V DC power supply for control modules and monitors the power status in real time to prevent potential power failures.
In pharmaceutical production facilities, which have strict requirements for production process stability, the EP3-E-4-EN provides reliable power to the control systems of production lines. Its network communication capability enables the integration of power data into the production management system, ensuring compliance with relevant regulations through complete data records.
EP3-E-4-EN
Related products:
ALSTOM EP3-E-2-EN – A 2A output version with Ethernet interface, suitable for small-scale networked power supply scenarios.
ALSTOM EP3-E-6-EN – A 6A output variant with enhanced network functions, ideal for powering multiple devices in large networked industrial systems.
ALSTOM EP3-E-4-ENR – A redundant version with dual Ethernet interfaces and dual power inputs, ensuring uninterrupted power supply and communication in critical applications.
ALSTOM NMS-100 – A network management software that can centrally monitor and manage multiple EP3-E-4-EN modules, providing data analysis and reporting functions.
ALSTOM EP3-E-4-EN-EXT – An extension module that increases output terminals and supports daisy-chain connection of multiple modules, suitable for complex industrial control panels.
Installation and maintenance:
Installing the ALSTOM EP3-E-4-ENrequires attention to network configuration in addition to the installation requirements of the EP3-E-4-A. The Ethernet cable should be connected to the industrial network switch, and the module’s IP address should be configured according to the network plan to ensure smooth communication with the central control system. It is recommended to use shielded Ethernet cables to reduce electromagnetic interference.
During installation, ensure that the total current of connected devices does not exceed 4A. The module should be mounted in a well-ventilated control cabinet, away from heat sources and vibration sources.
For maintenance, in addition to the regular inspections of the EP3-E-4-A, it is necessary to check the network connection status periodically. Use the web interface to view the fault logs and analyze the operating trend of the module. It is recommended to update the module’s firmware regularly to obtain the latest functions and security patches.
