ALSTOM AS111-2 Analog Signal Isolation & Conditioning Module
Sale!
ALSTOM AS111-2 Analog Signal Isolation & Conditioning Module
The ALSTOM AS111-2 functions as a high-performance signal isolation and conditioning module, serving as a protective barrier between field devices (sensors, actuators) and the central control system. It accepts analog input signals—typically 4–20mA or 0–10V—from field sensors, isolates them from the output side using transformer-based isolation (providing up to 2.5kVrms isolation), and conditions the signal to remove noise and linearize non-ideal sensor outputs. This conditioned signal is then transmitted to PLCs, DCSs, or data loggers, ensuring that the control system receives accurate, reliable data.
Model Number AS111-2
Brand ALSTOM
Type Analog Signal Isolation & Conditioning Module
Input Voltage 24 VDC ±10% (loop-powered option available)
Operating Temp Range -40°C to +70°C (suitable for extreme industrial environments)
Mounting Style DIN rail (35mm) with DIN EN 50022 compliance
Dimensions 22.5mm x 105mm x 118mm (W x H x D) (compact design for dense panel installations)
Weight 120g
Interface/Bus Field wiring terminals (input/output); no backplane required
Compliance IEC 61010-1 (safety), IEC 61326-1 (EMC), UL 508
Supported Protocols N/A (analog signal processing; compatible with all standard analog control systems)
Typical Power Draw 0.8W (loop-powered mode); 1.2W (externally powered)
The ALSTOM AS111-2 functions as a high-performance signal isolation and conditioning module, serving as a protective barrier between field devices (sensors, actuators) and the central control system. It accepts analog input signals—typically 4–20mA or 0–10V—from field sensors, isolates them from the output side using transformer-based isolation (providing up to 2.5kVrms isolation), and conditions the signal to remove noise and linearize non-ideal sensor outputs. This conditioned signal is then transmitted to PLCs, DCSs, or data loggers, ensuring that the control system receives accurate, reliable data.
AS111-2
What sets the ALSTOM AS111-2 apart is its dynamic signal filtering capabilities. Unlike fixed-filter modules that may over-dampen fast-changing signals, this module uses adaptive filtering: it automatically adjusts cutoff frequencies based on signal variability, preserving the integrity of rapid transients (like pressure spikes in hydraulic systems) while suppressing steady-state noise. It also features a wide input range, accommodating both active (powered) and passive sensors without the need for external resistors, simplifying integration into mixed-sensor environments.
AS111-2
Technical specifications:
Model Number AS111-2
Brand ALSTOM
Type Analog Signal Isolation & Conditioning Module
Input Voltage 24 VDC ±10% (loop-powered option available)
Operating Temp Range -40°C to +70°C (suitable for extreme industrial environments)
Mounting Style DIN rail (35mm) with DIN EN 50022 compliance
Dimensions 22.5mm x 105mm x 118mm (W x H x D) (compact design for dense panel installations)
Weight 120g
Interface/Bus Field wiring terminals (input/output); no backplane required
Compliance IEC 61010-1 (safety), IEC 61326-1 (EMC), UL 508
Supported Protocols N/A (analog signal processing; compatible with all standard analog control systems)
Typical Power Draw 0.8W (loop-powered mode); 1.2W (externally powered)
