Allen Bradley 6181X-12TPXPDC 12 inch industrial touch screen HMI

Description

Allen Bradley 6181X-12TPXPDC is a 12 inch industrial touchscreen HMI that seamlessly integrates with Allen Bradley’s FactoryTalk View SE software and various Rockwell automation control platforms including CompactLogix and ControlLogix. As the central interface for operator system interaction, it enables users to send commands, view real-time process data, and monitor system status with unprecedented ease and precision.

Technical specifications:
Model 6181X-12TPXPDC
Brand Allen Bradley
Type 12 inch industrial touch screen HMI
Display screen size 12 inches
Display screen type: LCD with capacitive touch screen
Installation method: Panel installation
Interface/Bus Ethernet/IP, PROFINET, Modbus TCP
Certification CE, UL, cUL
Special function anti glare screen, fanless design, wide working voltage range

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

6181X-12TPXPDC

Main features and advantages:
Its 12 inch high-resolution display achieves the best balance between screen space and compactness, allowing operators to simultaneously view multiple process variables without sacrificing clarity or detail. Capacitive touch screens provide a smooth and intuitive user experience, reducing the learning curve for new operators and minimizing the risk of input errors, thereby improving operational efficiency and productivity.

This HMI is sturdy and durable, with a wide operating temperature range, suitable for various harsh industrial environments ranging from dusty manufacturing plants to extreme outdoor conditions. Its fanless design eliminates the need for regular maintenance associated with fan based cooling systems, reducing downtime and maintenance costs. The seamless integration with Rockwell Automation’s control platform and industrial communication protocol simplifies system design, installation, and debugging work, saving valuable time and resources.

In today’s digital age, the built-in security features of6181X-12TPXPDC are crucial. By protecting automation systems from unauthorized access and network threats, it ensures the continuity of critical operations and the integrity of sensitive data. The ability to customize HMI interfaces using FactoryTalk View SE software enables companies to optimize terminal functionality based on specific operational requirements, providing long-term value and flexibility. Overall, Allen Bradley 6181X-12TPXPDC is a reliable and cost-effective solution that enhances the performance, safety, and efficiency of industrial automation systems.

6181X-12TPXPDC

Application areas:
In the pharmaceutical industry, strict regulatory compliance and precise process control are crucial, and this HMI is used to monitor and control drug production. Operators can use it to track key parameters during the manufacturing process, such as temperature, pressure, and chemical concentration, to ensure product quality and consistency.

In the field of aerospace manufacturing, there is a high demand for precision and reliability, and 6181X-12TPXPDC is used to manage complex assembly lines. It enables operators to supervise the installation of complex components, monitor the performance of robot assembly tools, and ensure that every production step meets strict quality standards.

In power plants, whether they are fossil fuel power plants, nuclear power plants, or renewable energy facilities, Allen Bradley 6181X-12TPXPDC plays a crucial role in monitoring and controlling the power generation process. Operators can use this HMI to manage grid connections, adjust power output according to demand, and monitor the health status of critical equipment to ensure stable and reliable power supply.

6181X-12TPXPDC

Related products:
6181X-15TPXPDC: A 15 inch version with a larger display screen, suitable for applications that require more extensive data visualization and complex control interfaces.
6186M-12PT: Another 12 inch industrial HMI with different features, providing an alternative option for users seeking a balance between functionality and cost.
6181P-12TPXP: A model with similar display sizes but different processing capabilities, suitable for applications with lower data density.
2711P-T12W22D9P-BSHK: A 12 inch widescreen HMI with a robust design, suitable for extremely harsh industrial environments that require high durability.
6181X-12TPXPDC-R: A variant with enhanced redundancy functionality designed for critical applications where system uptime is critical.
6181X-12TPXPDC-S: Equipped with additional security enhancements to provide an extra layer of protection for highly sensitive industrial automation systems.

6181X-12TPXPDC

Installation and maintenance:
Before installing Allen Bradley 6181X-12TPXPDC, it is essential to verify that the DC input voltage of the power supply is within the specified range. Ensure that there is sufficient space for proper ventilation at the installation location of the panel, as HMI generates heat during operation. Although it adopts a fanless design, appropriate airflow around the device helps maintain optimal operating temperature. When making wiring connections, please carefully follow the provided wiring diagram to ensure that power, communication, and any additional sensor or actuator connections are properly terminated. Pay special attention to the correct grounding equipment to prevent electrical interference.

For continuous maintenance, please regularly use soft, lint free fabrics and mild, non abrasive cleaning solutions to clean the surface of the touch screen. This helps maintain the responsiveness of the touch screen and the clarity of the display screen. Regularly check the status indicator lights of the HMI to monitor its operational status. Pay attention to any error codes or warning lights, which may indicate issues such as communication failures or power outages. Check for signs of wear, tear, or loose connections in the power and communication cables. If any damage is found, replace them immediately. Regularly backing up the HMI configuration to external storage devices is also crucial to prevent data loss in the event of hardware or software failures. If any technical issues arise, please refer to the comprehensive user manual or contact Rockwell Automation’s technical support team for timely assistance.
