Name: Allen Bradley 2711P-T6C20D8 6-inch color graphic terminal | Qiming Automation
Brand: A-B
Price: 59664.00 CNY
Availability: InStock

Description

The Allen Bradley 2711P-T6C20D8 is a 6-inch color graphic terminal that seamlessly integrates with Allen Bradley’s FactoryTalk View ME software and various control platforms from Rockwell Automation, such as MicroLogix, SLC 500, and ControlLogix. It serves as the central hub for interaction between operators and the system, enabling users to send commands, view real-time process data, and monitor system status. Its high-resolution color TFT display presents information in vivid graphics, charts, and text, helping to make decisions quickly and accurately.

2711P-T6C20D8

2711P-T6C20D8

Main features and advantages:
Its large-sized, high-resolution color display screen can clearly present complex process data, reduce the time for operators to analyze information, and achieve faster and more accurate decision-making. The intuitive interface design shortens the learning curve for new operators, reduces errors, and improves overall operational efficiency. Its sturdy structure and wide operating temperature range ensure reliable performance in harsh industrial environments, reducing the need for frequent replacement and maintenance. The seamless integration with Rockwell Automation systems simplifies the installation and configuration process, saving time and resources during deployment.

Its compact size makes it very suitable for applications with limited space, such as small control panels or portable devices. Although it is a monochrome display screen, it can present important data clearly and concisely, allowing operators to easily perform basic monitoring and control tasks. It is compatible with multiple communication protocols and Rockwell Automation’s control platform, ensuring integration into existing systems without the need for large-scale modifications. Its reliability and durability contribute to long-term cost savings by reducing maintenance and replacement costs.

2711P-T6C20D8

Application areas:
In the pharmaceutical industry, it is used to monitor and control the drug production process, ensuring strict compliance with quality standards. Operators can view real-time data such as temperature, pressure, and chemical concentration during the manufacturing process and make precise adjustments as needed. In the automotive manufacturing industry, it is used for assembly lines, managing the operation of robotic arms, conveyors, and other equipment. High quality display screens enable operators to closely monitor the production process and promptly identify any issues.

The Allen Bradley2711P-T6C20D8is suitable for applications that only require a simple and compact HMI. In small manufacturing plants, it can be used to control individual machines or production units, providing basic status information and control options for operators. In the food processing industry, it can be installed on small-scale batch production equipment, allowing operators to easily start, stop, and adjust processing parameters. It is also suitable for building automation systems and can be used to monitor and control HVAC systems, lighting, and safety systems in a compact control panel.

2711P-T6C20D8

Related products:
2711P-T10C20D8: A 10 inch color graphic terminal with a larger display screen, suitable for applications that require large amounts of data visualization and complex control interfaces.
2711P-K7C20D8: Equipped with a 7-inch color display and enhanced processing capabilities, suitable for more advanced HMI applications.
2711-K6C5: Provides another option for 6-inch color graphic terminal requirements.
2711-K5A15: A monochrome terminal similar to 2711P-K4M20D but with different functions, providing an economical and efficient solution for basic HMI requirements.
2711P-RP6T: A sturdy panel mounted terminal designed for extremely harsh industrial environments, with higher durability compared to standard models.

2711P-T6C20D8

Installation and maintenance:
Before installing Allen Bradley 2711P-T6C20D8 and 2711P-K4M20D, it is necessary to ensure that the input voltage of the power supply is within the specified range of each terminal. Choose a suitable panel installation location that is both convenient for operators to access and can protect the terminal from environmental factors such as dust, moisture, and high temperature. When making wiring connections, carefully follow the provided wiring diagram to ensure proper connection with other automation system equipment. For both terminals, it is necessary to ensure that the communication settings are configured correctly to match the protocol and address of the connected controller and device. Install the latest version of FactoryTalk View ME software on a compatible computer to fully utilize the functionality of the terminal and access the latest security updates.

For daily maintenance, regularly clean the display screen and touch screen (2711P-T6C20D8) of the terminal with a soft, wear-resistant cloth to remove dust, fingerprints, and other contaminants. Regularly check the status indicator lights of the terminal to ensure normal operation, and pay attention to any error messages or warning signals. Check for signs of wear, breakage, or loose connections in the power and communication cables, as faulty cables can interfere with terminal operation. Regularly backup the configuration of the terminal to prevent data loss in the event of hardware failure or software issues. If any problems arise, please refer to the user manual or contact Rockwell Automation’s technical support team for assistance.
